Epson Xp 2100 Driver For Mac

Epson Xp 2100 Driver For Mac Download

Scan Epson Xp 2100

Epson Xp 2100 Printer

Epson Xp 2100 Driver Mac Os

Epson Xp 2100 Driver Mac Catalina

Epson Xp 2100 Driver

Hello, Welcome to kiysoft.com, If you want to find information about Epson XP-4100 Driver, Software, Manuals, Downloads for Windows 10, 8, 7, 64-bit, and 32-bit, macOS, Mac OS X, and how to Install for needs, below we will provide other information such as, Review, Specs, Setup Manual, etc. for you, a little information for you, the Files or Software that we provide are from the Official Site, so you don’t need to be afraid to download them on here.

Epson Scanner Drivers Epson XP-2100 VueScan is compatible with the Epson XP-2100 on Windows x86, Windows x64, Windows RT, Windows 10 ARM, Mac OS X and Linux. If you're using Windows and you've installed a Epson driver, VueScan's built-in drivers won't conflict with this. When you're looking for an affordable, stylish and easy-to-use printer, the XP-2100 is sure to tick all the boxes. It’s also compact, produces clear and vibrant prints and is capable of mobile printing with Wi-Fi, Wi-Fi Direct and a range of compatible Epson apps.

Epson XP-4100

Categories: Printer

Author: Epson

Epson XP-4100 Specs

Printing Technology4-color (CMYK) drop-on-demand MicroPiezo® inkjet technologyMinimum Ink Droplet Size3 picolitersMaximum Print Resolution5760 x 1440 optimized dpiISO Print SpeedBlack: 10.0 ISO ppm Color: 5.0 ISO ppmInk TypeClariaInk Configuration4 individual ink cartridgesTemperatureOperating: 50° to 95° F (10° to 35° C) Storage: -4° to 104° F (-20° to 40° C)HumidityOperating: 20 – 80% Storage: 5 – 85% (no condensation)DimensionsPrinting: 14.8″ x 22.8″ x 9.5″ (W x D x H) Storage: 14.8″ x 11.8″ x 6.7″ (W x D x H)Weight9.5 lb

Epson XP-4100 Review

As Epson confirmed with the old Expression House XP-452, spending plan home printers don’t have to look low-cost and play awful. You can have a color screen, cordless printing and a suitable collection of attributes without investing more than ₤ 50. The brand-new Expression Home XP-4100 includes one more fiver to the spending plan and has a great deal alike with last year’s design, yet it really feels pared back in a couple of methods. The outcome is a residence printer that still seems to punch above its weight, however maybe not quite as high over as Epson’s older version. The Expression Home XP-4100 rests somewhere in the middle of Epson’s 2019 home printing line-up, being available in above the somewhat less costly XP-2100 as well as XP-3100, but below the XP-5100 and the XP-6100, we considered earlier this year.

It incorporates a typical four-ink print system with a 1200dpi scanner and 802.11 n Wi-Fi, supplying a selection of a direct COMPUTER or smartphone to printer connection or the more common link throughout a house network. It’s an extremely portable printer, smaller sized also than other portable residence all-in-ones like the Canon Pixma TS-8350, with a desktop impact of simply 37.5 x 30cm, though it stands taller than the Pixma at 17cm. With its 2.4 in color display, gloss-black surfaces and also rounded edges you could also define its appearances as trendy, though it doesn’t really feel rather as premium, specifically around the thin-plastic flaps and also lightweight hinges. We presume that a person at Epson has made a reasoning call and also chose smartphone printing is in while printing from external storage space is passé, but where the old XP-452 had a USB Type-A port as well as an SD card slot, the XP-4100 just has a solitary USB Type-B port for a direct link to PC.

The emphasis right here is far more on cordless printing, however– as is so usually the case– the setup wizard does not, in fact, take you via establishing the wireless link. It does not truly matter, as choosing the wireless icon as well as clicking ALRIGHT takes you right through to the wireless setup procedure. This is rather straightforward but prepare for some tiring moments if you need to go into a safety password. All the features, settings and maintenance stuff is managed with the color display as well as what looks like a touch-sensitive panel, however, it becomes a more old-fashioned control panel using clicky membrane switches. Most of the time this is fine, and also the alternatives tend to be logical and much where you ‘d anticipate them. Going into any kind of text, however, is something of a duty.

Here are 2 methods for downloading and updating drivers and software Epson XP-4100 safely and easily for you, hopefully, it will be useful.

Direct Download here – for your first option it is very easy to download it, it can be for you who are beginners because we have provided the download file for you.

Manually – for the second option you can follow the tutorial that we provide below for you, step by step to download Epson XP-4100.

Download the latest Epson XP-4100 Driver, Software manually

Go to the Epson Official Website

Enter Type Epson XP-4100 of your product, then you exit the list for you, choose according to the product you are using.

Select the OS that suits your device.

Then Download the Software or Drivers that you want.

Enjoy !!

Epson XP-4100 Driver, Software Download for Windows

File Name: XP4100_Lite_NA.exe

File Size: 12.9 MB

License: Freeware

Supported OS: Windows 10 32-bit, Windows 10 64-bit, Windows 8.1 32-bit, Windows 8.1 64-bit, Windows 8 32-bit, Windows 8 64-bit, Windows 7 32-bit, Windows 7 64-bit, Windows XP 32-bit, Windows XP 64-bit, Windows Vista 32-bit, Windows Vista 64-bit

Epson XP-4100 Driver, Software Download for Mac

File Name: XP4100_XP4105_Lite_64NR_NA.dmg

File Size: 9.90 MB

License: Freeware

Supported OS: macOS 10.15.x

Epson XP-4100 Utilities for Windows

File Name: EPFaxUtil_256.exe

File Size: 21.7 MB

License: Freeware

File Name: EEM_31121.exe

File Size: 17.0 MB

License: Freeware

File Name: ESU_451.exe

File Size: 5.56 MB

License: Freeware

File Name: ECPSU_1.41.exe

File Size: 3.99 MB

License: Freeware

Epson XP-4100 Utilities for Mac

File Name: EEM_25173.dmg

File Size: 29.1 MB

License: Freeware

Supported OS: macOS 10.15.x, macOS 10.14.x, macOS 10.13.x, macOS 10.12.x, Mac OS X 10.11.x, Mac OS X 10.10.x, Mac OS X 10.9.x, Mac OS X 10.8.x, Mac OS X 10.7.x, Mac OS X 10.6.x, Mac OS X 10.5.x

File Name: EPFaxUtil_190.dmg

File Size: 12,95 MB

License: Freeware

Supported OS: macOS 10.15.x, macOS 10.14.x, macOS 10.13.x, macOS 10.12.x, Mac OS X 10.11.x, Mac OS X 10.10.x, Mac OS X 10.9.x, Mac OS X 10.8.x, Mac OS X 10.7.x, Mac OS X 10.6.x, Mac OS X 10.5.x

File Name: ENCU_497.dmg

File Size: 14.9 MB

License: Freeware

Supported OS: macOS 10.15.x, macOS 10.14.x, macOS 10.13.x, macOS 10.12.x, Mac OS X 10.11.x, Mac OS X 10.10.x, Mac OS X 10.9.x, Mac OS X 10.8.x, Mac OS X 10.7.x, Mac OS X 10.6.x, Mac OS X 10.5.x

User Manual

File Name: cpd56913.pdf

File Size: 1,55 MB

File Name: cpd57811.pdf

File Size: 447,69 KB

Epson Xp 2100 Driver For Mac Download

File Name: cpd56917.pdf

File Size: 2,25 MB

File Name: cpd56916.pdf

File Size: 576,72 KB

Windows

Download / Installation Procedures

Click the link, select [ Save ], specify “Save As”, then click [ Save ] to download the file.

Memo :

If you select [ Run ] ( or [ Open ] ) instead of [ Save ], the file will be automatically installed after it is saved.

The downloaded file will be saved in the specified place in the self-extracting form ( .exe format ).

Double-click the downloaded EXE file to decompress it, then installation will start automatically.

Mac

Download / Installation Procedures

Download the file. For the location where the file is saved, check the computer settings.

Double-click the downloaded file and mount it on the Disk Image.

Double-click the mounted Disk Image.

Double-click the packaged file in the folder. Installation starts automatically.

Download Epson XP-4100

Epson XP-4100

5.0

Descriptions

Epson XP-2100 Driver, App, Scanner Software Download, Wireless Setup, Printer Install, Instructions Manual, Owners Guide, Troubleshooting for Windows 10, Mac, Linux – Epson XP-2100 Driver is the software that knows the specification and converts the Operating System instructions gives to the hardware commands. It is the most pivotal component in a computer that is responsible for creating a conjunction between the OS and the hardware components or the software programs. Do you now realize such an important role the driver software plays?

Therefore, the Epson XP-2100 driver update is essential for a smoother running of your printer, which needs to be installed on your laptop or PC to carry out your commands and adequately execute them. Then, You can explore and exploit all the features of your device. That’s why we are here to provide full support for your printer or scanner. On this page, We offer Epson XP-2100 Driver, scanner software, user manual, troubleshooting guide, and printer install by suitable wireless setup instructions. You can get it all for free with a single click on the download link below.

The control panel is easy to use. Buttons navigate the user interface. It is NOT a touch screen. The menu is simple and logical. If the screen is damaged, most functions can also be accessed from the desktop app. The panel can be laid flat or at an angle. Many promotional videos are misleading and make the board appear motorized and tilted when turned on. It’s false. The edge of the board is manually adjusted by hand. If the printer is placed high on a shelf, the flat position will allow you to see the screen below. If the printer is placed on a desk or lower rack, the angle will let you see the screen from above.

Most printers on the market today have an internal paper tray that curls the paper as it is fed. This Epson XP-2100 has an open rear plate that feeds the paper at any angle. This allows you to use wider paper types and sizes vary. Frequent paper jams occur when loading a single thick sheet. It seems best to work when the tray is loaded with multiple layers. The best feature of this printer is a hinged panel that covers the opening when the plate is not in use. This feature will prevent dust or dirt from falling into the printer and jamming it. The printer claims to have two-sided printing capabilities (automatic front and back printing).

Read also: Epson XP-2105 Software, Setup, Owners Manual PDF, App Download, Driver Install

However, I did not understand how to enable this feature. I suspect this might not be an option in the applications I use. Be careful when clearing Epson XP-2100 paper jams. Like the other inkjet printers, frequent use is essential. If you are not using the printer for a long time, the Epson XP-2100 ink heads will dry out and need to be cleaned. This will force you to waste a lot when you do maintenance. Fortunately, it has four separate ink cartridges. This feature reduces waste. All colors can be acquired separately. Magenta, Cyan, and Yellow can be acquired as a 3-pack for additional savings.

