Accelerate Wireless Innovation with Wi-Fi 7 (802.11be) RF Transceiver IP Core

T2M IP, a global leader in semiconductor IP cores and advanced connectivity solutions, has announced the availability of its partner’s cutting-edge Dual-Band Wi-Fi 7 RF Transceiver IP Core. Featuring an integrated Front-End Module (FEM), this next-generation IP solution is optimized for both consumer and industrial applications and is now available for licensing in TSMC’s 22nm ULL process.

Designed to meet the growing demands of bandwidth-hungry and latency-sensitive applications, the new Wi-Fi 7 RF Transceiver IP core supports a broad range of high-performance use cases—from set-top boxes and smart TVs to AR/VR headsets, streaming devices, automotive infotainment systems, and industrial IoT applications. The integration of the FEM simplifies system design, reduces bill of materials (BoM), and enhances RF performance, making it a highly attractive solution for chipmakers developing the next wave of wireless SoCs.

Wi-Fi 7: The Future of Wireless Connectivity

As wireless data consumption continues to surge, Wi-Fi 7 (IEEE 802.11be) is set to become a game-changer in the world of connectivity. Offering data rates well into the multi-gigabit range, ultra-low latency, and significantly improved spectral efficiency, Wi-Fi 7 enables truly seamless connectivity across an array of smart devices.

The T2M IP partner’s transceiver IP fully complies with the Wi-Fi 7 standard and includes backward compatibility with Wi-Fi 6/6E. Supporting both 1024-QAM and 4096-QAM modulation schemes, this IP core delivers highly efficient and high-throughput wireless communications. The advanced modulation enables higher data rates within the same spectrum, resulting in better performance in environments crowded with competing wireless signals—such as smart homes, public venues, and industrial facilities.

Optimized for Performance and Efficiency

One of the core highlights of this IP solution is its compact design and power efficiency. Engineered for minimal die area, the transceiver operates with ultra-low power consumption, making it especially suitable for battery-powered and thermally constrained devices like wearables and AR/VR headsets.

In addition to superior RF performance, the IP core includes built-in features for robust interference mitigation, seamless roaming, and reliable data transmission in dynamic environments. These capabilities ensure high-quality connectivity for mobile and embedded systems that must operate in varying and often challenging RF conditions.

Tri-Band Support and Scalability

The transceiver IP supports operation across the 2.4GHz, 5GHz, and 6GHz bands, providing full tri-band coverage for maximum flexibility and network performance. This tri-band support enables a broader range of applications and ensures compatibility with existing Wi-Fi infrastructure, while also future-proofing devices for emerging Wi-Fi 7 deployments.

Currently, the IP supports bandwidths of up to 80MHz, which is suitable for a wide range of high-speed applications. Looking ahead, the roadmap includes support for 160MHz bandwidth by Q2 2025, which will further elevate the performance of multi-user MIMO and OFDMA (Orthogonal Frequency-Division Multiple Access) technologies. This scalability makes the IP ideal for building flexible, future-ready wireless SoCs that can evolve alongside the Wi-Fi standard.

Accelerating Next-Gen SoC Development

With the introduction of this highly integrated Wi-Fi 7 RF Transceiver IP core, T2M IP and its partner aim to accelerate innovation in the semiconductor industry. By providing a complete, production-ready IP solution that balances high performance, power efficiency, and small footprint, T2M IP enables SoC developers to meet tight design schedules and get their products to market faster.

This IP is particularly beneficial for Access Point applications, including home and enterprise routers, where enhanced range, bandwidth, and throughput are critical. Integrating this solution into next-generation SoCs will empower OEMs to deliver faster, smarter, and more reliable wireless experiences to users worldwide.

Availability and Licensing

The Dual-Band Wi-Fi 7 RF Transceiver IP Core is now available for immediate licensing. Interested parties can reach out to T2M IP for more information on licensing models, deliverables, and pricing details.

About T2M IP

T2M IP is a leading global technology provider specializing in the licensing of semiconductor IP cores. With a robust portfolio that includes wireless, cellular, analog, mixed-signal, and connectivity IP solutions, T2M IP serves semiconductor companies worldwide in developing innovative, next-generation products across consumer, automotive, and industrial markets.

