MSI X870E: ATX 3.1 Ready Motherboard For Next-Gen PCs

Introducing a revolutionary feature to its MSI X870E series motherboards gives MSI great pleasure. This cutting-edge technology, which offers the additional power needed for AI computation and GPU-intensive applications, was created with professionals and gamers in mind. With its inbuilt 8-pin PCIe power connector, the supplemental PCIe Power feature provides more power to GPUs that require more watts, enabling them to operate at their best. When combined with the ATX 3.1 power standard, which can withstand a 2.5x power excursion for improved power delivery and reliability, this feature guarantees steady, effective, and prolonged performance even when faced with high loads. For the most demanding conditions, this additional PCIe Power gives unparalleled reliability and stability, whether gaming or handling complicated programs.

Supplemental PCIe Power: What Is It?

Consider it an additional motherboard battery pack. The motherboard‘s 24-pin power socket provides 12V electricity to the system, which powers the RGB extensions, fans, and PCIe interface in general. Even still, the additional PCIe power makes sure everything functions properly when your PC is stressed, such as when playing very graphically demanding games or using all of the fan dissipation for optimal performance.

- Advertisement -

With more power, you can work more efficiently, play games longer, and use your PC to its full potential without worrying about power outages or unstable systems. The Supplemental PCIe Power guarantees that your system remains stable and operates at peak efficiency, regardless of whether you’re running sophisticated AI programs or immensely demanding games. It’s like knowing that whatever you put at it, your system will keep up.

ATX 3.1

Motherboards from MSI X870E series are prepared to accommodate the most recent ATX 3.1 and PCIe 5.1 standards, offering the best basis for computing that will last into the future. Users can now run even the most demanding a games and apps with confidence thanks to the Supplemental PCIe Power feature, since their system is supported by MSI’s cutting-edge power management technology and ready to handle future increases in processing power requirements.

MAG X870 TOMAHAWK WIFI

Key Features of Power Management Broken Down

MAG X870 TOMAHAWK WIFI motherboard is one way MSI caters to performance-hungry customers. Imagine using it with the cutting-edge GeForce RTX 4090 SUPRIM X 24G GPU and AMD Ryzen 9950X processor. These components use a lot of electricity while operating at maximum load. Generally, the 24-pin 12V power connector on the motherboard is limited to 168W of power. This may be sufficient for simple activities, but when trying to push everything to its limits, particularly with RGB lighting, fans, and a powerful GPU like the 4090 connected, it becomes insufficient.

The MSI 8-pin Supplemental PCIe Power Connector comes into play in this situation. This extra connector on the MAG X870 TOMAHAWK WIFI offers up to 252W of additional power, making sure that everything has adequate power to function as intended. The combined power output of the 24-pin and 8-pin connectors is 420W, which provides the system with enough headroom to function properly even in the most taxing circumstances.

- Advertisement -

MSI X870E Motherboards

For users, what does this mean? The MSI X870E motherboards are guaranteed to offer the steady, reliable power required to manage high-end GPU performance and optimized system cooling at the same time thanks to the Supplemental PCIe Power. Whether adding a second GPU or overclocking a 4090 GPU, these motherboards are well-suited to handle the upcoming generation of power-hungry components, providing performance and stability. for AI demanding processing workloads.

The ATX 3.1 / 3.0 Ready PCIe5 PSU series from MSI provides reliable and effective power delivery for all connected devices, fully supporting the extra 8-pin PCIe power need. This includes strong support for all MEG, MPG, and MAG types, guaranteeing effective power distribution across the motherboard and any attached peripherals.

X870E Motherboard price

The price of an X870E motherboard can vary depending on the manufacturer, features, and retailer. On average, similar embedded or specialized ARM-based boards like the X870E might range from $50 to $150 USD

X870E Release Date

The MSI X870E series motherboards with Supplemental PCIe Power will be available for purchase on September 26.