Compatibility of Epson XP-2100 Driver

Epson XP-2100 Driver is compatible with Windows 10 (64-bit / 32-bit), Windows 8.1 (64-bit / 32-bit), Windows 8 (64-bit / 32-bit), Windows 7 (64-bit / 32-bit), macOS 11.0 Big Sur, macOS 10.15 Catalina, macOS 10.14 Mojave, macOS 10.13 High Sierra, macOS 10.12 Sierra, OS X 10.11 El Capitan, OS X 10.10 Yosemite, Linux (64-bit), Linux (32-bit).

Epson XP-2100 Driver Install and Setup Instructions

Scan Epson Xp 2100

Download the required file in the download section.

Double-click the .exe, .dmg or .pkg file that downloaded.

Follow the Epson XP-2100 installation instructions or refer to the Epson XP-2100 User Manual.

The driver installation is not complete yet. Updating your printer and scanner software is also critical. Official device manufacturers mainly release the software and drivers. They keep updating them to ensure better compatibility with different operating systems and improve the performance of your printer or scanner. Sometimes the manufacturer updates the printer driver on average 3-4 times a year. By installing the Epson XP-2100 driver update, you will generally get better performance and new features on your devices.

Epson Xp 2100 Printer

Epson XP-2100 Wireless Setup

After installing the Epson XP-2100 Driver, maybe you want to connect it to your wifi router. Not all Epson printers have wireless performance, so make sure your printer can link to the Web before continuing. This Epson XP-2100 Wifi setup tutorial reveals how to connect Epson XP-2100 to a wireless network using the WPS method (Wifi Protected Setup). This process will permit you to print or scan from any device on the same networking without needing to link the printer to your computer system.

Unpack your printer and read the Epson XP-2100 printer install instructions in the user manual.

Plugin the power cord, turn on the printer, and install the Epson XP-2100 ink cartridges. Wait until the printer is doing the start-up process.

Your wireless router and printer need to sustain the WPS or Wifi Protected Setup pushbutton setting. Read both device owners’ manuals.

The wifi router has to have a WPS button.

Your network should utilize WPA2 or WPA security. Many WPS wireless routers will not connect when using the WPS technique if WEP is available.

Most WPS routers will not connect utilizing the WPS method if you use the manufacturer’s default setting for the Wifi name and without a password.

To connect your printer to the router using the WPS method, begin the WPS push button setting on your printer.

For troubleshooting on how to begin WPS on your printer, see your printer’s user guide.

Within 3 mins, press the WPS button on your router.

Epson XP-2100 Driver, Software Download & Manual

cdwdrivers.com is an independent remote technical support service provider for third-party products. We, with this, disclaim any affiliations, sponsorship, or endorsement by such a third party. Any use of third party trade names, brands, services, and products are for reference only. “printer.cdwdrivers.com” is not responsible for any third-party content provided on or through the Site, and you assume all threats related to the use of such third party content, products, and services. Our support staff is certified technicians, but they do not necessarily have third party certification unless expressly stated otherwise.

How to Download Epson XP-2100 Driver

There are 3 Methods on How to Download Epson XP-2100 Driver.

Method 1: Epson XP-2100 Driver Download using Driver Booster

Updating drivers is a cumbersome task, especially when you don’t know how to do that. Sometimes you may download the wrong driver, or an error may show up during the installation process. So if you need to update the driver, updating drivers automatically is a better choice.

Driver Booster is a popular drivers’ finder that can help you find the outdated, missing, or erroneous drivers, and then download the latest drivers for you. With this software, you can update graphics, audio, keyboard, printer, scanner, mouse drivers easily and fast.

1. Download, install, and run Driver Booster on your computer.

2. Click Scan. After that, Driver Booster will start scan all your devices including the Epson XP-2100 printer driver, and recommend the latest driver.

3. Find XP-2100 printer, and click Update to update this driver.

Here if there are other outdated or missing drivers that need to be updated, you can click Update Now to update all drivers.

Method 2: Update Epson XP-2100 Driver via Device Manager

Epson Xp 2100 Driver Mac Os

Some people also want to use the device manager to update their drivers. Device manager is Microsoft’s built-in hardware management tool. In addition to updating drivers, it can also be used to view the status, model, and other information of the hardware.

1. Open Device Manager.

2. Expand Print queues. Here are some printers, scanners, and virtual devices that are already connected to your computer.

3. Right-click Epson XP-2100 Printer and select Update driver.

4. Select the first option: Search automatically for updated driver software.

After that, Microsoft will search for the latest driver and install it automatically. What you should do is to wait for several seconds.

There is another thing you should know is that if the printer shows a yellow exclamation and if the driver installed failed, you can uninstall the driver at first and then reinstall it again.

Method 3: How to Download Epson XP-2100 Driver Download from Epson Official Website

Some people may choose to manually update their printer drivers. If the first method is not suitable for you, you can also choose this way. Although it will take up some time, this method is very effective. For downloading Epson XP-2100 printer drivers and setup files, you can follow the next steps.

1. Go to the Epson XP-2100 Drivers Download page. Here you can see driver downloads, manuals, and services.

2. Search your product.

3. In the operating system, it will show the detected system. You do not need to select by yourself. If you want to download the XP-2100 printer drivers for other systems or other computers, select Windows 7, 8, or other items.

Here you can see the Drivers and Utilities Combo Package, click the Download button on the right side.

4. After you downloaded the driver to your computer, double-click the setup file to install it step by step.

Epson Xp 2100 Driver Mac Catalina

Tips: If you encounter any problems while setting up or installing the Epson XP-2100 printer, you can visit the XP-2100 setup document page. This online page includes all instructions for you to use your XP-2100 products, such as how to install, how to connect, how to use cloud printing, and more.

Epson Xp 2100 Driver

Incoming search terms:

0 notes

shygladiatorcollection · 4 years ago

Text

Qbasic 64 Download For Mac

Qbasic 64 Windows 10

Qbasic 64 Manual

Qbasic 64 Download

Qbasic 64 Online

Qbasic Download

Chipmunk Basic for macOS - (Version 1.368.2118, 2019Aug31) Current release with a few bug fixes. Tested on macOS 10.13 thru 11.1. Please send bug reports. Beta Test Chipmunk Basic v1.368.2202. For Apple Silicon M1 Macs and macOS 11 (2020Nov) Chipmunk Basic for Mac OS X - (Version 1.367.2627, 2016Apr01). QBasic download for Windows QBasic is a high-level programming language for beginners. This Qbasic download for windows is the article to get the knowledge about download and install the Qbasic for different versions. Here, you will learn to download the Qbasic for windows 7, 10, and for 32 or 64-bit operating systems.

Get QB64 v1.4

QB64 is a modern extended BASIC programming language that retains QBasic/QuickBASIC 4.5 compatibility and compiles native binaries for Windows, Linux, and macOS. → Read more

SUPPORT THE PROJECT

ABOUT

From the 80s to eternity

How BASIC made its way into the 21st century

The BASIC language has been the gateway into programming for countless people. Popular as a beginner programming language in the 80’s and evolving into a powerful professional tool in 90’s, BASIC (and its successor QBasic), helped many people develop a love for programming. These languages provided the foundational learning platform for most of today’s professional developers.

Qbasic 64 Windows 10

The QB64 project has evolved over the last decade to bring the magic and educational potential of BASIC from its 20th century roots into the modern era. The QB64 project is already in use in both educational and professional contexts and has an active and helpful user community.

Unlike traditional BASIC and QBasic code, QB64 gets compiled automatically into machine code – allowing exceptional performance, easy distribution, and the ability to link with external C and C++ programming libaries. Compatible with most QBasic 4.5 code, QB64 adds a number of extensions, such as OpenGL and other modern features, providing the perfect blend of classic and modern program development.

QB64 is available for all recent Windows, Linux, and macOS versions.

DOWNLOAD

You can either get the stable build or help us beta test the development build.

vWATCH

The debugging features you loved using in QuickBASIC are now available to help you squash those hard-to-find bugs in your projects. Made with QB64.

InForm

Qbasic 64 Manual

Design feature-rich graphical interfaces that blend in perfectly with today’s Operating Systems all without leaving BASIC behind. Made with QB64.

UTILITIES

It’s all about sharing

BASBin

Need to share a code snippet but don’t need all the fuss of traditional online tools? BASBin is what you’re after. Just paste code, hit the button, and share the link away. Files are wiped regularly, so treat it as the temporary storage it is, OK?

Qbasic 64 Download

BINBin

Qbasic 64 Online

Or maybe you need to share an image, or other type of binary file. If that’s the case, BINBin is for you. Select the file to share, hit the button, and share the link. Files are wiped regularly, so treat it as the temporary storage it is, OK?

Qbasic Download

Icons by Freepik, monkik and Pixel perfect from www.flaticon.com and by Custom Icon Design from www.iconarchive.com

0 notes

shygladiatorcollection · 4 years ago

Text

Mass Gmail Account Creator Full Crack

Mass Gmail Account Creator 2.2.5 Crack

Mass Gmail Account Creator 2.1.77 Cracked By Omega

Mass Gmail Account Creator Full Crack Download

My Gmail Account Is Full

Crack Nets - the complete catalog. Guitar Pro Full 5.0 serial number maker. Gmail Mass Account Creator patch. Dec 20, 2019 Hacking Gmail or Google is the second most searched account hacking topic on the internet next to hacking Facebook account. Python script for Hack gmail account brute force. Com” to find the Gmail address. When you need to brute force crack a remote authentication service, Hydra is often the tool of choice.

PVA CREATOR 2.5.7 DELUXE Cracked – Best PVA Account Creator – Gmail – Instagram – Twitter & more! Free Download Crack

PVA CREATOR 2.57 DELUXE Crack – Best PVA Account Creator – Gmail – Instagram – Twitter – Reddit – Facebook – Pinterest – Tumblr – YouTube – Outlook – Hotmail – Soundcloud – Slickdeals – Amazon – LinkedIn & more!

Create Phone Verified Accounts Automatically. PVA Creator crack can get phone numbers and receive sms to verify your accounts automatically.

