Colt Woodsman Serial Number

Colt Woodsman Series Semi-Automatic 22 LR Pistol

Colt Woodsman Serial Number Dates

Colt Woodsman Serial Numbers

Colt Woodsman Serial Number Lookup

Colt Woodsman Match Target Semiautomatic Pistol.22 cal., serial number 43382-S, 6' barrel length, Second Series. Manufactured 1949. (C&R) 6 Walther Model P 1 Double Action Pistol. 9 mm cal., serial number V003163, 5' barrel length. Date manufactured 2/77. 7 Thames Arms Company 38 Double Action Five-Shot Revolver.

Year / Serial Number. 1840-1843 1-500. Colt Baby Dragoon Pocket. Year / Serial Number. 1847 1 1848 2000 1849 8000 1850 12000 - 14000. Cloverleaf House Model Revolver.41. Year / Serial Number. 1871 1 1872 4000 1873 5000 1874 6000 1875 7200 1876 9600 - 9952. 1st Model Deringer Chambered in.41 caliber Manufactured circa 1870-1890.

Includes Challenger, Huntsman and Targetsman FIRST SERIES WOODSMAN: 1915-1947 (Target and Sport Models) DATE Approximate Serial Number Mar 1915 1 Jan 1916 850 Jan 1917 4000 Jan 1918 6400 Jan 1919 7000 Jan 1920 20200 Jan 1921 25000 Jan 1922 27200 Jan 1923 33500 Jan 1924 38700 Jan 1925 43000 Jan 1926 46650 Jan 1927 51700.

THERE ARE THREE DISTINCT SERIES (maybe even 4 or 5 depending on how fine you interpret it)

This article is a brief rendition of the Colt 'Woodsman series, and will give the average owner insight to this series. If you are a collector, then you need to do advanced searching

There are three basic series of Woodsman pistols, corresponding to three basic frame designs. There are also some sub-series within the series, like different barrel lengths, sights or grips, etc.

The models referred to here are all those pistols built on the “S” frame as designated by the Colt factory. The First 'Woodsman' series would have NOT been marked Woodsman, however for general purposes it is a Woodsman, but for collectors it is called the pre-Woodsman as noted below. The actual First model Woodsman (that had that name on it) as it existed prior to and during World War Two, was basically the same as the pre-Woodsman. The Second Series includes all versions built on the 'second' frame design from late 1947 until mid 1955, and the Third Series means the third “S” frame design as used from 1955 to the end of regular production in 1977.

The 'S' series is the model number that the Colt factory assigned to this model. Others model designations were 'P' for the SSA (Peacemaker), G for the Government model (1911), 'I' for the Python, 'M' for the 1903/1908 32/380 semi-auto and 'N' for the 1908 25ACP, etc.

Pre Woodsman (1915-1927) The first Colt 22 RF automatic was marketed as Colt Automatic Target Pistol. There was no inscription on the LH side of the frame at the location where the barrel threads into it.This pre-Woodsman and the First Model can be easily recognized by its distinctive profile, which resembles the German Luger and the later Ruger Standard model, both having the rakish rearward grip angle. The grips were standard checkered walnut. The serial numbers started at #1 which also provides a sure means of identification, with this serial number located on the front strap of the grip, and contains only numeric characters, with NO alphabetical suffix characters. The slides were marked on the LH side “Colt Automatic Caliber 22 Long Rifle” in 2 lines. There were no markings as to model or caliber on the frame or barrel.

These pistols were designed to use only Standard velocity ammo, (which was the only ammo at that time) and this pistol was identified by a checkered thumbprint on the upper rear web of the mainspring housing. This 'thumbprint' probably was not the intent at that time, but simply as a roughed area on the backstrap to better secure the gun in the shooter's hand following the pattern on their other models.

The grip-frame bottom was 90 degrees to the magazine with the small magazine latch on the rear of the grip frame securing the upper rear of the magazine in the magazine well. Most of these EARLY magazines had no identifying marks on the bottom. And as a side-note would many times, they could be mistaken and interchangeable with the High Standard A or B models.

