Downpipe Protector

Downpipe Protectors are designed to avoid potential collisions or impact away from pipes, cables and other similar assets. These are suitable to use in warehouse, facility, car park and working environments with frequent vehicle or forklift traffic.

Finish: Galvanised , Powder Coated Yellow

Size: Width 150mm x Depth 150mm x Height 1200mm Thickness 1.95mm

Hole Size for fixing: 10mm Holes

Note: OEM service is available, different materials and specifications can be customized according to your demands.

[rayleigh-bp]

U-Shaped Bollard

Our Heavy-Duty U-Shaped Bollard is designed to provide robust protection for pedestrians, equipment, and infrastructure in industrial and commercial environments.

Material：Heavy-duty steel

Tube Diameter: Available in 2.5", 3", 4", 4.5"or customized

Wall Thickness: 3mm, 4mm, or as required

Height: 24", 36", 42", 48" (customized)

Width: 36", 48", or customized as per request

Base Plate: 6" x 6", 8" x 8", or customized, with pre-drilled mounting holes

Surface Treatment: Galvanized or powder-coated

Installation: Surface mount with anchor bolts

[rayleigh-bp]

Pallet Racking Protector

Our pallet racking protectors is designed to protect pallet racking systems, shelving, and warehouse infrastructure from forklift impacts and accidental collisions.

Key Features:

Available In Three Size: To suit racking from 900mm--2700mm in width. These options cover single racks and back-to-back racking.

Bolt Down Installation: Fast and easy to install onto any strong and suitable warehouse flooring.

Vibrant Colouring: Bright yellow with black hazardous warning stripes warn machine operators of potential danger.

Guide Roller Option: Optional guide rollers help deflect impacts, reducing stress on fixing points.

Adjustable Size: Each size can be fine-tuned to fit precisely around racks for better protection without obstruction.

Indoor Use: Suitable indoors in almost all warehouse and factory environments.

Durable High-Quality Materials---Made from heavy-duty 5mm and 3mm gauge steel.

Note: OEM service is available, different materials and specifications can be customized according to your demands.

[rayleigh-bp]

Heavy Duty Column Protectors

Two-piece design for protecting in-plant columns and other vertical support members. Hardware is included to connect both pieces together.. Powder coat safety yellow finish.

· Two piece design for protecting vertical support members

· Includes hardware to connect both pieces together

· Heavy-duty welded steel construction for added strength

· Feature 2 base plates, each of which has 4 pre-drilled mounting holes.

Material: Heavy Duty Steel.

Heights: 600mm, 900mm and 1200mm.

Outside Diameter: 114mm.

Base Plate: 200mm by 200mm AB-Column Guard .

Color: Powder Coated Safety Yellow.

Service Range: Columns and vertical supports with measurements of up to 500mm by 500mm.

Note: OEM service is available, different materials and specifications can be customized according to your demands.

[rayleigh-bp]

Wheel Guide

Wheel guides are essential for loading bays, helping HGV drivers align vehicles safely and reducing damage to tail bars, lifts, wheels, and dock equipment. Easy to install, they guide vehicles into position and act as protective barriers.

· Colour: Yellow

· Material：Steel

· Finish：powder coat，spray paint or galvanized

· Tube Size: 2070mm Length x 250mm Width x 200mm Height

· Bolt Hole Size (mm)：16

· Thread Depth (mm)：10mm

· Number of Fixing Holes：8

Note: OEM service is available, different materials and specifications can be customized according to your demands.

[rayleigh-bp]

Personnel Gate

· Constructed with high-quality ASTM A1011 steel.

· Width Range: 21" to 48"

· Height 43" or customizable

· Finish: Painted or Galvanised (optional)

· Keep Personnel Safe --- The EdgeSafe Personnel Access Gate swings both ways to alert pedestrians about an upcoming area

Note: OEM service is available, different materials and specifications can be customized according to your demands.

[rayleigh-bp]

Impactable Bollard & Barrier Range

• Constructed with high-quality ASTM A1011 steel.

• Powder-coated handle it yellow for maximum visibility and durability.

• Heights: 18”, 27", 36", 42", 43” tall posts with hardware included

• Rail lengths from 2′ to 10′ long.

• Custom units available

Note: OEM service is available, different materials and specifications can be customized according to your demands.

[rayleigh-bp]

Pallet Rack Column Steel Guards

Material: Steel

Diameter: Ø 76.10 mm x tube Ø5 mm or customized size

Width: 800, 900, 1100, 1700, 1900 mm or customized size

The vertical height is 37 cm (center line) from the floor or according to your needs

Finish: powder coated any color, galvanized, and galvanized plus powder-coated

This low rack protection protects your shelves or storage racks from damage, eliminating the need for maintenance and replacement. Thanks to its flexible bases, your floor remains undamaged. The rack protector is ideal for mitigating forklift impacts. Thanks to its low profile, the rack protection can be placed under almost any rack end, saving floor space.