[apieinvestavimapaprastai]

Discover the Synopsys stock price forecast for 2025–2029, with insights into financial performance, AI-driven growth, and investment tips. #Synopsys #SNPS #SNPSstock #stockpriceforecast #EDAsoftware #semiconductorIP #AIchipdesign #stockinvestment #financialperformance #Ansysacquisition #sharebuyback

[atreybhosale]

In the past few years, the semiconductor and EDA industries have been through several changes. And, perhaps, in this Intellectual property (IP) has significantly contributed as well. Semiconductor intellectual property (IP) or IP cores are basically the reusable unit of logic or functionality that is generally developed with the idea of certifying to multiple dealers for use as structuring blocks in different chip designs.

It is used to develop advanced integrated circuits (IC’s). These design components are traded as verification units and therefore called intellectual property. Furthermore, these IP cores are combined to produce system on chip (SoC), application-specific integrated circuits (ASICs), and application-specific standard products (ASSPs).

Attributed to the applications and utilization of IP core, the industry has witnessed increased demand. Also, the market players have highly contributed to the development and innovations in IP cores. However, the increasing competition has led the companies to adopt numerous strategies such as collaborations, new product launches, and business expansions.

[t2mip]

12-bit 5MSps SAR ADC IP Core by T2M

T2MIP, high-performance 12-bit successive approximation register (SAR) ADC designed for precision, speed, and ultra-low power operation. This new IP core achieves conversion rates up to 5 mega samples per second (MS/s), making it ideally suited for next-generation applications that require high-speed data acquisition with minimal power consumption.

This cutting-edge 12-bit SAR ADC IP core is specifically engineered to meet the demanding requirements of modern SoC (System on Chip) and ASIC (Application-Specific Integrated Circuit) designs. It offers a unique balance of high-resolution data conversion, excellent dynamic performance, low power consumption, and flexible configuration options. These attributes make it a perfect fit for a variety of industries including industrial automation, precision measurement systems, wireless communications, and advanced microcontroller-based applications.

The need for energy-efficient, high-precision analog interfaces continues to grow across a wide range of industries. From portable industrial devices and battery-powered sensors to high-speed communication systems and automotive control units, designers increasingly require ADCs that not only deliver performance but also minimize energy draw. T2MIP’s new SAR ADC core directly addresses this need by providing exceptional signal quality and flexible operating modes while maintaining ultra-low power consumption.

The 12-bit resolution ensures accurate signal quantization, while the 5MS/s sampling rate makes the core well-suited for fast signal processing tasks. This performance is achieved without compromising power efficiency, a feature critical for embedded systems and IoT devices where power budget is often a limiting factor.

Key Performance Metrics

One of the standout features of T2M’s new SAR ADC IP is its high dynamic performance. The converter delivers a Signal-to-Noise and Distortion Ratio (SINAD) of 70 dB and a Total Harmonic Distortion (THD) of -72 dB, which translates to an Effective Number of Bits (ENOB) of 11.3 bits. This makes it ideal for applications requiring high fidelity and accurate representation of analog signals.

Design flexibility is another cornerstone of this IP core. It supports multiple input modes—both single-ended and differential—and can handle up to four input channels. This allows designers to tailor the ADC’s input architecture to their specific system requirements, whether that involves sensing multiple voltages or improving common-mode noise rejection.

Furthermore, the ADC supports selectable resolution modes—8-bit, 10-bit, and 12-bit—allowing developers to trade off between precision and power consumption as needed. Conversion modes include both single conversion and continuous operation, providing adaptability for event-driven or real-time sampling use cases.

One of the most notable innovations in this SAR ADC IP core is its scalable power consumption architecture. In idle mode, it draws zero static (DC) power, and its dynamic power consumption is directly proportional to the clock frequency. This intelligent power scaling makes it ideal for energy-sensitive applications where processing loads vary over time.

In addition to its baseline low-power operation, the IP core also includes extended power management modes. Designers can select between low-noise and ultra-low power modes depending on the performance priorities of the system. For example, battery-powered sensors can operate in low-power mode to extend life, while instrumentation systems can switch to low-noise mode for increased accuracy.

The ADC operates at ultra-low voltages, with an analog supply range from 3.3V down to 1.8V, and a digital supply of just 1.1V. This wide supply compatibility ensures the core can be easily integrated into modern low-voltage SoC platforms without the need for costly voltage level shifters or regulators.