Confirm Email Automatically.When some sites need email confirmation, PVACreator can do this for you automatically too Captcha Auto-Solving and Proxy Support.PVACreator can solve captcha automatically when register accounts, and you can import proxies to use in PVA Creator for creating many accounts.

Mass Gmail Account Creator 2.2.5 Crack

Mass Gmail Account Creator 2.1.77 Cracked By Omega

Multi-Threads SupportYou can set PVACreator to run with multi-threads to speed up the registration and create accounts for different sites at the same time.

What can PVA CREATOR do for youPVACreator is a super accounts bulk creating machine that can creating phone and email verified accounts for different sites. It can also solve captcha automatically and allow you to import proxies to register accounts.

Smart Task ManagerPVACreator allows you to create/manage/run/pause/resume multi-accounts creating tasks at the same time. Every task has full stats of account creating, you can manage and check everything easily. Auto/Custom Data SettingsPVACreator can create randomly datas like first name, last name, sex and age etc… to create your accounts, you can also import yourself data to create your accounts.

Customized Save SettingsYou can custom the register information to save, like you can only save username and password, or you can also set to save username, password, register proxy, register phone number, first name, last name and others. All information can be saved with created accounts if you want. Captcha Auto-Solving and Proxy Support.

PVACreator cracked can solve captcha automatically when register accounts, and you can import proxies to use in PVACreator for creating many accounts. Phone Verify AutomaticallyPVACreator can get phone numbers and receive sms to verify your accounts automatically. Auto-Confirm EmailWhen some sites need email confirmation, PVACreator can do this for you automatically too.

Multi-Threads SupportYou can set PVACreator to run with multi-threads to speed up the registration and create accounts for different sites at the same time.

Deluxe Version Contains all current sites and future sites in update.

$550$918 one time fee

Instagram VersionOnly for Instagram

Mass Gmail Account Creator Full Crack Download

$67$113 one time fee

Youtube VersionOnly for YouTube

$67$113 one time fee

Gmail VersionOnly for Gmail

$67$113 one time fee

Twitter VersionOnly for Twitter

$67$113 one time fee

Outlook VersionOnly for Outlook

$67$113 one time fee

LinkedIn VersionOnly for LinkedIn

$67$113 one time fee

Facebook VersionOnly for Facebook

$47$79 one time fee

Pinterest VersionOnly for Pinterest

$47$79 one time fee

Reddit VersionOnly for Reddit

$47$79 one time fee

SoundCloud VersionOnly for SoundCloud

$47$79 one time fee

sd Slickdeals VersionOnly for Slickdeals

$47$79 one time fee

Amazon VersionOnly for Amazon

$33$56 one time fee

My Gmail Account Is Full

This took a lot of time to get it cracked(very hard), it all loads up and everything appears to work, all functions are not tested! Please let people know if its working or if there’s any issues i’ll correct it.

Global Review

Facebook Automation Full

Trial Version

Unlimited version

Description

Easy to fetch your groups list, friends list, pages ...

Schedule your posts to anywhere (groups, public pages, friend wall, private message, comment).

Schedule bumping your posts in groups or specify posts ids.

Schedule joining to groups.

Settings time interval while posting, joining to groups, friend request sending ... Prevent spam detection from facebook.

Searching for groups by keyword, checking for status (joined, un-join, privacy open-close-secret group, members count, notify ...).

Easy to filter groups list. Join to any groups that you want. Leave bad groups (no more members, do not allow to post ...) by one click. Turn on/off notify from groups which you want.

Mass invite friends to group. Mass invite users via email to group

Post a message, single photo or multi-photos to groups which you chosed. You can also post your photo album to groups.

Tag specify friends to a post or random tag friends to a post.

Post a message, single photo or multi-photos to your wall or friend wall.

Post a mass private message to users which you chosed.

RANDOM/SPIN your message, link, images, photo ... while posting for prevent spam detection by facebook.

Sharing a your photo album/post to groups/pages/users ...

Searching for users by keyword, automatic sending friend request to users which you chosed. Get friend requests, accept or deny requests.

Convert users id to facebook emails.

Searching for pages by keyword, checking for details of these pages (likes count, can post, website, email, phone, country ...). Mass invite friend like the page. More filter options for you.

Export emails, phone, website from public pages.

Post a message, single photo, private message to public pages which you chosed.

If you want to buy it , contact me via skype : [email protected] or ICQ : 700589020

0 notes

shygladiatorcollection · 4 years ago

Text

Lewis Dot Structure Calculator Wolfram

Sometimes it's difficult to tell which of two possible Lewis structures of a compound represents the actual bonding of the molecule. In those cases we resort to calculating what's called the formal charge of each atom. Formal charge is just a way of bookkeeping that helps us to decide which of multiple Lewis structures is the likely true bonding arrangement of a covalent molecule. The sum of the formal charges, with a couple of extra rules, will help us to decide which of multiple-possible valid Lewis structures is likely to be the correct one. Here's how it's done.

Lewis Dot Structure Calculator Wolfram Equation

Free Lewis Dot Structure Calculator

Lewis Dot Structure Calculator Wolfram Calculator

Calculating formal charge

For each atom

Lewis Dot Structure Calculator Wolfram Equation

A step-by-step explanation of how to draw the CaF2 Lewis Dot Structure.For CaF2 we have an ionic compound and we need to take that into account when we draw. A step-by-step explanation of how to draw the CaF2 Lewis Dot Structure.For CaF2 we have an ionic compound and we need to take that into account when we draw. Lewis structure calculator, This page lets you easily convert IUPAC names, common names, SMILES codes, CAS numbers, and other identifiers into chemical structures. On the back end it employs OpenChemLib to decode SMILES codes, the OPSIN library developed by Daniel Lowe, data from PubChem, various drug and natural product dictionaries, and openmolecules software. 3D structure images are random.

Count the number of valence electrons of the neutral atom.

Subtract the number of non-bonding electrons (usually in lone pairs).

Subtract the number of bonds shared by the atom.

Example: CH4 (methane)

The carbon in CH4 has four electrons as a neutral atom. It has no lone pairs, and it shares four bonds, so the formal charge is zero. Each hydrogen atom has one electron as a neutral atom, no lone pairs and shares one bond, for a formal charge of zero. All atoms in the molecule have zero formal charge, the 'happiest' situation for any molecule.

Free Lewis Dot Structure Calculator

Example: H3C(CO)CH3, (acetone)

Lewis Dot Structure Calculator Wolfram Calculator

The central carbon has a formal charge of 4 (valence electrons) - 0 (lone pairs) - 4 (bonds) = 0. The oxygen has a formal charge of 6 - 4 - 2 = 0 (same ordering of terms). Each of the methyl (CH3) carbons has a formal charge of 4 - 0 - 4 = 0

0 notes

shygladiatorcollection · 4 years ago

Text

Free Software To Open Pcb File

Printed Circuit Boards are very crucial in Electronics circuit design and making, these PCB boards are acts as support base for the Electronic Elements & components and provides bias and signal path to the required components. Now a days growth of SMD (Surface Mount Device) and SMT (Surface Mount Technology) shrinks the electronic components size and makes more complex to the PCB design. Due to no pin hole terminals in SMD components two side of PCB board filled up with tracks and components.

Typically, free EDA software is poorly developed, or has restrictions on design size that render it useless for any real project. Not CircuitMaker - you get the full power of 16 signal + 16 plane layers, and no restrictions to the PCB dimensions. If you do not need dark current compensation you can remove the second photodiode and leave the pads open. The software reads the data using a clock which is driven by the ADC. The clock frequency is the same as the sampling rate (20MSPS). How to open PCB files. If you cannot open the PCB file on your computer - there may be several reasons. The first and most important reason (the most common) is the lack of a suitable software that supports PCB among those that are installed on your device. A very simple way to solve this problem is to find and download the appropriate application.

The Printed Circuit Board have copper tracks to connect the electronic components placed upon it, Different types of PCBs are,

Single Sided PCBs

Double Sided PCBs

Multilayer PCBs

Rigid PCBs

Flex PCBs

Rigid-Flex PCBs

In order to produce compact, quality perfect printed circuit board we need good PCB design software, this Article may help you to find most leading and competitive 10+ free PCB design software.

eSim

Kicad

gEDA

Free PCB

Osmond PCB

ExpressPCB

PCBWeb Designer

DesignSpark PCB

Fritzing

Eagle

ZenitPCB

eSim

eSim (previously known as Oscad / FreeEDA) is an open source EDA tool for circuit design, simulation, analysis and PCB design. eSim offers similar capabilities and ease of use as any equivalent proprietary software for schematic creation, simulation and PCB design, without having to pay a huge amount of money to procure licenses. This software runs on Ubuntu Linux and Windows and it is released under GPL (eSim Software).

Kicad

Kicad EDA is a cross platform and open source electronics Design Automation suite. It enables support for every aspects in electronics design such as, Schematic capture, PCB layout and 3D Viewer,it allow you to modify the aesthetic appearance of the board or to hide and show features for easier inspection (Kicad software).

gEDA

PCB design software from gEDA is a cross platform software, and has rats nest features, schematic/netlist import, design rule checking and provide Industry standard RS-274X (Gerber), photorealistic design review images and lot more..(gEDA PCB software).

Free PCB

FreePCB is a free, open-source PCB editor for Microsoft Windows, released under the GNU General Public License. It was designed to be easy to learn and easy to use, yet capable of professional-quality work.

1 to 16 copper layers

Board size up to 60 inches by 60 inches

Imports and exports PADS-PCB netlists

Exports extended Gerber files (RS274X) and Excellon drill files

Design rule checker

Autosave

These are notable features built in Freepcb PCB design software. (freepcb Software)

Osmond PCB

Osmond PCB provides free software for small designs, it has multiple layer design option, we can design thru-hole and surface mount based PCBs. It has Design rule checking features and produce industrial standard boards output (Osmond PCB Software).

ExpressPCB

ExpressPCB software is a user friendly easy to use PCB design software, First time PCB designer can easily operate this software without any struggle and it provides well explained documentation & steps on how to make printed circuit board (ExpressPCB software).

PCBWeb Designer

PCBweb is a free CAD application to designing and manufacturing electronics hardware, It provides full service design and manufacturing features, we can do schematic capture fast using easy to use writing tool, we can create multi-layer boards and it has integrated Arrow part library (PCBweb designer)

DesignSpark PCB

DesignSpark PCB software from RS components and Allied Electronics makes it easy to design complex PCBs and this software works with minimum configuration systems, It has huge library collections and good support by forum and video tutorials (DesignSpark PCB).

