Hardness Tester- TEST-301

Hardness Tester- TEST-301Measuring tablet thickness, diameter and hardness the PHARMAG INSTRUMENTS TabTest-301 Tablet Hardness Tester is both USP and EP compliant and offers excellent flexibility and configurability. This robust 301 design removes the need for a thickness gauge, eliminating redundant calibrations and reducing overall testing cost.

Product Features:

USP PHARMACOPEIA AND EP COMPLIANT: Compliant with USP < 1217> and EP <2.9.8>.

MULTI-PARAMETER MEASUREMENTS: The TabTest -301 measures:

Thickness

Diameter

Hardness

LED DISPLAY: The seven-segment display provides calibration, thickness, diameter, and hardness results.

SMALL FOOTPRINT: Ideal for laboratories with limited bench space. The compact, lightweight design is well-suited for portability and use in a production setting.

"OPTIONAL" BUILT-IN PRINTER: Available with an optional 40-column built-in printer.

SAMPLE THROUGHPUT: Approximately 6-10 samples per minute.

"ADJUSTMENT FREE" TESTING JAWS: No adjustments needed for the test jaws. They are designed to suit all tablet shapes and sizes with a unique grooved design to properly align each tablet before testing.

Specifications:

Display: LED

Keypad: User-friendly 9-key operations

Hardness Range: 5 - 500 N

Hardness Accuracy: >1 N

Diameter and Thickness Range: 1.5 - 40 mm

Diameter Accuracy: >±0.06 mm

Measurements: Thickness and diameter in either mm or inches

Measurable Units:

N (Newton)

KP (KiloPond, 1 KP = 9.81 N)

Sc (Strong Cobb, 1 KP = 1.435 c)

Force Rate Constant (Linear): Force or constant (linear) speed

Number of Tests for Statistics: Up to 99

Stored Methods: Last test result

Calibration Procedure: Requires 10 mm Reference Block and 10 kg Reference Weight (Certified)

Calibration Technique: No tilt (user-friendly)

Distance Validation: 10 mm Certified Block (For Thickness and Diameter)

Load Cell Linearity: 3-Point Linear Calibration with Certified Weight (5, 10, 15 kg)

Load Cell Diagnostic Check: Yes (Check the Load Cell Signal Falls Within Range Before Making Any Further Calibration)

Self Test: Yes

Fault Localization: Yes (Text Format)

Load Cell Overload Protection: Yes

Password Protection: Yes (For Advance Settings)

Factory Setting Reset: Yes

Real-Time Clock: Yes

No Tablet Detection: Yes

Interface Ports:

RS-232 (Serial Port for Service Use Only)

External 80/40 Column Printer

40 Column Built-In Mini Dot Matrix Printer

Dimensions: 235 (L) x 420 (B) x 195 (H) mm

Weight: 16.5 lbs / (7.5 kg)

Electrical Power:

115V ± 15V, 50/60 Hz or

230V ± 23V, 50/60 Hz visit www.technovalue.in for more information