Barrels were 6 5/8” long and a step down shoulder at the rear to a small diameter straight, “pencil barrel” (no taper). You will note in the photo below that there is no writing on the LH side of frame where the barrel screws into. And that many of these early guns had the trigger placed nearer the center of the trigger guard as seen below.

Ammo Change If your pistol is pre-WWII, (and has not been altered) it will have a pattern on the mainspring housing, where the web between the thumb and forefinger touches when holding the pistol in firing position. If that pattern is checkered (photo on the left below), it was made for use of standard velocity ammo (as that was all that was available at that time). If it is a pre WWII gun made after 1931, the pattern was changed to horizontal parallel lines (center in the photo below), because these later designed guns all were all designed for the later high velocity ammo which came out in 1931 at about s/n 80,000 of these pistols.

Later the factory did offer conversion kits for usage of High Speed ammo in the early guns. This included a new mainspring housing and recoil spring. However it is possible to have an early standard velocity gun that has just had the recoil spring replaced with the newer high speed version, but the only way to tell on these is tear it apart and look at the recoil spring as identified below. It is not recommended to use the older pistols with the older weaker recoil spring when using the now common High Speed ammo because of possible internal damage to the slide.

After my having the opportunity to look over factory blueprints, the identifying difference of the newer High Speed recoil spring being is that it is wound LEFT HANDED, as compared to the older weaker Standard Velocity spring that is the common right handed wind. I came up with this after which I had the rare chance of looking at copies of original factory blueprints and am probably the only one around that knows this (until now).

Some say that the mainspring housing was made stronger. In all my years as a obsolete firearms parts replacement manufacturer, I seriously doubt this, and the change was simply the horizontal lines to easily identify one from the other. Also in my 60 plus years of gunsmithing, I have seem numerous of the older standard velocity guns still being shot using High Speed ammo. They still seemed to survive, adding to the excellent original design of this firearm, however the most common problem was that the slide would not go forward with enough energy to completely feed or chamber a round (common with a weakened recoil spring being the culprit).

The original standard Velocity ammo marking on Left, with High Velocity ammo marking on RightWoodsman pre-war magazine

Woodsman First Series (1927-1944/1946)

The normally accepted serial number separating the pre-Woodsman from the 'Woodsman' is #54,000. This model is a carry over of the Pre woodsman with the following exceptions. The LH side of the of the frame at the location of the barrel threads is marked ‘The Woodsman”.

The model was the same, serial numbers carried on from the pre series, but at this time the addition of the 4 1/2' sport barrel and the first series Match Target which had a heavy flat sided barrel was introduced. This Match Target model also has a MT prefix to the serial number and these numbers are on the RH side of the bottom of the grip frame as the normal location on the front strap was covered by the larger wrap-around walnut grips.

Again after the introduction of the High Speed ammo in 1931 the recoil spring was changed and this thumbprint was changed to signify HS ammo, at about s/n 80,000.Conversion kits were made available for the older Standard Velocity guns.Some say the mainspring housing/slide stop was made of a different or casehardened material. However it is my educated guess that this is not the case, just that the horizontal parallel lines on the mainspring housing for identification, since they made the recoil spring stronger to accommodate the more powerful round there was really no need to change the housing.

There were 3 sub series, the

(1) Sport model which had a 4 ½” straight taper barrel and a fixed front sight.And the

(2) Target model with a 6 5/8” barrel tapered barrel with a small front sight base, and the front sight pivoting in with adjustment screw in front for elevation of the sight blade.

(3) The Match Target used a totally different barrel, being flat sided nearly the same thickness as the front of the frame, then running parallel for about 1 ½”, raising to about 1” from the top and then lathe turned in a taper but with the sides still flat, to the muzzle.On the LH side of the flat directly in front of the where the barrel is threaded into the frame, was rollmarked a Bullesye about 1” in diameter, with the words Match above the Bulleseye and Target below.