Fritzing

Fritzing is an open-source hardware initiative that makes electronics accessible as a creative material for anyone. We offer a software tool, a community website and services in the spirit of Processing and Arduino, fostering a creative ecosystem that allows users to document their prototypes, share them with others, teachelectronics in a classroom, and layout and manufacture professional pcbs… from its website (Fritzing software).

Eagle

Autodesk eagle PCB design software is powerful and easy to use tools for every engineer, and it is offered in free version and also paid version , it has easy to use schematic editor, powerful pcb layout and ready to use part libraries and this software most suitable for complex pcb designs (eagle software).

ZenitPCB

Zenit PCB software is a excellent tool to create professional printed circuit board, and it is easy to use CAD proram, ZenitPCB Suite is directed to all those people who want to make printed circuit board for hobby, or to student and academics from universities or high schools, who want to create their own pcb with a professional approach and particularly without having to pay for expensive licenses, from its website (ZenitPCB software).

Note: This Article is just to show you the software options for PCB designing and there is no compulsion or promoting of any software and Images used here are for the education purpose only, Image credit to the respective owners.

ProntoCAD-CONNECT is the importer engine featured in all Unisoft software modules and allows the importing of virtually any CAD, Gerber, Bill of Materials (BOM), CNC and mechanical drawing formats.

VIDEO: Click the video above for product overview.

BOM IMPORTING

SOFTWARE DOWNLOAD: A quick way to learn about the software is to download it by clicking this link.

The software has HELP for most menu items by hovering over the menu item for a second then click any of the videos, manual or website links to learn about the software. For example the SMART OPEN menu has help on importing CAD and Gerber files.

Free PCB CAD Viewer & Gerber Viewer Software

The software download link and periodic updates will be sent to this address. Please double check that your email address is correct. Your email address will be kept private.

Importing Your CAD Files

Importing your CAD files is easy with the Unisoft software! The 'SMART OPEN' feature is your CAD EXPERT that does all the work for you finding and sorting out all the proper files in your project folder!

TO USE 'SMART OPEN': From the Unisoft software click FILE from the main menu, click SMART OPEN and a new window opens. In the new window browse to and select the directory that your project CAD or Gerber files are located in. A new window opens and select one of the files presented and your PC Board will be displayed.

The SMART OPEN feature looks at all the files for your project in the folder you select and then presents you with only the correct PC Board, CAD and Gerber files that can be imported into the Unisoft software with the most desirable CAD files at the top of the list.

MORE ABOUT CAD FILE IMPORTING:

The Unisoft software can import the wide assortment of CAD, Gerber, BOM and XY rotation files that EMS/CEM and OEM electronic manufactures encounter. Unisoft has a set of the best ECAD, Gerber and BOM importers in the world today. This software developed over the last 30 years imports all types of ECAD, MCAD and BOM formats.

Unisoft imports the ASCII text files created by CAD systems and supports revision levels dating back to the 1980's and this can be important because older versions of CAD systems are still in use and need to be supported. For example the PADS ASCII output .ASC file format dates back to the 1980's and Unisoft supports virtually all the variations PADS created through the years within that format.

Unisoft SMART OPEN feature outlined previously above, will scan all files in a folder and will automatically detect the CAD files which have correct content for importing into the Unisoft software. So for example if you have a folder containing 40 assorted CAD, Gerber, BOM and Drawing files for a PC Board project use the Unisoft SMART OPEN feature by clicking FILE from the main menu then click SMART OPEN and point to the directory folder with the files and click OK and you will be presented with a list of the CAD files you can import. In general look for at a minimum 'PCB pin x-y' in the field 'Contains this type of data'. If the file contains 'PCB pin x-y' data then usually with the Unisoft software this will be sufficient data to program your Assembly, AOI inspection and selective Soldering equipment; and also create process assembly sheets, kitting labels, costing reports, do first article and general inspection.

If you are having trouble finding the right type of CAD file to import into the Unisoft software then the table below lists PC Board CAD, Gerber and mechanical CAD file formats that maybe imported into the Unisoft software. You can use this table to match up the correct CAD file required to be imported. After you have installed the Unisoft software full samples of most of the CAD formats listed in the table below can be found by default in the directory c:program filesunisoftcad-import-file-samples-etc or c:program files(x86)unisoftcad-import-file-samples-etc . In that directory the sample files start with SAMPLE_ and the CAD System is in the name of the file, for example the file SAMPLE_PADS.ASC is a full sample of the PADS CAD system ASCII file. If you are having trouble finding the right type of CAD file then use these samples to match them to the CAD files your CAD department or your clients may have available for processing with the Unisoft software. For example if your company or client uses the OrCAD CAD system to design their PC Boards and they have not sent you the correct files then use the table below to have them send you the desired files. From the table below under the field 'CAD system' look for OrCAD and you will find two listings. Next under the field 'File label or type' you will find 'Min File' and 'GENCAD'. Under the field 'Contains this type of data' you will find that both have the same listing of 'PCB pin x-y,netlist,trace data'. The field 'Contains this type of data' indicates the PC Board data types contained in the file and usually the more types listed the better. In the case of OrCAD both the 'Min File' and 'GENCAD' files have full 'Contains this type of data' listings of 'PCB pin x-y,netlist,trace data' and either one will work fine for importing into the Unisoft software. Next look at the field 'Standard extension' and in the case of OrCAD they are .MIN and .CAD and if you have either of these files available you are ready to go; if not then request them from your client or your CAD department and do this by forwarding them the samples of the file formats you need and these samples are available by default in the directory c:program filesunisoftcad-import-file-samples-etc or c:program files(x86)unisoftcad-import-file-samples-etc . In the case of OrCAD the two files you would send them would be sample_orcad.min and sample_GENCAD.cad and these files should aid them in matching the correct file type you need.

STANDARD CAD FILES: Note that many CAD systems in addition to exporting their native format may export industry standard CAD formats such as GENCAD, GENCAM, FABMASTER, IPC-D-356, IPC-2581, etc. In most cases these files can be used in place of the native CAD files and are importable into the Unisoft software.

GERBER FILES: When CAD files are not available then Gerber files are often the only files available to Contract Manufacturers and OEM's. The Unisoft software can quickly translate these files into your required manufacturing files (see note 2 below).

X/Y CENTER & ROTATION FILES: When CAD files are not available then X/Y center & rotation files are often the only files available to Contract Manufacturers and OEM's. The Unisoft software can quickly translate these files into your required manufacturing files (see note 7 below).

CAD & Gerber File Listings

The information below helps to find the best data files for importing to the Unisoft software. We are available anytime to assist you directly online.