Key Features:

12-bit Resolution with up to 5MS/s Conversion Rate

High Dynamic Performance: SINAD of 70dB, THD of 72dB, and ENOB of 11.3 bits

Multiple Input Modes: Supports both single-ended and differential configurations with up to 4 input channels

Zero DC Power with scalable consumption tied to clock frequency

Selectable Resolution: Operates in 8, 10, or 12-bit modes

Multiple Conversion Modes: Continuous and single conversion modes supported

Extended Sampling & Power Modes: Includes low-power and low-noise modes for tailored performance

Flexible Reference Options: External and optional internal reference support

Ultra-Low Voltage Operation: Analog supply from 3.3V to 1.8V; Digital supply at 1.1V

Advanced Functions: Self-calibration, optional hardware averaging, window watchdog

These advanced features not only improve performance but also simplify the overall design and reduce development time by eliminating the need for external supporting logic in many applications.

Ideal Applications and Use Cases

This SAR ADC IP core is highly suitable for applications requiring compact, power-efficient, and high-performance data conversion. Common use cases include:

Microcontrollers and Embedded Systems: Extend battery life while maintaining accurate analog signal capture in portable electronics, wearables, and sensor nodes.

Industrial Instrumentation: Achieve precision measurements in multichannel monitoring and control systems with minimal power draw.

Broadband Wireless Systems: Convert analog signals at high speed with excellent dynamic range, aiding in RF baseband processing and signal analysis.

Automotive Electronics: Integrate with automotive MCUs for tasks like battery monitoring, motor control, and advanced driver-assistance systems (ADAS).

By addressing the core challenges of low power, high resolution, and easy integration, this ADC IP enables semiconductor manufacturers and system developers to accelerate product development without compromising performance.

Licensing and Availability

T2MIP’ new 12-bit, 5MS/s SAR ADC IP core is available immediately for licensing. semiconductor ip is delivered with comprehensive documentation, test benches, and integration support to ensure a smooth implementation into your design flow. Interested in evaluating or licensing the core can visit t-2-m.com or contact T2M directly at contact@t-2-m.com

[t2mip]

eDP 1.4 Tx PHY, Controller IP Cores with Visual Connectivity

T2M-IP, a leading provider of high-performance semiconductor IP solutions, today announced the launch of its fully compliant DisplayPort v1.4 Transmitter (Tx) PHY and Controller IP Core, tailored to meet the escalating demand for ultra-high-definition display connectivity across consumer electronics, AR/VR, automotive infotainment systems, and industrial display markets.

As resolutions, refresh rates, and colour depths push the boundaries of visual performance, OEMs and SoC developers are prioritizing bandwidth-efficient, power-conscious solutions to deliver immersive content. T2M-IP’s DisplayPort 1.4 Tx IP Core answers this need—supporting up to 8.1 Gbps per lane (HBR3) and 32.4 Gbps total bandwidth, alongside Display Stream Compression (DSC) 1.2, enabling high-quality 8K and HDR content delivery over fewer lanes and with lower power consumption.

The market is rapidly evolving toward smarter, richer media experiences. Our DisplayPort v1.4 Tx PHY and Controller IP Core is engineered to meet those demands with high efficiency, low latency, and seamless interoperability enabling customers to fast-track development of next-generation display products with a standards-compliant, silicon-proven IP.

Key Features:

Full compliance with VESA DisplayPort 1.4 standard

Support for HBR (2.7 Gbps), HBR2 (5.4 Gbps), and HBR3 (8.1 Gbps)

Integrated DSC 1.2, Forward Error Correction (FEC), and Multi-Stream Transport (MST)

Backward compatible with DisplayPort 1.2/1.3

Optimized for low power and compact silicon footprint

Configurable PHY interface supporting both DP and eDP

The IP core is silicon-proven and available for immediate licensing, supported by comprehensive documentation, verification suites, and integration services to streamline SoC design cycles.

In addition to its DisplayPort and eDP 1.4 IP solutions, T2M-IP offers a comprehensive portfolio of silicon-proven interface IP cores including USB, HDMI, MIPI (DSI, CSI, UniPro, UFS, SoundWire, I3C), PCIe, DDR, Ethernet, V-by-One, LVDS, programmable SerDes, SATA, and more. These IPs are available across all major foundries and advanced nodes down to 7nm, with porting options to other leading-edge technologies upon request.

Availability: Don't miss out on the opportunity to unlock your products' true potential. Contact us today to license our DisplayPort and v1.4 Tx/Rx PHY and Controller IP cores and discover the limitless possibilities for your next-generation products.

About: T2M-IP is a global leader and trusted partner cutting-edge semiconductor IP solutions, providing cutting-edge semiconductor IP cores, software, known-good dies (KGD), and disruptive technologies. Our solutions accelerate development across various industries, including Wearables, IoT, Communications, Storage, Servers, Networking, TV, STB, Satellite SoCs, and beyond.