In the photo below you will notice the writing on the frame where the barrel screws into that says 'The Woodsman'. Also note the trigger moved more rearward in the trigger guard. Triggers were interchangeable between ALL Woodsmans, even the 3rd series.

Colt First Series Sport Woodsman

The grips for the MT were usually made of checkered walnut and wrapped around the front of the grip frame, utilizing one center screw there along with the normal through screw.These wood grips had the sides extending downward, simulating elephant ears by which they were nicknamed.

This Match Target only came with a 6 5/8” barrel and also had adjustable front and a new adjustable Stevens rear sight.This series Match Target was in production from 1938 to 1944.Wartime MT production saw the use of brown plastic grips extending downward near the same configuration of the later 3rd series guns.

The plastic material that the shorter standard grips that were used on the Sport or Target versions was the same as the wartime MT.

The rear sights were normally non adjustable on the Sport or Target pistols.

Magazines for the Pre-Woodsman and 1st series Woodsman are interchangeable no matter the color.

All of the Woodsman series have a unique take down system that retains the recoil spring for easier re-assembly. You will note a small 1/8' peg protruding upward in front of the rear sight and slightly to the side of it. This peg activates a recoils spring retainer that has to be utilized upon reassembly of the slide onto the frame.

The 1938 factory advertisement for the First Series Woodsman Match Target shown below.

Production ceased during WWII for private sales, however some 4,000 Match Target pistols were assembled and issued for military practice purposes up into 1944.These would have been marked 'US PROPERTY'. And the wooden grips were replaced with newer longer plastic grips. After the war, in 1946, some sporting guns were assembled of existing parts.

Woodsman Second Series (1947-1952) The Second Series Woodsmans was a newer, improved redesign of the 1st series, their most predominate distinguishing feature is they have the magazine bottom being parallel to the barrel, making for a larger grip area. And they have a automatic slide stop, or hold open device that is activated by the magazine thumbpiece.

These 2nd Series Woodsmans were the first model that had a push button magazine release, similar to what was being used on the Government Model 45. They also came with the then new Coltmaster adjustable rear sight. There was alanyard ring provision incorporated in the bottom rear of the mainspring housing.

Magazines for this series, although made slightly different for the 2nd and 3rd series are somewhat interchangeable. The LATE 3rd series will not latch in place in the 2nd series unless there is a retainer notch cut in the front (some have it while others may not, depending on vintage). However the 2nd series will lock into the 3rd as the latch on them is on the heel of the magazine. More details explained below.

Woodsman 2nd series, Sport. Note the similarity to Colt 1911 45 ACP magazine latch & the adjustable rear sight, with Coltwood gripsGrip adapters in Coltwood

All post-WWII type Woodsmans, both Second and Third Series, have the serial number stamped on the RH side of the frame at the rear where the barrel is threaded into. An S suffix is added to the serial number.

Barrels were 4 ½”for both the Sport or Match Target, with 6” for the Target and Match Target. Front sights were different on the Sport than the Target models. The Sport had a front sight sloping forward apparently to facilitate a easier draw from a pocket, while the Target and Match Target model's upper rear angled rearward, to give a better non reflective sighting surface. Of the versions offered, the 4 1/2' Match Target is the rarest, because most dedicated target shooters wanted the longer barrel, supposedly for better accuracy.

All barrels of the post War models were screwed into the frame using LEFT HAND THREADS. This was apparently because of the RH rifling and IF the barrel was not secured tightly enough, the bullet rotating inside the barrel and the barrel using RH threads, the barrel could unscrew, not a common occurrence, but did happen occasionally. There was a magazine safety feature of the this new series, which made the firearm unfireable with the magazine out. And there is a slide stop inletted into the LH grip panel, as visible in the photo above, on all the Woodsmans of this series that slidestop holds the slide back on firing the last shot in the magazine. This slide stop feature was not available on the economical Challenger, Huntsman or Targetsman, however the slides could have been machined for it as they probably came off the same Woodsman production production line before the rear sight cuts were made.