Read more on govindhtech.com

[govindhtech]

MSI EZ DIY With X870E/X870 Motherboards For AMD Ryzen

MSI EZ DIY Features with X870E and X870 Motherboards for AMD Ryzen Processors.

MSI X870E

MSI is known for creating high-quality PC hardware with user-friendly designs and functionality. They introduced the first tool-less M.2 slot in 2022, enabling storage drive installation without a screwdriver. This simple function generated a lot of favorable response, prompting us to add it to other motherboard components.

EZ DIY

MSI’s X870E and X870 Motherboards provide EZ DIY

MSI is introducing additional DIY-friendly capabilities to the 800-series AM5 motherboards to ease constructing, troubleshoot, and modify your PC. They made creating your PC simpler and more fun, whether you’re an expert or a beginner.

One-Hand PC Build

The motherboard might be difficult to install in your PC case due to case stand-offs, I/O backplates, etc. The MSI X870E and X870 motherboards‘ EZ Slide Installation and EZ Mounting ease this procedure and protect your important components.

Pre-installed I/O Shield + Smart Backplate Design=EZ Slide Installation

PC construction may be unpleasant and painful when installing an I/O shield manually. To simplify installation, a pre-installed I/O shield removes this step. They’re pleased to announce that all MSI X870E and X870 motherboards will come with I/O Shields.

The MEG X870E motherboards include a metal backplate to protect the back components and make installation easier.

Easy mounting: Collision Notification, Double ESD Protection, Keep Out Zone

PC builders worry about safety while installing the motherboard in a case. EZ Mounting features ensure component safety and allow for mistakes without catastrophic failure.

MSI X870E Motherboard

Installation with One Finger

MSI invented the tool-less M.2 slot in 2022, and your support has kept us going. The MSI X870E and X870 motherboards now include EZ DIY capabilities that let you install numerous popular PC components with a single finger, making installation and upgrades easy.

Installation: EZ Magnetic M.2 Shield Frozr II + EZ M.2 Clip II

All MEG and MPG X870E motherboards’ EZ Magnetic M.2 Shield Frozr II makes M.2 heatsink installation/removal so easy you’ll forget you required a screwdriver to access your NVMe SSD.

For other MSI 800-series AM5 motherboards, tehir tool-less EZ M.2 Shield Frozr II heatsink will improve installation and removal.

When updating or creating a new PC, the little M.2 drive screws mysteriously disappear, which everyone dislikes. With an easy clip, the EZ M.2 Clip II installs your NVMe SSD in seconds without tools!

EZ GPU Installation: PCIe Release + Clip II

Since SSD installation is tool-less, They focused on simplifying graphics card installation and removal, one of your PC’s most costly components! Beginners find it tough to fiddle with an uncomfortable PCIe latch beneath their graphics card to remove it without hurting it or their motherboard.

All MSI AM5 800-series gaming motherboards include an EZ PCIe Release button to remove your graphics card from its slot with one finger. The EZ PCIe Clip II, available on other 800-series motherboards including MSI’s PRO line, has an expanded latch that makes it simpler to remove your graphics card.

Easy System Command: Buttons and Switches

Whether a BIOS update abruptly ends or a faulty setting causes boot loops or instability, difficulties might arise unexpectedly. The Clear CMOS, Flash BIOS, and Dual BIOS switches help you recover quicker.

Smart Button: You may configure the Smart Button on the rear I/O to initiate a Safe Boot, reboot, maximum fan speed, or toggle your Mystic Light RGB lighting in your BIOS.

Boot and Reset Button: These onboard buttons let users boot or reset their device without the front panel buttons. As a Smart Button, the Reset Button adds functionality.

The Flash BIOS Button lets you update your BIOS without a CPU or memory.

Avoid removing the CMOS battery again using the clear button. This button on the motherboard’s back resets the BIOS to default and boots.

If anything goes wrong, Dual BIOS Switch takes control. Flip the switch to use the second BIOS!

EZ LED Switch: Faster, simpler system lighting control.