For more information, visit: www.t-2-m.com to learn more.

[t2mip]

ADC IP 14-Bit, 4.32 GSps Silicon-Proven with No Royalty

T2M-IP, the global independent semiconductor IP Cores provider & Technology experts, is pleased to announce the immediate availability of its partner’s 14-bit 4.32Gsps Time-interleaved Pipeline ADC IP Core, fully silicon-proven and whitebox ready for licensing without royalty fees. This cutting-edge technology promises to enhance the performance and efficiency of a wide range of electronic devices, from advanced consumer electronics to critical medical and industrial applications.

Key Features of the 14-Bit ADC IP Core (Time-Interleaved Pipeline ADC IP):

Ultra-Fast Sampling Rate: Achieves a remarkable 4.32 GSps (Giga-samples per second), ensuring high-resolution data acquisition at unprecedented speeds.

Superior Signal-to-Noise Ratio (SNR): Delivers a 60dBFS SNR (9.7 Effective Number of Bits, ENOB) for input frequencies ranging from 54MHz to 1794MHz, providing excellent signal clarity and accuracy.

Versatile Input Signal Handling: Features external AC coupling for the input signal and supports a 1.0Vpp differential full-scale input, with buffered analog inputs to maintain signal integrity.

Optimized for Power Efficiency: Operates with dual power supplies—1.8V for analog processing and 1.0V for digital compensation—offering a balance between performance and power consumption.

Broad Input Signal Bandwidth: Handles input signals within the 54MHz to 1794MHz range, making it ideal for a wide variety of high-frequency applications.

Low Power Operation: Includes a power-down mode for energy-saving operation, further enhancing its suitability for power-sensitive applications.

Efficient Data Output: Provides 16x14-bit data output at 270 MHz (4.32GHz/16) along with a Data Ready output signal at 270MHz, ensuring seamless integration into high-speed digital systems.

Proven in Silicon: Developed and verified using 28FDSOI technology, this ADC IP has been successfully extracted from a production DOCSIS Tuner STB chip, underscoring its reliability and readiness for deployment in commercial applications.

Availability and Licensing

For more information about the 14-bit 4.32Gsps Time-interleaved Pipeline ADC IP Core and how it can benefit your projects, or to inquire about licensing opportunities, please contact contact@t-2-m.com

About T2M: T2MIP is the global independent semiconductor technology expert, supplying complex semiconductor IP Cores, Software, KGD, and disruptive technologies enabling accelerated development of your Wearables, IOT, Communications, Storage, Servers, Networking, TV, STB and Satellite SoCs. For more information, please visit: www.t-2-m.com

Availability: These Semiconductor Analog IP Cores are available for immediate licensing. For more information on licensing options and pricing please drop a request / MailTo

[t2mip]

T2MIP is the global independent semiconductor technology experts. Semiconductor Interface IP Cores are available for immediate licensing.

For more information on licensing options & pricing please visit on: https://t-2-m.com/

[t2mip]

T2MIP is the global independent semiconductor technology experts. Semiconductor Interface IP Cores are available for immediate licensing.

[t2mip]

Hello Connections,Are you tired searching for the right career opportunity? Here we have kept the door open for the right talent to join us.Kindly feel free to get in touch with us if you are a passionate, smart, and talented engineer and looking for the right opportunity to grow.

[t2mip]

T2MIP is the global independent semiconductor technology experts. Semiconductor Interface IP Cores are available for immediate licensing either stand alone or with pre-integrated Controllers & PHYs.

[t2mip]

T2M Top Semiconductor IP Cores Company

[t2mip]

T2M world top semiconductor Intellectual property (IP) company supplies complex system level semiconductor Digital, SW, RF IP Cores , KGD & Disruptive technologies enabling accelerated development of IoT, wireless & consumer electronics devices.

[t2mip]

T2M top semiconductor Intellectual property (IP) company supplies complex system level semiconductor Digital, SW, RF IP Cores , KGD & Disruptive technologies enabling accelerated development of IoT, wireless & consumer electronics devices. For More Info Visit On: https://t-2-m.com/

[t2mip]

T2M top semiconductor ip company supplies complex system level semiconductor Digital, SW, RF IP Cores , KGD & Disruptive technologies enabling accelerated development of IoT, wireless & consumer electronics devices. For More Info Visit On: https://t-2-m.com/