The slide appears to be the same rounded top as the 1st series.All the rear sights used on these early 2nd series models were the Coltmaster.The front sights all were installed in a small silver-soldered on ramp, and the blades were retained by 2 small pins.

The grips were made of “Coltwood” a wood-grained mottled brown/yellow/black Bakelite.The Target and Match Targetutilized a thumbrest on the LH grip panel.The Sport version’s LH panel was plain. At some later date the grips went to injection molded brown plastic.

A unique feature of the 2nd series Woodsman is the provision for a grip adapter on the back strap which was made of the same material as the grips. With few exceptions, each originally came with two grip adapters, a large and a small, and were secured by a single screw from the rear.

Now you may see some of the Sport versions with the standard ramp front sight base but a fixed rear sight and made from mid-1949 to mid-1950 only.

However these seem to be a the prototype and predecessor to the Challenger series. One Colt letter states this was issued to the military as a arctic survival pistol.

Although it is part of the Second Series, the Challenger model, (being a economy model) unlike the Woodsman, had a spring catch at the butt and a C suffix to the serial number.The Challenger was a economy model with fixed front and rear sights. These could have either the 4 ½” or 6” barrel, with the shorter barrel more common as these were promoted as a trappers sidearm.

Triggers were usually the curved for the Sport, Challenger and early Target, with the Match Target being grooved and more straight with a forward bend at the bottom. However on some of the early 2nd series you will see the less pronounced arc normally used on the Match Target of the same vintage found on some Targets or even Sport versions as seen in the photo above.

Colt Challenger, early version. Note the spring type butt style magazine latch, brown grips & fixed sights

Woodsman Second Series, Late (1953-1955)

In 1953 the slide had a center raised rib and a newAccro rear sight was used.This sight was inletted into the top of the slide’s rib, making for a rear sight of less upward protrusion giving it more protection. This is sometimes called the 2nd Series late version.

In the photo below you will notice the new style adjustable rear sight as used on the Target and Match Target guns. Also notice the thumb rest on the LH grip panel also used on the Target and Match Target guns and brown plastic grips.

Woodsman 2nd series, late Match Target. Note the new style Accro adjustable rear sight & slightly raised rib on slide

Woodsman Third Series (1955-1977)

The 3rd Series replaced the 2nd Series in mid 1955. The most obvious change was the replacement of the push button magazine release with a new style snap catch at the rear of the butt.If the magazine release is at the heel of the butt, AND the pistol has an S at the end of the serial number, it is a third series.

The trigger guard was made a bit larger, the grip adapters and lanyard ring were eliminated, and the trigger was reshaped.

The magazine safety, which was a feature of the 2nd series, was carried over to the 3rd series for a few months, and then was quietly dropped as the parts supply was depleted.

The sights stayed the same as the 2nd series except for the Match Target, which went to the new Elliason target style.Grips were originally injection molded black plastic, but they were otherwise identical to the late 2nd series brown plastic grips. In 1960, at about SN 189200-S, Colt switched to real walnut wood which were bulkier than the previous plastic.

The first 1001 Woodsmans of the 3rd series were assigned serial numbers from the end of the 2nd series serial number block, from 146138-S to 147138-S. The numbers then skipped to 160001-S and restarted.

Note in the RH photo below the new style magazine bottoms were made of a stamped metal that could be removed for cleaning.

The 2nd and 3rd series utilized a automatic slide stop. If the slide stop engages by itself and not ONLY when the last round is fired, in all probability the slide lock spring is either broken or badly bent and or out of position. The problem is usually the spring is not functioning and the lock is not being held down but slightly floats, which bounces around during recoil, intermittently bouncing up at the wrong time.