Recommended use: rack ends and storage racks, concrete floors, warehouses and production facilities, and loading docks.

Note: OEM service is available, different materials and specifications can be customized according to your demands.

[rayleigh-bp]

Standard Barrier Protection / Heavy-duty Guardrail

Regular size: Pipe post: 2.5’’ diameter, schedule 80 pipe or other sizes

Pipe rails: 4’’ schedule 40 pipe or other sizes

Standard Heights: 14 3/4’’, 27’’, 36’’, 42’’，Custom configurations available

Standard Lengths: 4’, 6’, 8’, 10’，Custom configurations available

Impact Resistant: Withstands multiple forklift crashes, protecting equipment and workers in high-traffic areas.

Easy to Install: No on-site welding or bolting required, reducing installation time and costs.

Note: OEM service is available, different materials and specifications can be customized according to your demands.

[rayleigh-bp]

Corner Protection Bollard

Our heavy-duty corner protection bollards are designed to safeguard machinery, buildings, and office spaces by fitting securely around corners. Constructed from welded steel for long-lasting durability, these guards feature a scratch-resistant yellow powder-coated finish with black safety stripes for enhanced visibility. The size is tailored to your needs.

Note: OEM service is available, different materials and specifications can be customized according to your demands.

[rayleigh-bp]

Double-Sided Bike Rack

Durable Construction:

Made from heavy-gauge steel for exceptional durability and strength.

Features a galvanized finish, ensuring resistance to rust and weathering.

High Capacity:

Accommodates up to 10 bicycles, perfect for high-traffic areas such as schools, workplaces, and public parks.

Sturdy Design:

Built with a 1-5/8" OD frame and 14-gauge crossbars, securely welded at the top and bottom for maximum stability.

Space-Efficient Dimensions:

Overall dimensions: 60"L x 37.75"W x 28.5"H, offering a compact yet spacious solution for bike storage.

This double-sided bike rack is a reliable and efficient solution for organizing and securing bicycles in busy environments

[rayleigh-bp]

Single-sided Bike rack

Durable Construction:

Made from heavy-gauge steel to ensure long-lasting performance.

Features a galvanized finish for superior corrosion resistance, even in harsh outdoor conditions.

Ample Capacity:

Designed to securely hold up to 5 bicycles, making it ideal for schools, parks, and commercial spaces.

Robust Design:

Built with a 1-5/8" OD frame and 14-gauge crossbars, welded securely at the top and bottom for enhanced stability.

Compact Dimensions:

Overall dimensions: 60"L x 27.75"W x 28.5"H, providing efficient use of space while accommodating multiple bikes.

This single-sided bike rack combines functionality and durability, making it a practical choice for bike storage solutions.

[rayleigh-bp]

Strength Equipment

· Our perforated square tubings can be used to make all kinds of strength equipments.

· Punched with holes on all four sides down the entire length, convenient for the equipment assembling .

· Different sizes (1.50”, 1.75", 2.00", 2.25", 2.50" etc) with 12 or 14 gauge are available as per request.

· Durable rust resistant powder coating with all kinds of colors are available according to customers' demand.

· These strength equipments can help people improve overall health and enhance stability and balance.

[rayleigh-bp]

Mobile Homes

Our perforated square sign posts are used for Mobile Homes

[rayleigh-bp]

Chicken Reaper System

Our perforated square sign posts are used for Chicken Reaper System.

[rayleigh-bp]

Square Tube Cart

· Perforated Square Tube: 1.75"x32", 1.75"x25", 2.0"x14.25" all with 12 Gauge thickness.

· Wheels:13"x5"- 6" size with 4PR tire.

· Caster: Two fixed caster and one swivel caster.

· Steel plates: 120x120x5mm.

· Carriage bolt and pins: Four bolts and one pins.

· Usage: Transport Air Conditioner.

[rayleigh-bp]

20in Fire Pits

Material: Hot-rolled steel, no coating or surface treatment required

Size: Semicircular plate: Hot-rolled steel plate thickness 3.04mm, width 381mm, length 1048mm, circle diameter 597mm;

The entire square plate is flat: Hot-rolled steel plate thickness 4.8mm, width 483mm, length 1217mm, the width of the left and right square plates is 267mm each

Two small plates connecting the grill and the square plate: Length 312mm, thickness 9.5mm, width 32mm, edge curvature is 16mm radius, grill: Hot-rolled rods are 12.5mm in diameter, 6 are 610mm long; The longer hot-rolled rods are 659mm long, 114mm wide, and the spacing is 19.5mm; There are four hot-rolled rods at the bottom, with spacings of 189mm, 156mm, and 189mm respectively; the back of the upper hot-rolled rod is 30.5mm longer than the lower hot-rolled rod, the front is 45mm longer, and the width is 23mm on both sides