CAD system or standards fileFile label or typeStandard extensionContains this type of data / rotation typeSampleAccel P-CAD (see note 12)PDIF.pdf (see note 12)PCB pin x-y,netlist,trace (see note 12 / 1a)yAccel P-CAD (see note 18)IPC-D-356.ipc/.356/varies (see note 18)PCB pin x-y,netlist (see note 18 / 1a)yAccel P-CAD (see note 13)ASCII output.PCB (see note 13)PCB pin x-y,netlist,trace (see note 13 / 1a)yAccel P-CAD (see note 2) Altium Designer(see note 5)Gerber Protel outputvaries (see note 2) .pro (see note 5)PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist,trace (see note 5 / 1a)y yAltium Designer (see note 21) Altium Designer (see note 22) Altium Designer (see note 5)ODB++ IPC-2581 pin x-y listvaries .cvg .PCB (see note 5)PCB pin x-y,netlist,trace (see note 21 / 1b) PCB pin x-y,netlist,trace (see note 22 / 1b) PCB pin x-y,netlist,trace (see note 5 / 1a)y y yAltium Designer (see note 5) Altium Designer (see note 2)Data Gerber.PCBdoc (see note 5) varies (see note 2)PCB pin x-y,netlist,trace (see note 5 / 1a) PCB drawing file (see note 2 / 1a)n yAutoCAD (see note 20 below)Design Exchange.dxf (see note 20)drawing file (see note 20)yAutodesk Eagle (see Eagle PCB) AutoCAD Electrical (see note 31) AutoTRAX DEX (see note 19) AutoTRAX DEX (see note 2) Bartels Auto Engineer(note 18)(see Eagle PCB) x-y centroid (see note 19) Gerber IPC-D-356(see Eagle PCB) varies (see note 31) (see note 19) varies (see note 2) .ipc/.356/varies (see note 18)(see Eagle PCB) PCB x-y center (see note 31) (see note 19) PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist (see note 18 / 1a)- y n y yBartels Auto Engineer GENCAD.cadPCB pin x-y,netlist,trace (see note 1b)y Bartels Auto Engineer (note 2) Cadence-Valid Allegro(note 3)Gerber pin x-y listvaries (see note 2) varies (see note 3)PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist,trace (see note 3 / 1b)y yCadence-Valid Allegro (note 3) Cadence-Valid Allegro (note 2)IPC-D-356 Gerber.ipc/.356 (see note 3) varies (see note 2)PCB pin x-y,netlist (see note 3 / 1a) PCB drawing file (see note 2 / 1a)y yCADint CADint (note 18) CADint (see note 26) CADint (note 2) CADSTAR (see note 17 below)GENCAD IPC-D-356 pin x-y list Gerber CADIF.cad .ipc/.356/varies (see note 18) .fat/.fatf - FATF file (note 26) varies (see note 2) .paf (see note 17)PCB pin x-y,netlist,trace (see note 1b) PCB pin x-y,netlist (see note 18 / 1a) PCB pin x-y,netlist,trace (see note 26 / 1b) PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist,trace (see note 1a)y y y y yCADSTAR CADSTAR (see note 2)pin x-y list Gerber.cdi varies (see note 2)PCB pin x-y,netlist,trace (see note 1a) PCB drawing file (see note 2 / 1a)y yCIRCADGENCAD.cadPCB pin x-y,netlist,trace (see note 1b)yCIRCAD (see note 4 below) CIRCAD (see note 2)IPC-D-356 Gerber.ipc/.356 (see note 4) varies (see note 2)PCB pin x-y,netlist (see note 4 / 1a) PCB drawing file (see note 2 / 1a)y yComputerVision ComputerVision (see note 2)pin x-y list Gerber.cvi varies (see note 2)PCB pin x-y,netlist,trace PCB drawing file (see note 2 / 1a)n yCopper Connection (see note 2) CR5000 (see note 17 below) CR5000 (see note 6 below) CR5000 (see note 2) CR8000 (see note 17 below) CR8000 (see note 6 below) CR8000 (see note 2) DesignSpark (see note 27) DesignSpark (see note 2) Diptrace Diptrace Diptrace Diptrace Diptrace Diptrace (see note 7) Diptrace (see note 2) Douglas CAD/CAM Pro(note 7) Douglas CAD/CAM Pro (note 2) Draftview(see note 23 below) Draftware(see note 23 below) Eagle PCB(see note 4 below)Gerber CADIF ODB++ Gerber CADIF ODB++ Gerber ODB++ Gerber IPC-D-356 ODB++ PADS type ASCII PCAD PCB Min OrCAD file x-y centroid Gerber x-y centroid Gerber drawing file drawing file IPC-D-356varies (see note 2) .paf (see note 17) varies (see note 6) varies (see note 2) .paf (see note 17) varies (see note 6) varies (see note 2) varies (see note 27) varies (see note 2) .ipc/.356 varies (see note 6) .asc .pcb .min varies (see note 7) varies (see note 2) varies (see note 7) varies (see note 2) varies (see note 23) varies (see note 23) .ipc/.356 (see note 4)PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist,trace (see note 17 / 1a) PCB pin x-y,netlist,trace (see note 6 / 1b) PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist,trace (see note 17 / 1a) PCB pin x-y,netlist,trace (see note 6 / 1b) PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist,trace (see note 6 / 1b) PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist,trace (see note 6 / 1b) PCB pin x-y,netlist,trace PCB pin x-y,netlist,trace (see note 1a) PCB pin x-y,netlist,trace PCB pin x-y,netlist,trace (see note 1a) PCB x-y center (see note 7) PCB drawing file (see note 2 / 1a) PCB x-y center (see note 7) PCB drawing file (see note 2 / 1a) drawing file drawing file PCB pin x-y,netlist (see note 4 / 1a)y y y y y y y y y y y y y y y y y y y y yEagle PCB (see note 4 below)GENCAD.cad (see note 4)PCB pin x-y,netlist,trace (see note 4 / 1b)yEagle PCB (see note 4 below)pin x-y list.fatf - FATF file (see note 4)PCB pin x-y,netlist,trace (see note 4 / 1b)yEagle PCB (see note 4 below) Eagle PCB (see note 2) Easy-PC(see note 8 below) Easy-PC (see note 32 below) Easy-PC (see note 2)other Gerber GENCAD ODB++ Gerberscripts (see note 4) varies (see note 2) cad (see note 8) varies (see note 32) varies (see note 2)PCB exports using scripts (see note 4) PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist,trace (see note 21 / 1b) PCB pin x-y,netlist,trace (see note 32 / 1b) PCB drawing file (see note 2 / 1a)y y y y yEasyEDA EasyEDA EasyEDA EasyEDA EE Designer EE Designer (see note 2)PADS-PCB Protel output x-y centroid Gerber ASCII output Gerber.asc .pro varies (see note 7) varies (see note 2) .ala varies (see note 2)PCB pin x-y,netlist,trace (see note 1a) PCB pin x-y,netlist,trace (see note 1a) PCB x-y center (see note 7) PCB drawing file (see note 2 / 1a) PCB Ascii PCB drawing file (see note 2 / 1a)y y y y n yFabmaster (see note 26)pin x-y list.fatf - FATF file (note 26)PCB pin x-y,netlist,trace (see note 26 / 1b)yFabmaster Fabmaster (see note 2)pin x-y list Gerbervaries varies (see note 2)PCB pin x-y,netlist,trace (see note 1b) PCB drawing file (see note 2 / 1a)y yFastCAD (see note 2 below)Gerbervaries (see note 2)PCB drawing file (see note 2 / 1a)yFreePCB (see note 2 below) FreePCB Fuji PCB assembly file GENA PxxxPCB(see note 7 below) GENA PxxxPCB (see note 2)Gerber PADS-PCB Flexa .pgo x-y centroid Gerbervaries (see note 2) .asc .pgo varies (see note 7) varies (see note 2)PCB drawing file (see note 2 / 1a) PCB netlist (pin x-y?, trace?) PCB x-y center PCB x-y center (see note 7) PCB drawing file (see note 2 / 1a)y y y y yGENCADGENCAD.cadPCB pin x-y,netlist,trace (see note 1b)yGENCAMGENCAM.gcmPCB pin x-y,netlist,traceyGerber (see note 2 below)Gerbervaries (see note 2)PCB drawing file (see note 2 / 1a)yHPGL (see note 23 below)Internet.hpgdrawing fileyIncases Incases (see note 2)TL CAD Gerber.tl varies (see note 2)PCB Ascii PCB drawing file (see note 2 / 1a)n yIntergraph Intergraph (see note 2) pin x-y list Gerber.lst varies (see note 2)PCB pin x-y,netlist,trace PCB drawing file (see note 2 / 1a)y yIPC-2581 (see note 24) IPC-2581A(xml) (see note 25) IPC-D-356(see note 18)IPC-2581 IPC-2581A IPC-D-356.cvg (see note 24) .xml (see note 25) varies (see note 18)PCB pin x-y,netlist,trace (see note 24 / 1b) PCB pin x-y,netlist,trace (see note 25 / 1b) PCB pin x-y,netlist (see note 18 / 1a)y y yKeysight ADS (see note 7) Keysight ADS (see note 2) KiCAD KiCAD (see note 7) KiCAD (see note 2) x-y centroid Gerber GENCAD x-y centroid Gerbervaries (see note 7) varies (see note 2) cad varies (see note 7) varies (see note 2)PCB x-y center (see note 7) PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist,trace (see note 1b) PCB x-y center (see note 7) PCB drawing file (see note 2 / 1a)y y y y yMcCADIPC-D-356.ipc/.356PCB pin x-y,netlist (see note 1a)yMcCADGENCAD.cadPCB pin x-y,netlist,trace (see note 1b)yMcCAD McCAD (see note 2) pin x-y list Gerber.tbs varies (see note 2)PCB pin x-y,netlist,trace PCB drawing file (see note 2 / 1a)n yMentorBoardStation (see note 29)Mentor Neutral pin x-y.neu/variesPCB pin x-y,netlist (see note 1a)yMentorBoardStationMentor Route (traces).txt/variesPCB traceyMentorBoardStation (note 6) MentorBoardStaion (note 2)ODB++ Gerbervaries (see note 6) varies (see note 2)PCB pin x-y,netlist,trace (see note 6 / 1b) PCB drawing file (see note 2 / 1a)y yMentor Expedition (see note 9)GENCAD.cad (see note 9)PCB pin x-y,netlist,trace (see note 9 / 1b)yMentor Expedition (see note 9)IPC-D-356.ipc/.356 (see note 9)PCB pin x-y,netlist (see note 9 / 1a)yMentor Expedition (notes 6, 9) Mentor Expedition (see note 2)ODB++ Gerbervaries (see notes 6, 9) varies (see note 2)PCB pin x-y,netlist,trace (notes 6, 9 / 1b) PCB drawing file (see note 2 / 1a)y yODB++ (see note 6 below)pin x-y listvaries (see note 6)PCB pin x-y,netlist,trace (see note 6 / 1b)yOrCAD PCB Designer (note 30) OrCAD PCB Designer (note 6) OrCAD PCB Designer (note 28) OrCAD PCB Designer (note 2) OrCAD MasstekGENCAD ODB++ IPC-2581 Gerber Min file.cad varies (see note 6) .cvg varies (see note 2) .minPCB pin x-y,netlist,trace (see note 1b) PCB pin x-y,netlist,trace (see note 6 / 1b) PCB pin x-y,netlist,trace (see note 22 / 1b) PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist,trace (see note 1a)y y y y yOrCAD Masstek OrCAD Masstek (note 18) OrCAD Masstek (see note 2) GENCAD IPC-D-356 Gerber.cad .ipc/.356/varies (see note 18) varies (see note 2)PCB pin x-y,netlist,trace (see note 1b) PCB pin x-y,netlist (see note 18 / 1a) PCB drawing file (see note 2 / 1a)y y y OrCAD 386+ (see note 7) OrCAD 386+ (see note 2)x-y centroid Gerbervaries (see note 7) varies (see note 2)PCB x-y center (see note 7) PCB drawing file (see note 2 / 1a)y yPADS (see note 11 below)ASCII output.asc (see note 11)PCB pin x-y,netlist,trace (see note 11 / 1a)yPADS (see note 6 below) PADS (see note 2)ODB++ Gerbervaries (see note 6) varies (see note 2)PCB pin x-y,netlist,trace (see note 6 / 1b) PCB drawing file (see note 2 / 1a)y yPanasonic PCB assembly file Pantheon/Intercept Pantheon/Intercept (note 2) Pantheon/Intercept (note 18) Pantheon/Intercept Pantheon/Intercept (note 6) Pantheon/Intercept P-CAD(see note 12 below)Panasonic .crb GENCAD Gerber IPC-D-356 Mentor ODB++ Visual PDIF.crb .cad varies (see note 2) .ipc/.356/varies (see note 18) .neu varies (see note 6) varies .pdf (see note 12)PCB x-y center PCB pin x-y,netlist,trace (see note 1b) PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist (see note 18 / 1a) PCB pin x-y,netlist (see note 1a) PCB pin x-y,netlist,trace (see note 6 / 1b) PCB pin x-y,netlist,trace PCB pin x-y,netlist,trace (see note 12 / 1a)n y y y y y y yP-CAD (see note 18 below)IPC-D-356.ipc/.356/varies (see note 18)PCB pin x-y,netlist (see note 18 / 1a)yP-CAD (see note 13 below) P-CAD (see note 2)ASCII output Gerber.PCB (see note 13) varies (see note 2)PCB pin x-y,netlist,trace (see note 13 / 1a) PCB drawing file (see note 2 / 1a)y yPulsonix Pulsonix (note 33) Pulsonix (see note 2)GENCAD ODB++ Gerber.cad varies (see note 33) varies (see note 2)PCB pin x-y,netlist,trace (see note 1b) PCB pin x-y,netlist,trace (see note 33 / 1b) PCB drawing file (see note 2 / 1a)y y yProtel (see note 14 below)Protel output.PCB/.pro (see note 14)PCB pin x-y,netlist,trace (see note 14 / 1a)yProtel (see note 18 below) Protel (see note 2)Protel output Gerber.ipc/.356/varies (see note 18) varies (see note 2)PCB pin x-y,netlist (see note 18 / 1a) PCB drawing file (see note 2 / 1a)y yProteus (see note 6 below) Proteus (see note 2) SCI Card SCI Card (see note 2)ODB++ Gerber Neutral file Gerbervaries (see note 6) varies (see note 2) .cii varies (see note 2)PCB pin x-y,netlist,trace (see note 6 / 1b) PCB drawing file (see note 2 / 1a) PCB Ascii (see note 1a) PCB drawing file (see note 2 / 1a)y y n ySeetrax Ranger Seetrax Ranger (see note 2)GENCAD Gerber.cad varies (see note 2)PCB pin x-y,netlist,trace (see note 1b) PCB drawing file (see note 2 / 1a)y ySuperMax ECAD (see note 18) SuperMax ECAD (see note 2)IPC-D-356 Netlist Gerber.ipc/.356/varies (see note 18) varies (see note 2)PCB pin x-y,netlist (see note 18 / 1a) PCB drawing file (see note 2 / 1a)y yTango (Protel) (see note 15) Tango (Protel) (see note 2)pin x-y list Gerber.PCB (see note 15) varies (see note 2)PCB pin x-y,netlist,trace (see note 15 / 1a) PCB drawing file (see note 2 / 1a)y yTheda Theda (see note 2)TL Gerber.tl varies (see note 2)PCB pin x-y,netlist PCB drawing file (see note 2 / 1a)n yULTIboard (see note 16 below)GENCAD.cad (see note 16)PCB pin x-y,netlist,trace (see note 16 / 1b)yULTIboard (see note 18 below) ULTIboard (see note 2)IPC-D-356 Netlist Gerber.ipc/.356/varies (see note 18) varies (see note 2)PCB pin x-y,netlist (see note 18 / 1a) PCB drawing file (see note 2 / 1a)y yVeribestpin x-y list.vrbPCB pin x-y,netlistyVeribest (see note 10 below) Veribest (see note 2) Valor (see note 6 below)GENCAD Gerber ODB++.cad (see note 10) varies (see note 2) varies (see note 6)PCB pin x-y,netlist,trace (see note 10 / 1b) PCB drawing file (see note 2 / 1a) PCB pin x-y,netlist,trace (see note 6 / 1b)y y yVisula (see note 17 below) Visula (see note 2)CADIF Gerber.paf (see note 17) varies (see note 2)PCB pin x-y,netlist,trace (see note 17 / 1a) PCB drawing file (see note 2 / 1a)y yVutrax (see note 2) X-Y Component Center (note 7)Gerber X-Y centersvaries (see note 2) .xyr (see note 7)PCB drawing file (see note 2 / 1a) PCB X-Y Components centers (see note 7)y yZuken (see note 17 below) Zuken(see note 6 below) Zuken (see note 2)CADIF ODB++ Gerber.paf (see note 17) varies (see note 6) varies (see note 2)PCB pin x-y,netlist,trace (see note 17 / 1a) PCB pin x-y,netlist,trace (see note 6 / 1b) PCB drawing file (see note 2 / 1a)y y y