This spring is a bitch to get in place without pinching/bending it so it allows the lock to function freely. It is a FINE wire with a couple of coils in the middle that goes in a hole in the slide lock and with tails on both ends, one tail under the hex headed screw and it has to be installed so that tension holds the lock DOWN. It should only be activated UP on the last shot by the magazine thumbpiece. Pull the grips off and you should be able to see it in the hole, but all the rest is hid behind the stop body. If you take the screw off (do not pull it out), but try to keep it in position with the stop as you pull the unit out to the left and away from the gun. And be careful to not remove this on or near a carpet floor. The hard part is putting it back. What trick I do is to use a Dremel tool and grind a slight groove in the screw body, under the head for the spring tail to nestle in. This then allows the tail of the spring a place to be slightly retained in place as you insert the unit back in place and hopefully retains it there as you tighten the screw. You probably will have to do this numerous times to get the tail from not being slid/locked under the larger screw body shank.

Woodsman 3rd series, Target. Note the new style butt pivoting magazine latchMagazine latched in

The 2nd series Challenger was replaced with the very similar model called the Huntsman but continued with the Challenger C suffix serial numbers.Word was, that there was a model name confusion between the Browning Challenger 22 pistol also on the market at that time, and the Colt’s pistol of the same name, so Colt changed their name to Huntsman.

These more economical guns did not have the automatic slide stop as did the 'Woodsmans' of the same vintage.

Colt Huntsman Note the fixed sights & new style pivoting butt magazine latch & no slide stop

The Targetsman which came into being in 1959 was a just a 6' barreled Huntsman with a economy fragile adjustable rear sight, also using the C suffix serial numbers.

Colt Targetsman. Note the economy fragile style rear adjustable sight

Some of the internal parts interchanged from the early (even pre-war) models clear into the last versions, these being hammers, hammer plunger, sear and sear spring and trigger bar.

There are more changes that could be added to this list, depending on how far one wishes to go with the collection, and on which features the collector considers significant.An engineering or design change might be an important variation to one person, and an insignificant item of little interest to another who just wants a pistol for plinking or packing on a hunting trip. With the many overlapping changes that took place over the span of years, the possibilities for the collector are almost endless.

Post War Serial Numbers ; All three post-WWII type Woodsmans: Sport, Target and Match Target, both Second and Third Series, have an S suffix to the serial number. The Challenger has a -C suffix. The Huntsman (third series) replaced the nearly identical Challenger when the third series was introduced in 1955. The Targetsman, which is basically a slightly upgraded 6' Huntsman, was added to the line in 1959. The Huntsman and Targetsman both continued with the Challenger serial numbers (-C suffix) until 1969, when the serial numbers of all S frame models then in production: the Woodsman Sport, Woodsman Target, Woodsman Match Target, Huntsman, and Targetsman were integrated and restarted at serial number 001001S.

You may encounter zero prefixes which confuse many Woodsman owners who ignore the zeroes and think they have an early, low serial number gun. The zero prefix serial numbers caused another problem when the serial numbers beginning with 001000S reached 099999S and rolled over to 100000S because serial numbers in that range had already been used in 1951-52 and began repeating themselves. When the error was discovered 1336 guns had already been serial numbered, so they were hand stamped with a S prefix creating the 'Double S' prefix/suffix serial number.

This series of pistols were made in the excess of 690,000 firearms being sold during their production life of 62 years ending in 1977.

For a link to a factory Woodsman takedown instructions CLICK HEREThis is copied off Bob Rayburn's Colt 22 website.

Magazines ; The pre-WWII magazines were two-toned until about 1939 or 1940. After that they were solid blue, but otherwise identical to the previous version. The factory parts replacement magazines are ALSO solid blue, but the floor plate on them is marked differently. These pre-war guns used a magazine with a magazine follower that had a raised section at the rear, which upon the last round being fired, this upward protrusion acted as a slide stop.

