education3244 · 1 year ago

Text

Ansys Workbench Online Course | Get Hand On Training

Get our Ansys Workbench Online Course to understand the fundamentals and advanced features of this software, which is used by the mechanical, structural, aerospace, and computer-aided design (CAD) industries. Register Now!!

#ansyscourse #ansysworkbench #ansysworkbenchonline #ansysworkbenchcourse #ansystraining #ansysworkbenchtraining

1 note · View note

alotimeysltd-blog · 6 years ago


In November, we shall be live at the University of Ibadan to take the COMPUTATIONAL FLUID DYNAMICS TRAINING (ANSYS), courtesy of NIMechE UI-SC. It promises to hold a lot of learnings. Join us! @ui_bests @nuesa_unimaid_chapter @nuesa_uniport @ife_edu_ @_face_of_nuesa_national2k19 @unilorin_engineers @nuesaui @ife_edu_ @unilorin_engineers @nuesa_unilag @nuesaabuad @nuesa_engr @nationalconferencenuesa @biu_nuesa @nuesauniuyo @nuesauniabuja @nuesa_funaab @futonuesa @nuesa_osustech_chapter @nuesa_ig @nuesa_engr @nuesaunilag @nuesaprime_switch @nuesa_uniabuja #learniningman #mindset #alotimeys #photooftheday #class #skill #october #collaboration #ogun #learnings #institution #mechanicalengineers #cad #autodeskinventor #ansysfluent #ansysworkbench (at University of Ibadan) https://www.instagram.com/p/B3zUzN1hUun/?igshid=1t6y2d4db83sq

#learniningman #mindset #alotimeys #photooftheday #class #skill #october #collaboration #ogun #learnings #institution #mechanicalengineers #cad #autodeskinventor #ansysfluent #ansysworkbench

0 notes

bookpiofficial · 6 years ago

Text

Improved Dual Electrothermal Microgripper based on a Chevron actuator | Chapter 03 | Advances in Applied Science and Technology Vol. 3

In Micro-Electro-Mechanical Systems (MEMS) technology, there is an important interest in the characterization of devices using dynamic analysis, which is a technique to determine the dynamic behavior of a structure or component, involving time, inertia and the possibly damping of the structure. This paper is focused on the analysis and simulation of an improved dual microgripper and its components: microcantilever and chevron. In addition, a movement amplifier based on an arrangement of beams was also designed in order to improve the opening of each jaw of the top gripper. Dual microgrippers are designed on silicon and implemented using Professional Autodesk Inventor. Top gripper is initially closed, while the down one is initially open. The analytical response of the microgripper components was acquired with Steady-State Thermal, Static Structural, and Modal modules of Ansys Workbench Software. The dynamic behavior, resonance frequencies for chevron actuator and dual microgrippers are presented. Simulation results show the modal shapes of allanalyzed devices, determining their respective modal frequencies. A comparison between initial and improved dual microgrippers was also performed. About the top grippers, the increment showed by the improved microgripper in total displacement is of 24.4%, and the temperature distribution only showed a little reduction (7%). For the case of the down gripper, the total displacement decrease in approximately 50%, force remains without change and its temperature shows a little decrement (7.2%). In both dual microgrippers, the biggest temperature value resides in the chevron inside, at the top part of its shuttle, with 162.76°C. Supply voltage was considered from 0 to 7 V. This swept could be useful to determine the more appropriate voltage level to obtain adesirable response. In each analyzed device, their corresponding modal shapes, using FEA, were determined. The modal shapes analysis allow to understand the performance of the analyzed devices, at the correspondent frequency. From the comparison between initial and improved dual microgrippers, implemented with Silicon, special attention was given to the top grippers. Total displacement showed by the improved microgripper has a maximum value of 0.86 μm. Third natural frequency remains almost without change (4.7%), increasing at 70.38 kHz and the temperature distribution only showed a little reduction (7%, maximum temperature was of 131.49°C), which is better for practical applications. For the case of the down grippers of improved dual microgripper, the total displacement decrease in approximately 50% (with a value of 0.18 μm), force remains without change (3.8 μN) and its temperature decreases (7.2%), at 162.77°C, which is also better for practical applications. These parameters values of the improved dual microgripper are illustrative for possible applications.

Author(s) Details

Margarita Tecpoyotl Torres

Centro de Investigación en Ingeniería y Ciencias Aplicadas, IICBA-CIICAp-UAEM, Mexico.

Pedro Vargas Chablé

Doctorado en Ingeniería y Ciencias Aplicadas, IICBA-CIICAp-UAEM, Mexico.

Alejandra Ocampo Diaz

Doctorado en Ingeniería y Ciencias Aplicadas, IICBA-CIICAp-UAEM, Mexico.

Ramon Cabello Ruiz

Universidad Tecnológica Emiliano Zapata del Estado de Morelos (UTEZ), Mexico.

Read full article: http://bp.bookpi.org/index.php/bpi/catalog/view/39/147/281-1

View Volume: https://doi.org/10.9734/bpi/aast/v3

#cantilever #Book #Science #AnsysWorkbench #MEMactuators #resonancefrequency

0 notes

stckonsultan · 6 years ago


Training ANSYS Basic Fluent CFD yang di selenggarakan oleh PT Surabaya Teknika Cipta Konsultan pada 25-27 November 2019 di Hotel Santika Pandegiling Surabaya

#ansys #ansysfluent #ansysworkbench #ansyscfx #trainingansys #ansys_fluent #ansyscfd #stckonsultan #trainingdisurabaya

0 notes

meesam-ali · 9 years ago

Video

tumblr

My first heat flux analysis (very basic level) using ANSYS Workbench 16.2

#ansys #ansysworkbench #heatflux #FEM #analysis

0 notes
