Yanhua ACDP2 Correct MB HU6 ODO (IC177) Mileage Guide

Q: Is it possible to use Yanhua ACDP2 to correct mileage for Benz HU6 instrument module with R7F701403 chips?

A: Yes. Yanhua Tech has released the Yanhua Module 37 to work seamlessly with the Yanhua Mini ACDP/ACDP2 for the MB HU6 instrument module IC177 mileage correction (Worldwide exclusive). No need to solder! No risk!

Yanhua ACDP Module 37 Key Features:

1.Supported Functions:

Mileage correction for the MB HU6 instrument module (A 167/A 213/A 247) equipped with R7F701403 chips.

2.Compatible Vehicle Models:

Mercedes-Benz W247: A-Class, B-Class, CLA, GLA, GLB (2019 and later)

Mercedes-Benz W177: CLA, GLA (2019 and later)

Mercedes-Benz W167: GLE, GLS (2019 and later)

Mercedes-Benz W213: E-Class, CLS (2020 and later)

Mercedes-Benz H243/X243: EQA, EQB (2021 and later)

Mileage Correction Using Yanhua ACDP2 and Module 37

Connection diagram:

Mini ACDP App Menu:

Select Benz >> HU6 Module (IC177) ODO >> R7F701403

Perform Mileage Correction:

Follow the app steps for mileage correction:

1.OBD Identify

OBD+ICP Reset Mileage

3.Original Module Reset Mileage

Step 1: OBD backup data ICP Modify Data

Step 2: ICP modify data

Step3: OBD modify KM

Yanhua ACDP Module 37 for MB HU6 ODO (IC177) Mileage Correction will be available at EOBDTool.co.uk in mid-January 2025.

Pre-order it now!

[auto-tools]

Fixing W177 Frame Misalignment with Yanhua ACDP Module 37

Customer Problem: Hi, I have an issue with the W177 frame. It is mikes off and not correct when using Yanhua ACDP Module 37. You'll see from the Pics that it doesn't line up. All line up apart from that one circled.

Salutation: You only need to purchase the HU6-R7F71403-B board.

www.obd2shop.co.uk

[eobdtooluk-blog]

How to Use Yanhua Module 37 for MB HU6 Mileage Correction?

how to use Yanhua ACDP Module 37 MB HU6 Instrument Module(IC177) Mileage Correction?

[auto-tools]

Yanhua ACDP Module 37: MB HU6 IC177 Mileage Correction

New release! Yanhua ACDP Module 37 for MB HU6 instrument module(IC177) mileage correction has been launched. It supports adjusting mileage for the A167/A213/A247 module with chip model R7F01403. It needs to work with Mini ACDP2 together.

Supported Vehicle Models: Support for Mercedes-Benz W247 A/B/CLA/GLA/GLB after 2019. Support for Mercedes-Benz W177 CLA/GLA after 2019. Support for Mercedes-Benz W167 GLE/GLS after 2019. Support for Mercedes-Benz W213 E/CLS after 2019. Support for Mercedes-Benz H243 EQA and X243 EQB after 2021.

www.obd2shop.co.uk

[eobdtooluk-blog]

Yanhua ACDP2 Module 39 Correct Mileage for Benz MB HU7 Instrument

Yanhua Module 39 is newly released and works with Yanhua ACDP1/ACDP2 for mileage correction on bench for Mercedes-Benz MB HU7 instrument module (A206/A223/A177) equipped with chip model R7F7015293/R7F7015294. Module 39 comes with a free emulator. One car requires one emulator. More emulators can be purchased separately (1 HU7 emulator/5 emulators).

If you want to correct mileage for MB HU6 instrument modules (models A167 /A213/A247) with chip R7F701403, choose Yanhua ACDP Module 37.

Yanhua ACDP Module 39 Supported Vehicle Models:

S-Class(W223)

C-Class(W206 / S206 / V206 / X206)

AMG(192 / X290)

A-Class(W177)

B-Class(W243 / W247)

CLA(C118 / W118)

CLE(A236 / C236)

EQA(H243)

EQB(X243)

EQE(V294)

EQS(V297)

GLA(H247)

GLB(X247)

GLC(C254 / X254)

GLE(V167)

GLS(X167)

CLS(W257)

SL(232)

Supported Instrument Modules:

A206

A177

A223

ACDP APP Menu Path:

Benz-> HU7 ODO Module (IC177/IC223) mileage correction-> R7F701529 (A177/A206/A223)

There are three interface boards for selection, choose the correct interface board depends on the dashboard module.

BENZ-HU7-A Interface board (A point)

BENZ-HU7-A Interface board (C point)

BENZ-HU7-B Interface board

Reset mileage process:

1.Identify info.

2.Reset mileage

Step 1: Modify ODO Module KM

Step 2: Install ODO Module emulator

BENZ-HU7-A Interface board (A point)- for A223 and A206

(need to push the DIP switch on the BENZ-HU7-A interface board to the A-end)

BENZ-HU7-A Interface board (C point)- for A177

(need to push the DIP switch on the BENZ-HU7-A interface board to the C-end)

BENZ-HU7-B Interface board- for A223

[eobdtooluk-blog]

Yanhua ACDP with Module 37 Correct Mileage for Benz A247 W177 A-Class HU6 Cluster

Yanhua Tech released a new YANHUA MB HU6-R7F71403-B Interface Board for Mercedes-Benz A247 W177 A-class HU6 instrument mileage correction. It works with Yanhua ACDP 1/ ACDP 2 and Module 37.

[eobdtooluk-blog]

Yanhua ACDP2 with Module 37 Reset Benz HU6 IC177 Mileage on Bench

This is a guide on how to Reset Benz HU6 IC177 Mileage with Yanhua ACDP2, Module 37 and Yanhua Mercedes-Benz HU6 YH-OBD Platform on Bench

[eobdtooluk-blog]

Yanhua Mercedes-Benz HU6 YH-OBD Platform for Mercedes- Benz HU6 IC177 Mileage Reset

As we know, Yanhua ACDP/ACDP2 with Module 37 can correct the mileage for the MB HU6 instrument module (A167/ A213 / A247) equipped with the R7F701403 chip. However, previously, it was necessary to install the original HU6 module in the vehicle and perform mileage modification via OBD. Now, Yanhua Tech has released the MB HU6 YH-OBD Platform, eliminating this requirement and enabling direct bench operation for a more convenient and efficient process.