Here is shown a pre-war series Woodsman two-toned magazine Here is shown the slide stop provision of the follower

The later (post war) magazines were all the same, (as seen below) but different. The Second and Third Series (ALL VARIATIONS) used a magazine latch similar to the Colt 1911s, requiring a upper retainer notch. The Challenger and Huntsman also used this same magazine, however they utilized a rear bottom frame mounted latch. The factory simply supplied the same Woodsman magazine for both (where the Challenger and Huntsmans latch used the bottom rear as a retainer disregarding the upper Woodsman latch notch.) When the supply of these notched magazines ran out, the next batch did not have the retainer notch of the earlier versions. The design was slightly different (simplified) but they fit and operated the same.

Colt Woodsman Serial Number Dates

Here is shown a 2nd/3rd series Woodsman magazine with a caliper measuring the notch location to the TOP of the retainer notch

The later Cadet and Colt 22 used the same magazine as the later non notched 3rd series magazine, however they were usually made of stainless steel.

If you have a 2nd or 3rd series gun and need a magazine, any of the Challenger and Huntsman or Cadet and Colt 22 magazine can be altered buy cutting a retainer notch at the proper location. This notch location is CRITICAL to proper feeding. The factory notch is .087' wide and measured from the very inside corner where the bottom

joins the body 3.155' to the TOP of the notch as seen in the photo above. This can be cut by using toolmakers Layout die, scribing the lines in this colored die for guidance, then using a Dremel tool with a cut-off stone and CAREFULLY make the notch. It may be best to cut the top cut a bit lower and use the trial and error method of lockup as you do not want a lot of up/down slop, however you need ENOUGH to have the latch engage freely. The lower side of the notch is not really critical, EXCEPT if it is overly wide, then more debris can accumulate inside.

This notch

does not be very deep

(.075') or about .293' measured from the bottom of the notch to the opposite side. If the cut is made flat with the box, the overall width will be about .243'.

It is best to grind this notch with ammo in the magazine and to where your depth comes close, but does not normally touch the bullet. The reason for this is the follower coil spring

rides in this rounded groove and you could very easily cut (ruining) this spring if it was fully UP, with no ammo in the magazine.

Copies ; These guns, like many successful firearms after patent rights ran out, were copied. There was one made in South America

by the name of something similar to Gaucho.

Iver Johnson made another copy calling theirs the Trailsmen but made in 1985-1986 with only 1990 guns produced. Now Comes My Association With the Colt Woodsman. As a young man in high school, I ran a trap line EARLY mornings and week-ends during the winter. I had saved enough money doing farm jobs during the summer and convinced my mother to purchase me a 22 pistol. Which happened to be a used H&R model 922, with a 6' barrel. This was the older version without multiple extraction, you had to use the cylinder base pin to push out each fired case. I literally wore this gun out, even sent it back to the factory once, I later wore/chipped the ratchet on the cylinder, so I soft soldered a gob of solder on the missing section, and with my pocket knife whittled it down so the cylinder rotated and was timed correctly. When it wore down again, I just redid the solder job. I got very good at shooting tree leaves and specks of foam floating down the nearby creek in the winter time. And during the summer, if I hung a spinner on a alder limb across the creek while fishing for cutthroat trout, would pull the line tight and shoot the limb off to get my spinner back.

After I got out of school and got a job in the woods, I bought my own Christmas present, a used 1953 Colt Woodsman Target on December 21, 1956 for $47.50. I remember this price as it was $10.00 more than Ruger was selling their new Standard model 22 automatic pistols for at the time. I still have the bill of sale (somewhere). Matter of fact a number of years ago, I mentioned to my wife 'Happy anniversary of our first date'. She asked how could I remember that, 'easy I had just bought my first Colt Woodsman that day', (not what she wanted to hear by the way).

When I turned 21, I got my first Concealed Weapons Permit and that pistol was a constant companion to me, riding in a Nelson shoulder holster for MANY years. I could not begin to count how many ruffled grouse that pistol has accounted for. Or how many deer it has finished off, not to mention the one or two it got all on it's own. It even finished off a bull elk once and killed numerous slaughtered beef cattle with it. Or the pigeon who's head was shot off while sitting on the top of a barn roof with it. And possibly even a few salmon in the fall, not to mention those ferocious soda cans.