Single-Look Identification

Without the necessary features, troubleshooting is unpleasant. That’s why all MSI X870E and X870 gaming motherboards provide debug tools like a 7-segment POST code display!

EZ Digi-Debug, Debug, and Memory Detection LEDs

Startup or boot troubles unrelated to your OS may make even the simplest PC-building experience a misery. MSI’s Gaming Series (MEG, MPG, and MAG) motherboards now include an EZ Digi-Debug LED, a 7-segment display displaying POST codes, to help diagnose boot difficulties.

EZ Debug LEDs on other MSI motherboards help PC builders identify the component causing boot issues.

EZ Memory Detection LEDs solve the age-old tech support question: Is your RAM working? After detecting a memory stick misbehaving or no memory in that slot, these LEDs flash up.

EZ Monitoring: Dynamic Dashboard III

Monitoring CPU/GPU temperatures, clock speeds, and fan speeds may make or break a steady overclock or boot loop.

Dynamic Dashboard III on the MEG X870E GODLIKE makes hardware monitoring easy. Its huge 3.99-inch LCD screen displays CPU/GPU temperatures, fan speeds, clock speeds, and more in real time, helping you maintain system stability and performance.

Lost EZ Identify Manual? Not to worry!

They’ve added a lot of useful information to the motherboard, but consulting your manual is always a smart idea. For instance, legends surrounding M.2 slots now indicate which drives they support (PCIe or SATA). On the back I/O, USB speeds are clearly marked.

Do More in One Step

A few steps might make PC building unpleasant. The MSI X870E and X870 motherboards include several one-step features that make PC construction easier.

EZ Link: GODLIKE Cable Management

The MSI Project Zero motherboard for a clean, cable-free design to produce the MEG X870E GODLIKE motherboard.

EZ Link reduces cable clutter without modifying the motherboard architecture, allowing neater setups with common PC components. With the EZ Bridge and EZ Control Hub, you can route untidy case front panel wires, fan cables, ARGB/RGB connections, and more to the motherboard’s back and side!

Connecting: EZ Conn-Design + Front Panel Cable

Some MSI-exclusive connections decrease PC clutter. First, MSI PRO series X870 motherboards include a 7-pin (4-pin Fan + 3-pin ARGB) header for one-step ARGB fan wiring.

The X870E and X870 gaming series motherboards’ JAF_V2 11-pin (4-pin Fan + 3-pin ARGB + 4-pin USB) connector lets you connect MPG CORELIQUID P-Series Liquid AIO Coolers with a single cable! Even without one, this JAF_V2 header works with the accompanying 1 to 3 EZ Conn-Cable to connect to the ARGB, Fan, and internal USB ports on many AIO Coolers.

Digging into your case to plug in small connections is difficult. The EZ Front Panel cable has an extension to plug in the headers outside the case, making this simpler.

EZ Plug: Slide M.2 + Wi-Fi Antenna

Image Credit To MSI

Installing or replacing an M.2 drive requires opening your PC, which might be difficult. Accessing M.2 SSDs via the rear I/O using MSI’s M.2 XPANDER-Z SLIDER GEN5 in the MEG X870E GODLIKE removes this problem. It supports two M.2 drives at PCIe 5.0 x4, so performance never suffers for convenience.

The EZ Wi-Fi Antenna is another cool addition to their X870E and X870 motherboards. It plugs in one step for fast installation and removal.

MSI X870 Motherboards

Performance Boost in One Click

Even the simplest construction method is useless without top-notch hardware performance. The MSI X870E and X870 motherboards include several EZ DIY features that boost thermal, CPU, and networking performance.

Click BIOS X, MSI newest BIOS interface, streamlines and simplifies the interface for both experienced and novice over clockers on these motherboards.

EZ Overclocking: Game Boost, AI Boost, EXPO with New Click BIOS X

Overclocking improves hardware performance without overheating. When utilizing a suitable RAM kit, enable EXPO with one click to overclock! Memory Try It lets you overclock your memory to higher clock rates or tighter timings! It provides a list of typical memory settings to easily cycle through.