The CAD and Gerber file listings above are provided for informational purposes only. Unisoft is not responsible for any problems encountered with the usage of this information.

Full samples of most of the CAD formats in the table above can be downloaded by clicking this link https://www.unisoft-cim.com/download/cad_samples.zip. After the download is complete you will find the CAD samples in the file CAD_SAMPLES.ZIP.

BINARY FILES: The Unisoft software imports the ASCII files the ECAD systems export but it does not import their binary files. Binary PCB database files are the ECAD companies own proprietary binary format. These binary file formats are normally not public or documented and my violate copyrights. Also as an ECAD company releases new versions of it's software their binary format may change and it would be virtually impossible to modify the Unisoft software to accommodate these changes in a timely manner. For these reasons the Unisoft software does not import the binary files directly and only imports the standard ASCII files these ECAD systems export. TIP: If you try to open your CAD file with a TEXT editor and the characters are not standard ASCII text characters then it is most likely a binary file and not the ASCII CAD file and the Unisoft software will not be able to import it!

Note 1a:CAD files without explicitly defined component rotations: This CAD file does not have explicitly defined component rotations.

This CAD file has component pin information but no usable data about component rotations and in these cases Unisoft automatically calculates component rotations using standard zero degree package orientations.

Note 1b:CAD files with explicitly defined component rotations: This CAD file has explicitly defined component rotations.

This CAD file contains rotation information. When a CAD file is imported into the Unisoft software were the component rotations are explicitly defined in the CAD file then Unisoft assigns these explicitly defined rotations to the components.

In some cases it may be desirable to modify these explicilty defined component rotations. If this is the case then the RESET ROTATION feature can be used to change the rotation of the component package shapes in CAD files that have explicitly defined rotations. When the RESET ROTATION feature is used then the Unisoft software automatically calculates component rotations using standard zero degree package orientations.

Note 2:Gerber: Gerber data is basically a drawing file of the PC Boards pad information. Most of the systems listed above gerber data files. Gerber does not contain component, pin or netlist information. Wherever possible, from the table above, try to obtain CAD files with pin x-y,netlist,trace data. However as is the case with virtually all Contract Electronics Manufacturers [EMS/CEM] often the only data their clients provide are the gerber files. In this case the Unisoft GERBER-CONNECTION menu is used to quickly turn these raw Gerber files into intelligent data to program your Assembly, AOI inspection, ATE Test and selective Soldering equipment; and also create process assembly sheets, kitting labels, costing reports, do first article and general inspection.

Gerber files are exported by hundreds of different CAD and software systems. The first few lines of the GERBER file will look something like the sample below.

There is also a full sample of a GERBER file on your installation directory of the Unisoft software and by default it would be c:program filesunisoftcad-import-file-samples-etcsample-gerber.ger or c:program files(x86)unisoftcad-import-file-samples-etcsample-gerber.ger.

Note 3:Importing Cadence Allegro CAD files into the Unisoft software: Cadence Allegro is usually less straight forward then the other CAD systems in generating the necessary ASCII file that is then imported into the Unisoft software. The Allegro CAD system requires an extraction program in order to get the data out of the system. The extraction script exports ASCII files and therefore anyone needing PCB data from the Allegro database needs to use the Cadence Extraction program. Outlined below are two options to create the ASCII file.

Please note that the main Allegro binary database has a .BRD extension. The .BRD is in Allegro's own proprietary binary format that is not public or documented and Unisoft does not import this file directly. The Unisoft software imports the standard ASCII files this database can export.

Option #1 - Some Allegro systems (NT version for example) will allow you to export out an IPC-D356 ASCII file. IPC-D356 is created directly from the export menu on the Allegro CAD system and the Unisoft software can then import the IPC-D356 file.

To export IPC-D356 from the Allegro software click the EXPORT MENU then click IPC-D356 and the resultant .IPC file created can be imported into the Unisoft software. To import the .IPC file into the Unisoft software first start the Unisoft software and click the main FILE menu then select SMART OPEN and select the directory where the .IPC file is located, then select the .IPC file and click OK. A window will open, click OK and the PCB will be displayed.

Option #2 - Some customers that use ALLEGRO have been able to export the standard file format from ALLEGRO known as the Fabmaster 'extraction script'. We recommend this file format because it contains a large amount of the PC Board detail (pins, netlist, traces, etc.).

To export Fabmaster 'extraction script' from the Allegro software you need to download and run the skill file script to extract the Fabmaster 'extraction script' CAD data. The licensed Cadence Allegro user can go to 'Sourcelink' on the Cadence website and download the Fabmaster skill file to extract Fabmaster 'extraction script' CAD data. The skill file should contain information on how it should be run. The resultant Fabmaster 'extraction script' CAD file created can be imported into the Unisoft software. To import the file you can use the SMART OPEN feature in the Unisoft software and the PCB will be displayed. The other option to import the file is to make sure the file name is .FAB then start the Unisoft software and click the main FILE menu then select OPEN and select the directory where the .FAB file is located. Next click the pull down menu next to 'LIST FILE TYPES' and select 'FabMaster Files (*.FAB)' then select the .FAB file and click OPEN and the PCB will be displayed.

The first few lines of the file will look something like this:

Note if you are using an older version of Unisoft before year 2016 the following may apply. Newer versions will detect these differences automatically: If you have an ASCII file similar in format to the one above 'A!XXX!YYY!ZZZ!' but it does not import into the Unisoft software with the above mentioned methods then first change the file extension to .VAL and try to import it into the Unisoft software. If that does not work then change the file extension to .VA2 and try to import it into the Unisoft software. The format above 'A!XXX!YYY!ZZZ!' comes in many variations so if you still have issues then please contact Unisoft.

Note 4:Importing EAGLE PCB files into the Unisoft software: Note that Eagle (CadSoft) was acquired by Autodesk in 2016 and so the export information below may change as the product is integrated into Autodesk.. ---- EAGLE PCB system users can export GenCAD, IPCD356 and Fabmaster files that can then be imported into the Unisoft software. The Eagle PCB system uses 'User Language Programs' scripts to export data out. To download these user contributed scripts for GenCAD, IPCD356 and Fabmaster go to the Eagle website then click DOWNLOAD, then click ULP's — USER LANGUAGE PROGRAMS — and select the GenCAD, IPCD356 or Fabmaster download. Please follow any instructions provided on the Eagle website.

From either the schematic or board editor type the word 'run' (No quotation marks) and then press enter. A dialog will appear that will allow you to browse for the ULP you want to run, select the desired ULP and then click open. EAGLE will now execute the ULP.

Note 5:Altium Designer .PCBdoc / .PCB / .PRO: The .PCBdoc and the .PCB files from Altium Designer / Protel are normally file formats that the Unisoft software can import. Also other formats from Altium Designer that the Unisoft software can import is the Protel PCB 2.8 ASCII format.

PCBdoc/PCB: The .PCBdoc or .PRO file formats typically can be imported. To export these files from the CAD system click FILE then SAVE AS or FILE then SAVE COPY AS.

The .PCBdoc or .PRO top of the file header should look like the following:

Protel PCB 2.8: The Unisoft software can import from Altium Designer the Protel PCB 2.8 ASCII format. To export the Protel PCB 2.8 ASCII format from the SAVE AS menu on the Altium Designer CAD system choose the Protel PCB 2.8 ASCII format. This file will import correctly into the Unisoft software. The Protel file exported should have a .PRO extension but may have a .PCB file extension. If you use the preferred Unisoft SMART OPEN menu then it does not matter what the extension is. If you wish to open it with the Unisoft standard OPEN menu then the file should have a .PRO extension.

