OpenCV Porting on T507 Platform with Linux 4.19: A Deep Comparison Between Standalone Compilation and Buildroot Compilation

OpenCV is an open-source computer vision library that provides a rich set of image processing and computer vision algorithms, supporting multi-platform development. It can be used for various computer vision tasks such as image and video processing, feature extraction, object detection, image segmentation, pose estimation, and object recognition. There are two methods for porting OpenCV: standalone compilation and Buildroot compilation.

Standalone Compilation of OpenCV

Standalone compilation requires CMake, a cross-platform build system similar to the commonly used ./configure. Once configured, it generates a CMakeLists.txt file that defines the project's build rules.

1. Install CMake

2. Configuration

First, extract opencv-2.4.13.7.tar.gz, enter its directory, and run cmake-gui to open the configuration interface.

(1)Set the source code path and build output path (the output path must be created in advance);

(2)Click Configure and select Unix platform cross-compilation mode;

(3)Configure compiler settings.

(4)Configure compiler settings after configuration.

Enable TIFF support.

Disable CUDA (Compiling with CUDA fails; CUDA is for NVIDIA GPUs, which are not available on T507, so disabling it has no impact).

Select Grouped to configure the installation path in cmake.

Cancel GTK

Reconfigure and generate the build files.

3. Compilation

Before compiling, modify the CMakeLists.txt file to configure linker rules:

The goal is to configure the rules for the connector,

-lpthread: Links the libpthread.so library, which provides multithreading support

-lrt: links the librt.so library, which provides real-time extension-related functions

-lrt: links the librt.so library, which provides real-time extension-related functions

make compilation

4. Installation and Deployment

The installation path needs to be cleared before installation.

make install.

Generated test program.

Generated library.

There is also a part of the build path.

Package the above content and release it to the file system of the board.

5. Test

The program can be called to the library to run normally.

However, there are still some errors in the application processing.

Build root compile opencv

1. Enter the Graphical Interface

2. Select Compilation Parameters

Select opencv3 in the following path

Tick all the parameter items.

3. Save the .config file.

Go to the output path of the source package/OKT507-linux-sdk/out/t507/okt507/longan/buildroot，

Change the existing target file to any name and create a new target file

4. Standalone Compilation

Networking is required for the compilation process

Buildroot outputs the standalone compiled content to the previously created **target** directory. The contents can then be packaged and deployed to the **filesystem**.

5. Test

ZD-Atom provides an OpenCV Qt test program based on **i.MX6UL**, where the **.pro** file defines the application's dependencies.

These libraries are available in the files generated by the compilation.

Both methods have their pros and cons:

Standalone Compilation: Allows trying different source versions and offers more flexible parameter configuration, but the process is complex.

Buildroot Compilation: Enables easy deployment by simply extracting the generated files, but switching versions is inconvenient.

[chemical-processes]

I want a fic where murderbot has to act human around another Secunit who's 10000% convinced that it's human and needs immediate rescue

[forlinx]

Forlinx Officially Launches RISC-V SoM Based on StarFive JH7110!

Forlinx has officially launched their latest System-on-Module, featuring the powerful StarFive JH7110 RISC-V chip. These versatile SoM and compatible carrier board are now available for order, catering to a wide range of applications including commercial, medical, and industrial automation.

Recently, a few embedded products have emerged utilizing the same processor, including the VisionFive 2, Pine64, and Milk-V Mars. However, the FET7110 SoM will be the first product from Forlinx to feature the integrated Jinghong 7110 processor. See the JH7110 block diagram for reference.

• JH7110 – 64-bit RISC-V, up to 1.5GHz (quad SiFive U74-RV64GC, up to 5.09 CoreMark/MHz)

JH7110 block diagram

The JH7110’s GPU integrates the IMG BXE-4-32 MC1 (up to 600MHz) which offers full support for mainstream APIs like OpenCL 3.0, OpenGL ES 3.2, and Vulkan 1.2.

Regarding power consumption, Forlinx indicates that the JH7110 is segmented into eight independently switchable power domains. Additionally, the CPU frequency can be dynamically adjusted via software, allowing customers to fine-tune the frequency based on various application scenarios that require flexible control and power consumption.

The JH7110 facilitates camera access through both MIPI-CSI and DVP interfaces, with ISP support. It enables video decoding capabilities of up to 4K@60fps and video encoding of 1080p@30fps. Moreover, the SoM supports HDMI (4K@30fps) and RGB (1080p@30fps) display output interfaces, along with MIPI-DSI (2K@30fps).

Specifications listed for the FET7110-C SoM include:

• Memory/Storage:

￮ 2/4GB LPDDR4 RAM

￮ 32GB eMMC 5.0

￮ 100 Mbps QSPI

￮ SD 3.0/MMC 5.0

• Connectivity:

￮ 2x GMAC for RMII/RGMII 10/100/1000 Mbps

• Display/Audio:

￮ 1x HDMI 2.0 (up to 4K@30fps)

￮ 1x 4-lane MIPI DSI, (up to 2K@30fps)

￮ 8-lane I2S PCM/TDM

• Camera:

￮ 1x 4-lane MIPI-CSI

• Expansion:

￮ 1x PCIe2.0x1, 2 PCIe2.0 controllers integrated w/ PHY

• USB:

￮ 1x USB 2.0

￮ 1x USB 3.0

• I/O Peripherals:

￮ 6x UART, 7x I2C, 7x SPI

￮ 1x SDIO

￮ 8x PWM

￮ 64x GPIOs

￮ 2x CAN 2.0B (Up to 5Mbps)

• Power:

￮ 5V DC

• OS:

￮ Linux 5.15.0

• Mechanical:

￮ 60 x 38mm

￮ B2B connectors (3x 80-pin)

Specifications listed for the OK7110-C development board include:

• Memory/Storage:

￮ 2/4GB  LPDDR4 RAM

￮ 32GB eMMC 5.0

￮ 100 Mbps QSPI

￮ SD 3.0/MMC 5.0

• Connectivity:

￮ 2x Gigabit Ethernet ports

• Display/Audio:

￮ 1x HDMI 2.0 port

￮ 1x MIPI DSI

￮ 2x Speakers

￮ 1x Mic

• Camera:

￮ 1x MIPI-CSI

• Expansion:

￮ 2x PCIE 2.0

￮ 1x Micro SIM

• USB:

￮ 1x USB Type-C

￮ 3x USB 3.0

• I/O Peripherals:

￮ 2x CAN

￮ 2x RS485

• Other Features:

￮ 1x Power button, 1x Reset key

￮ RTC battery

• Power:

￮ 12V DC (via barrel connector)

• Mechanical

￮ B2B connectors (3x 80-pin)

These products are now available for ordering. Customers can find the product page for the FET7110-C SoM here.