To simplify overclocking, they created Game Boost, a one-click CPU overclock that optimizes CPU performance instantaneously. However, AI Boost is a clever algorithm that boosts NPU performance for optimal AI performance when horsepower is needed.

MSI Center Smart Management: EZ Optimization

Many AI capabilities integrate AI into your computing experience to make better, real-time choices. Manage and customize your PC experience using the MSI Center’s sleek, basic interface. For instance, AI Engine optimizes PC performance depending on applications.

Read more on govindhtech.com

[govindhtech]

COMPUTEX MSI Introduces DIY Power Supplies and PC Cases

COMPUTEX MSI 2024

The yearly technology extravaganza, COMPUTEX MSI, is here, and MSI, a top motherboard company in the world, is determined not to miss this significant occasion. In order to extend a hearty welcome to guests from all around the world, MSI has made every effort to display the newest technologies.

COMPUTEX MSI Presenting Thunderbolt 4, New Memory Solutions, and Easy DIY

The new X870 motherboards will catch your eye as soon as you walk up to the demonstration because to their sleek, modern appearance. Apart from AMD desktop processors from the Ryzen 9000 series, the MSI X870 motherboards feature the newest do-it-yourself designs that are unique to COMPUTEX MSI. The improved screwless M.2 Shield Frozr makes it simple to install M.2 heatsinks, and the EZ PCIe Release makes it simple to remove a large graphics card with just one finger.

The SSD installation and removal process is made quick and easy with the help of the EZ M.2 Clip II. The EZ Antenna, an MSI DIY accessory, is another noteworthy design. It makes it simple to plug in and remove Wi-Fi connectors with only one hand and eliminates the need to rotate the antennas. Additionally, the display offers an exploration of Intel Next-Gen desktop motherboards.

New motherboards with creative memory options will also be on display alongside. MSI is pleased to present the Z790 PROJECT ZERO PLUS, which utilises the newest memory technology, CAMM2, in partnership with Kingston. Using a compression connector on the rear of the module that inserts into a narrow vertical socket, the CAMM2 is thought to be a laptop substitute for the SO-DIMM.

The CAMM2 reduces compatibility difficulties by supporting dual-channel per module on motherboards. Additionally, each module supports up to 128GB, offering outstanding speed and capacity for demanding computing requirements. Extreme overclocking is made possible by these optimisations, offering enthusiasts looking for the best performance possible.

A new age of connectivity begins with Thunderbolt 4’s speed, adaptability, and efficiency. Imagine using one fast cable to transfer data, power several devices, and connect to high-resolution displays. Thunderbolt 4 transforms MSI gaming and work. A Thunderbolt 4 type-C connector lets a professional photographer edit high-resolution photographs and backup files to an external storage. Thunderbolt 4, with up to 40Gbps, ensures lag-free performance even with huge multimedia files.

A new programme called Thunderbolt Share, which made its premiere at COMPUTEX MSI, promises to improve everyday computing experiences outside of work environments. Envision quickly adding more ports and accessories to your desktop by simply attaching your laptop to a docking station. Transmitting multimedia files becomes effective and blazingly quick with Thunderbolt Share. Get ready to discover Thunderbolt’s full potential during MSI’s demonstration.

MPG P Series and MAG A Series New Liquid Cooling Reveal

MSI’s main goal has always been to improve the user experience. After adding do-it-yourself designs to its motherboards, MSI is now taking on liquid cooling. With MSI’s EZ DIY Designs, the MPG CORELIQUID P Series provides an easy-to-assemble solution without sacrificing performance. The UNI Bracket greatly reduces assembly complexity by supporting AMD and Intel sockets.

You can eliminate cable clutter thanks to the united cable design, which simplifies the connection between the radiator fan and the water block into a single cable. More screen space is available for showing material thanks to the panel’s upgrading from a 2.4″ D Series panel to a 4.3″ IPS panel. Users may enjoy optimal screen viewing thanks to the bigger panel’s customisable angles and design, which fits the MSI 270-degree panoramic cases.