The Protel PCB 2.8 top of the file header will look something like the sample below.

There is also a full sample of this CAD file on your installation directory of the Unisoft software and by default it would be c:program filesunisoftcad-import-file-samples-etcsample_protel.pro or c:program files(x86)unisoftcad-import-file-samples-etcsample_protel.pro.

'PIN COORDINATE IS TOO LARGE' BOUNDARY LIMIT ERROR: If you are using Unisoft software version 5.11.11 or newer skip the following note because these newer versions of the software automatically adjust for the boundary limit error outlined here: If on importing the Protel PCB ASCII file into the Unisoft software you get the message 'Nothing to display!! Most likely a pin coordinate is too large. Failed.' then the PC board you are trying to import is usually outside the Unisoft software display size limits which is 65.536 inches by 65.536 inches (X=+32.767 to -32.767 and Y=+32.767 to -32.767). Usually the issue is that the PC Board when it was being designed on the CAD system was positioned towards the extreme corner of the CAD system display. So to fix this the CAD Designer simply needs to reposition the PC Board more towards the 0,0 origin of the CAD display and then regenerate the Protel PCB ASCII file. You should then be able to import this newly generated Protel PCB ASCII file into the Unisoft software. If you were to open the failing Protel PCB ASCII in a text editor you could actually see the coordinates that are too large. For example in the following file below on the fifth line we see the coordinate 36120000 and on rescaling this coordinate is 36.12 inches which is greater than our maximum limit of 32.767 inches.

Note 6:ODB++ (standard file format - Mentor Graphics/Valor ):

Importing into Unisoft: The Unisoft software can import the ODB++ format. ODB++ is not a single file format as most CAD type files but an array of files in multiple directories that usually have several levels of files. These files may or may not be in a single compressed file format such as .TGZ, .ZIP or .TAR . If compressed then to import the ODB++ file into the Unisoft software first make sure the single .TGZ, .ZIP or .TAR file that the ODB++ files are in is unzipped. Then when uncompressed you should see subdirectories with the names MATRIX, STEPS, FONTS, SYMBOLS, etc. Next from the Unisoft software click FILE from the main menu then click SMART OPEN and select the root directory where the ODB++ files are located then click OPEN and click OK. Click OK to close the Costing window and your PC Board is displayed.

About .TGZ and .TAR files: A file with the TGZ file extension is usually a GZIP Compressed Tar Archive file. TGZ files can be opened with most popular zip/unzip programs. Compressed archives are typically created by assembling collections of files into a single TAR archive, and then compressing that archive with gzip which then creates a .TGZ file. So basically most popular zip/unzip programs will work for opening .TGZ, .TAR and .ZIP files.

Note 7:X-Y Component center and rotation file: An X Y Center and rotation (XYR) file is any file containing component X Y center and rotation information. This type of file in most any format can be imported into the Unisoft software and is useful in creating Assembly and AOI machine programs. Our customers may find a file with similar data to that found in the XYR in their project CAD and BOM data folder. They can then use that file to import into the Unisoft software.

For example it may look like any variation of the following: Below are examples of files that contain reference designator, X/Y center and rotation formation in various formats. All of these files and more can be imported into the Unisoft software.

Please note that it is always preferable to use the other full CAD files listed above and not a XYR file as your first choice for importing into the Unisoft software.

For more details on XYR importing click here FEATURES and see 'Importing your X/Y Center, Rotation files'.

Note 8:OPTIONAL EXPORT OUTPUT: Generating this output may be an optional feature. Please check with the software provider for details.

Note 9:CAD Extraction Procedure: From Mentor Expedition select File, then Export then General Interface and then select the export type GenCAD. You can now import this file into the Unisoft software.

The first few lines of the GenCAD file will look something like the sample below.

There is also a full sample of this CAD file on your installation directory of the Unisoft software and by default it would be c:program filesunisoftcad-import-file-samples-etcsample_GENCAD.cad or c:program files(x86)unisoftcad-import-file-samples-etcsample_GENCAD.cad.

Note 10:CAD Extraction Procedure: Use Report Writer (Veribest) and export the Mitron option to create the GenCAD file. You can now import this file into the Unisoft software.

The first few lines of the GenCAD file will look something like the sample below.

There is also a full sample of this CAD file on your installation directory of the Unisoft software and by default it would be c:program filesunisoftcad-import-file-samples-etcsample_GENCAD.cad or c:program files(x86)unisoftcad-import-file-samples-etcsample_GENCAD.cad.

Note 11:CAD Extraction Procedure: In PADS on the In/Out menu select ASCII Out and select the ALL option so that the full PADS ASCII file is created then output the .ASC file. You can now import this file into the Unisoft software.

The first few lines of the PADS .ASC file will look something like the sample below.

There is also a full sample of this CAD file on your installation directory of the Unisoft software and by default it would be c:program filesunisoftcad-import-file-samples-etcsample_PADS.asc or c:program files(x86)unisoftcad-import-file-samples-etcsample_PADS.asc.

Note 12:CAD Extraction Procedure: From the P-CAD File Menu select Export and select PDIF to create the .PDF file. You can now import this file into the Unisoft software.

The first few lines of the P-CAD .PDF file will look something like the sample below.

There is also a full sample of this CAD file on your installation directory of the Unisoft software and by default it would be c:program filesunisoftcad-import-file-samples-etcsample_PCAD.pdf or c:program files(x86)unisoftcad-import-file-samples-etcsample_PCAD.pdf.

Note 13:CAD Extraction Procedure: From the P-CAD File Menu select Save As and select the option ASCII .PCB . You can now import this file into the Unisoft software.

The first few lines of the .PCB file will look something like the sample below.

There is also a full sample of this CAD file on your installation directory of the Unisoft software and by default it would be c:program filesunisoftcad-import-file-samples-etcsample_ACCEL TANGO.PCB or c:program files(x86)unisoftcad-import-file-samples-etcsample_ACCEL TANGO.PCB.

Note 14:CAD Extraction Procedure: From the PROTEL file menu select Save As and select ASCII .PCB . You can now import this file into the Unisoft software.

Note: For Protel 99 SE (service pack 6) should be able to export to a PCAD 2000 .PCB which is actually a TANGO .PCB file and the Unisoft software can import that file. Also other Protel 99 formats can be imported.

Please examine the first few lines of the .PCB file created and they will look something like the sample below and must be in this format.

There is also a full sample of this CAD file on your installation directory of the Unisoft software and by default it would be c:program filesunisoftcad-import-file-samples-etcsample_ACCEL TANGO.PCB or c:program files(x86)unisoftcad-import-file-samples-etcsample_ACCEL TANGO.PCB.

Also an example of another Protel 99 format that can be imported follows:

Note 15:CAD Extraction Procedure: From the TANGO DOS File Menu select Save As and select the option ASCII .PCB . You can now import this file into the Unisoft software.

The first few lines of the TANGO DOS .PCB file will look something like the sample below.

There is also a full sample of this CAD file on your installation directory of the Unisoft software and by default it would be c:program filesunisoftcad-import-file-samples-etcsample_ACCEL TANGO.PCB or c:program files(x86)unisoftcad-import-file-samples-etcsample_ACCEL TANGO.PCB .

Note 16:CAD Extraction Procedure: Use DDF2GenCAD (Ultiboard) to export the GenCAD file. You can now import this file into the Unisoft software.

The first few lines of the GenCAD file will look something like the sample below.

There is also a full sample of this CAD file on your installation directory of the Unisoft software and by default it would be c:program filesunisoftcad-import-file-samples-etcsample_GENCAD.cad or c:program files(x86)unisoftcad-import-file-samples-etcsample_GENCAD.cad.

Note 17:CAD Extraction Procedure: From the CAD system select the Interface option in the Job menu and select CADIF output to create the .PAF file. You can now import this file into the Unisoft software.

The first few lines of the CADIF .PAF file will look something like the sample below.

There is also a full sample of this CAD file on your installation directory of the Unisoft software and by default it would be c:program filesunisoftcad-import-file-samples-etcsample_cadif.paf or c:program files(x86)unisoftcad-import-file-samples-etcsample_cadif.paf.

Note 18: The first few lines of the IPC-D-356 file will look something like the sample below. You can import this file into the Unisoft software.

There is also a full sample of this CAD file on your installation directory of the Unisoft software and by default it would be c:program filesunisoftcad-import-file-samples-etcsample_IPCD356.356 or c:program files(x86)unisoftcad-import-file-samples-etcsample_IPCD356.356.

Note 19: Unisoft is not aware of any full ASCII CAD file or any X,Y center rotation file export capabilities from this CAD system that can be used for import into the Unisoft software.

Since these data files are not available one other option is this CAD system can export Gerber's that the bareboard is made with. These Gerber files can then be imported into the Unisoft software and used to MAKE the component shapes on the PC board and at that point the files needed to program for your assembly, AOI and test equipment can be created. Also you can create assembly process documentation, kitting labels, do First Article Inspection, quoting, etc.

Refer to Note 2 above for additional information on Gerber files.

Note 20:AutoCAD DXF: AutoCAD DXF (Drawing Interchange Format, or Drawing Exchange Format) is a CAD data file format developed by Autodesk for enabling data interoperability between AutoCAD and other programs. AutoCAD .dxf files are a 'Design eXchange Format' files. This file type is only a drawing file. Unisoft can import and display these drawing files but they have little other value within the Unisoft software. For example you can not extract component, pin, x/y, netlist data, etc. from this type of file.

Note 21:ODB++ (Valor/Mentor Graphics software):

Exporting from the CAD System: From the Altium CAD system on the FILE menu select FABRICATION OUTPUT and select ODB++ FILE. You can now import this file into the Unisoft software. Note: Depending on the version of the Altium software, etc. this option may not be available.

When uncompressed you should see subdirectories looking something like those below.

Note 22: An export that maybe available from the Altium Designer CAD system is the IPC-2581 cvg file format. The first few lines of the IPC-2581 .cvg file will look something like the sample below. You can import this file into the Unisoft software.

Link to download a sample IPC-2581 .cvg file Link to download a sample IPC-2581A .xml file

Note 23:CAD tool: This CAD tool exports drawing type files. For example some of the drawing file types that maybe created by this CAD tool are DXF, TIFF, JPG, BMP, HPGL, etc. These files are drawing type files and Unisoft can import and display these drawing files but they have little other value within the Unisoft software. For example you can not extract component, pin, x/y, netlist data, etc. from these type of files.

Note 24: The first few lines of the IPC-2581 .cvg file will look something like the sample below. You can import this file into the Unisoft software.

Note 25: The first few lines of the IPC-2581A .xml file will look something like the sample below. You can import this file into the Unisoft software.

Note 26: The first few lines of the Fabmaster FATF file will look something like the sample below. You can import this file into the Unisoft software.

Link to download a sample Fabmaster FATF file

Note 27: For the DesignSpark CAD system to generate an ODB++ file go to the main menu and click OUTPUT and then click ODB++ . After the ODB++ file has been created go to Note: 6 .

Note 28: An export that maybe available from the OrCAD PCB Designer system is the IPC-2581 .cvg file format. The first few lines of the IPC-2581 .cvg file will look something like the sample below. You can import this file into the Unisoft software.

Link to download a sample IPC-2581 .cvg file Link to download a sample IPC-2581A .xml file

Note 29:Mentor Graphics Neutral File:

Exporting from the CAD System: From the CAD system on the output menu of the Fablink utility select WRITE NEUTRAL FILE and then select to output all options. You can now import this file into the Unisoft software.

Link to download a sample Mentor Graphics Neutral file Note 30: OrCAD export of GenCAD:

Exporting from the CAD System: In the OrCAD layout software without a board or project open from the File menu select Export and choose the GenCAD option. You can now import this file into the Unisoft software.

Link to download a sample GENCAD file

Note 31:X-Y Component center and rotation file: An X Y Center and rotation (XYR) file is any file containing component X Y center and rotation information. This type of file in most any format can be imported into the Unisoft software and is useful in creating Assembly and AOI machine programs. In AutoCAD Electrical an X Y Center and rotation (XYR) file maybe exportable via the Data Extract window. They can then use that file to import into the Unisoft software.

Below are examples of files that contain reference designator, X/Y center and rotation in various formats. All of these file types and also a similar one exported from AutoCAD Electrical via the Data Extract window can be imported into the Unisoft software.

Please note that it is always preferable to use the other full CAD files listed above and not a XYR file as your first choice for importing into the Unisoft software.

For more details on XYR importing click here FEATURES and see 'Importing your X/Y Center, Rotation files'.

Link to download a sample XY Rotation file

Note 32:ODB++ export from EASY-PC:

Exporting ODB++ from EASY-PC: Go to the Output menu to export the ODB++ file. In the window displayed for Layers click the box Select All and at the top of the window click the box Compressed . A compressed .TGZ file will be created in the folder location selected in the Compressed File field.

Note 33:ODB++ export from Pulsonix:

Exporting ODB++ from Pulsonix: Exporting ODB++ from Pulsonix: Go to the Output menu to export the ODB++ file. In the window check the box Compressed . Leave the box Use CAM/Plot Layer Combinations unchecked. A compressed .TGZ file will be created in the folder location selected.

INVESTIGATE OUR OTHER SHOP FLOOR AUTOMATION SOFTWARE:

CELLS Workflow MES Product Tracking is a Process Control System for use in manufacturing sectors such as electronics, semiconductor, automotive, aerospace, medical devices, pharmaceuticals and food processing. CELLS Workflow MES Product Tracking includes complete product tracking, inventory tracking software, defect tracking software, collection data, deliver & control documents, Statistical Process Control (SPC) quality reporting and more.

ProntoTEST and FIXTURE will accurately setup your Automatic Test Equipment (ATE) and design your 'bed of nails' test fixturing.

ProntoVIEW-MARKUP is assembly CAD Viewer & Gerber Viewer software quickly find components, pin, shorts between traces, etc. ProntoVIEW-MARKUP is also a redline tool that allows annotation of the assembly to create work and assembly instructions, etc. Download the ProntoVIEW-MARKUP Software ….

ProntoPLACE will quickly program your surface mount SMT and thru-hole assembly equipment.

ProntoGERBER CONNECTION imports raw Gerber data and allows the user to add intelligent information to the shapes on the display. This smart data is then used directly by the other Unisoft OneFACTORY software modules or export to standard ASCII file formats for use by other manufacturing systems.

Unisoft: Manufacturing software since 1985

Pcb File Open

When compared over the last 30+ years Unisoft software has been the clear choice in price and performance.

0 notes

shygladiatorcollection · 4 years ago

Text

Screen Record On Mac Sierra

How To Screen Record On Mac Sierra

Mac is a great and probably the most stable operating system or platform for computers. It doesn’t matter whether you are a student, businessman or regular internet user, you can definitely start using Mac computer to get the better experience. Let’s assume that you want to record your screen for any reason. For example, you are a writer, and you want to show your readers how to do a particular thing on Mac with a video tutorial. At such moment, you can record your screen using these screen recording apps for Mac. Not all of them are free. However, whatever the price is, that is worth buying.

Salah satu kelebihan perangkat Apple yaitu kemudahan penggunaanya. Salah satu fitur yang diberikan Apple secara gratis yaitu Aplikasi Screen Recorder. Hampir semua perangkat apple sudah mempunyai perekam layar bawaan mulai dari Iphone, Macbook, Imac hingga Ipad. Apple has included an incredibly easy to use screen recorder with macOS High Sierra, contained inside the QuickTime Player utility. AppleInsider shows you how to use it. Record the entire screen Click in the onscreen controls. Your pointer changes to a camera. Click any screen to start recording that screen, or click Record in the onscreen controls. How to Record Screen on Mac using QuickTime Player (macOS High Sierra & Sierra) If you’re running an older version of macOS like macOS High Sierra & Sierra, you can always use the QuickTime Playe r for basic screen recording (as well as audio recording). Mac screenshots: 4 ways to capture your MacBook's screen. Keyboard shortcuts to take screenshots might seem straightforward on your Mac, but each technique captures a different part of your screen.

Best Screen Recording Apps for Mac

1] QuickTime Player

When you have a free tool already installed on your computer, you do not have to search for another third-party tool. From basic to advanced, you can record every kind with the help of QuickTime Player. QuickTime Player is a video player app that you can use to record your screen without any problem. It doesn’t matter whether you want to record your file explorer or browser window or any other app, you can do everything by utilizing this free inbuilt tool. To start using this tool, press Cmd + Space and type QuickTime Player. Open the corresponding result. Therefore, you have to click the File > New Screen Recording.

After that, you will a RECORD button that you need to press. Following that, you should select a region that you want to record. It can be a particular app window, or full screen – whatever you want. After completing the recording, you can find an option to save the video and choose a path where you want to save your recorded video.

2] Snagit

Although Snagit is a paid application for Mac, you can find a lot of features in this tool. In simple words, Snagit is worth buying. This tool is built to capture screenshot. However, you can use it to record your screen as well since it does that job pretty well and without any lag. This is meaningless to mention anything about the resolution since that depends on your monitor’s resolution. Talking about recording, you would be able to record any app window, full screen, browser window or anything else. There is no limit on time, and hence, you can create as long video as you want with the help of Snagit. Regarding compatibility, you should have macOS High Sierra, Sierra, or El Capitan (macOS 10.11 or later).

3] FimoraScrn

Filmora Scrn is another paid software to record Mac screen without any problem. In case you do not like the Snagit app for your Mac or you think that it costs too much, you can definitely buy Filmora Scrn, which is more affordable. Talking about the price, it costs only $19.99 (one-time payment). The available features of this tool are pretty good and handy. You can find an intuitive design, webcam recording, audio recording, etc. in this tool. This is possible to add watermark to your video with the help of this tool. On the other hand, you can find a basic video editing interface, which you can use to apply basic changes. As per the official statement, you can record video up to 120 FPS without any lag. As mentioned earlier, you can record screen and webcam simultaneously.

4] Apowersoft Screen Recorder

Apowersoft Screen Recorder is a free screen recording app for Mac that comes with no time limit. Being said that, you can record as long video as you want. Being compatible with macOS High Sierra, Apowersoft Screen Recorder has gained much popularity among them, who do not want to use QuickTime Player but want to use a free alternative. Talking about features, you can record webcam, computer screen, microphone, system sound (or both), etc. The best thing about this tool is its user interface, which is neat and clean. You can choose a custom resolution to record video, choose a region and do more with the help of this tool. It also comes with a video file explorer that will let you manage all the recorded videos from one panel.

5] Capto

Capto is another paid, but very affordable screen recording software for Mac, which costs around $29.99 and this is available for macOS 10.10.5 or later version. You can record screen up to 60 FPS. Like any other tool, you can record any app including music player, browsers like Google Chrome, Firefox, and more. The highlight of this tool is you can find a video editor to give it a professional touch. Being said that, you do not need any other third-party tool for basic editing. Not only a video editor but also you can find an audio editor. This is important when you captured audio alongside your video and want to edit it accordingly. There is a file manager as well that will let you browse all the recorded files. Another essential thing is you can share your recorded video on various social networking sites like Facebook, Twitter, etc. Apart from you can upload video to YouTube, Evernote, Dropbox, etc.

6] Camtasia

If you need a professional video editor alongside a screen recording app, you should not think twice and opt for Camtasia 2018 edition. Although this tool is quite expensive, you do not have to download any other tool after using this one. Talking about the price, it costs around $249 for one license. On the other hand, you should have macOS 10.10 or later version to install it on your computer. When you would try to record your screen, you can find a lot of options like range selection, cursor visibility, system sound recorder, microphone support and more others. The user interface of this tool is pretty good, and you should not get any issue while starting the recorder or editing the video. Also, it renders the video quite fast. Therefore, you do not have to consume a lot of time to export the video from the editor.

Would you like to make video tutorials to show others how to use the program? Or maybe you need to discuss a problem with your computer that you are experiencing. One of the most successful ways to present this information is screen recording software. So, in this feature, I am going to show you how to screen record or record a video on Mac without using any additional software.

Fortunately, Mac has a built-in screen recorder and this feature was included with the macOS Mojave update is a feature that allows you to record video of your screen as well as take screenshots with the macOS screen capture tool.

You Might Also Like: How to Uninstall Programs on Mac Computer in Two Different Ways 2020

How to Record Screen on Mac ( macOS Catalina & macOS Mojave)

Luckily it’s easy to record what is happening on the screen of your Mac as I said earlier that macOS Catalina and macOS Mojave has a built-in screen recording feature and there’s no need to install any other screen recording applications. So, if you’re using macOS Catalina and macOS Mojave then you have to use this feature to record screen or video on Mac.