The first MSI liquid cooler that use the UNI Bracket, the MAG CORELIQIOD I Series, with a number of easy-to-assemble DIY designs that make installation a breeze. The pre-installed fans on the wire cover and radiator guarantee a neat and orderly appearance within your PC case and make dust removal simple.

Together with an optimised base thickness that ensures complete CPU coverage and an expanded cooper base surface, the MSI I Series also improves effective heat dissipation. At COMPUTEX MSI, the MAG CORELIQUID A Series also makes its premiere. Along with its triangle water block design, the A Series liquid cooler has pre-installed fans and a UNI Bracket. These innovative goods provide guests with a variety of displays that highlight various facets of innovation.

Investigating Advanced Power Source

COMPUTEX MSI takes great pleasure in its outstanding motherboards and amazing AIO liquid cooling systems. Of course, a strong PSU is necessary to supply enough power to maximise the performance of your components. High-wattage power supplies are required by enthusiasts, and the MSI MEG Ai1600T PCIE5 with ARGB lighting effects surpasses all expectations. Its high efficiency conversion rate and construction with superior titanium materials guarantee steady and reliable power delivery.

The SiC-MOSFET with interleaved PFC in the PSU improves power correction efficiency and stability. You can quickly and simply monitor current and wattage with MSI Centre, which gives you important information about your computer system. The MEG Ai1600T PCIE5, which has two native 12V-2×6 connectors, satisfies ATX 3.1 requirements with a 2x total power excursion and a 3x GPU power excursion, making it future-ready for use in AI computing.

Furthermore, MSI is pleased to present the new MPG GS Series power supply, which complies with ATX 3.1 specifications and has two 12V-2×6 connections. Before the end of 2024, the MPG GS Series which comes in 1200W, 1000W, and 850W variations will be introduced, offering choices to match your particular power equipment. The new power supply has been designed to reduce fan noise. To make cable management easier, the supplied cables are also made to be flat, and the cable headers are now yellow.

The Ideal Match for Your Parts Modern Style Chassis

By the end of the year, MSI will be releasing the MPG VELOX 300R AIRFLOW PZ, a new mid-tower PC case with two 160 mm ARGB PWM fans up front and one 120 mm PWM fan down back. It is intended to maximise airflow. With metal panels and an aluminium nameplate, the external design features metal components that are reminiscent of the MPG VELOX Series case. The diamond-shaped cutout design on the front panel ensures effective ventilation of airflow.

The 160 mm dual layer blade fan design specific to COMPUTEX MSI: the outside blades provide stability, while the interior blades focus airflow. The fan extends airflow farther than traditional blade designs by synchronising the outer and inner blades. Even in large-sized cases, the extended cold focused airflow enhances heat dissipation efficiency.

Taking a little break from the gaming theme, MSI presents the new Modern Series case, which combines style and utility. The MSI Modern Series case is made with a 4 mm anodized aluminium front panel frame and goes through several meticulous production procedures to achieve a visually appealing and minimalist design through mixed-material assembly.

Because of its superb craftsmanship, the case can easily incorporate maple wood accents, which makes it ideal for Scandinavian-style rooms that are popular among designers and aficionados of white-themed setups. Maple wood offers a sense of beauty and is frequently used in furniture because of its strength and longevity. To ensure easy transportation of your project, the two sturdy maple wood handles on top have also undergone extensive testing to sustain weights of up to 50 kg.

Additionally, an upper area is supplied for the addition of ornamental components. The inner fans’ wooden embellishments draw attention to their natural beauty and elegance. The front fan bracket design allows for easy adjustment to accommodate a range of fan sizes, from 120 mm to 200 mm, without compromising functionality. This innovative enclosure supports back-connect motherboards, including ATX and Micro-ATX sizes, for a neat and tidy PC construction.