My parents lived near a creek that had a footbridge crossing it leading to the barn. In the winter when the water was up, I shot many floating alder leaves and specks of foam moving with the current from this bridge with this pistol. And you will be surprised on how good a person can get at instinctive shooting (from the hip) like this when you can see the bullet impact in the water.

From this association, after becoming a full time gunsmith and being more closely associated with firearms, I began acquiring more of these little beauties. Before long I found some that were not listed in any of the reference books available at that time. This intrigued me, so if I could not buy one of these different versions, I would at least make notes as to the differences and serial numbers. Through my business and attending Washington Arms Collectors monthly meetings, I became acquainted with a man who was collecting Winchester 22 pump rifles. He also had a few Colt Woodsmans, so we started comparing notes. This man was Major Robert Rayburn.

Bob soon became more interested in the Colts than the Winchesters, sold the rifles off and we both pursued collecting Colts. I went for all Colt automatics, while Bob stayed with just the Woodsmans. We compared notes for a good many years, gaining insight to these pistols. We had both put together very good Colt collections. I did some competitive indoor 22 pistol shooting for a while until my eyesight deteriorated to where I needed cataract surgery. And yes, I shot a Colt Match Target model.

At that time

, the property I owned was just under 3 acres and I was leasing another 4 + acres. I was raising riding/pack horses for my son and I for our elk hunting trips into high primitive country on the Cascade Mountain range. I had made mention to the owner of this leased property, if he ever decided to sell, I wanted 1st chance. Well he finally offered it to me. But I had boxed myself into a corner then and needed this property as I had built a larger barn on my property for the horses. But I did not have the

finances to purchase the other property at that time. The only tangible thing I was somewhat willing to part with was my Colt collection

. This was a hard decision, but for those of you who may also have a collection of any kind, how do you store it safely, take care of it, much less who do you even consider showing it to? As someone may mention your name at the wrong time or place and it could get repeated in the presence of a thief or his friends.

And it was a investment (sort of), and so would be that land. I made a deal with the land owner and started selling off

my Colt collection. It was split up, and Bob bought all the Woodsmans, where the centerfire guns went to another collector in Portland OR. Bob cherry picked out the guns I had, with what he didn't have, or upgraded his with mine and sold/traded the others. Before long he accumulated one of the best Colt Woodsman collections in the world.

Bob expanded his knowledge, displayed his collection at national conventions and wrote magazine articles. He even wrote books giving explicit information not previously published. He put together a websitehttp://www.colt22.com/ Some of his data was acquired from visiting the Colt factory achieves. On his website he has photos of the most frequent problem of reassembling this pistol.

When I sold my collection, the one pistol that did not go was my original Woodsman. It had by then been transformed into a Sport version by shortening the barrel to 4 1/2', reinstalling the front sight ramp and replacing the front target blade with a sport blade. Many may ask if a longer barrel is more accurate. From my experience, I did not notice any difference, other than ease of carrying.

To carry on part of the Colt Woodsman tradition, after selling my collection, I purchased another well used one, cleaned and reblued it, then and gave it to my oldest grandson when he turned 21.

Then

along the way, I acquired another Sport Woodsman of the same vintage, but this one had rested in a watery highway ditch for many years before someone found it and turned it into law enforcement, from whom I later traded repair work for. This gem was so rusty that I filled a gallon glass pickle jar with rust remover, (I suspect it was Phosphoric Acid). This did such a good job of removing the rust that even all the screws and small springs were salvaged, however I did replace the recoil and hammer spring. I lined the barrel with a rifled liner and found a set of used grips from a later series at a gun show. This pistol may usually be found in my hunting or fishing backpack. It is so ugly that no one would want to steal it, but it now shoots just as good as my old standby.

Then

as I got older (much older), I began disposing of many of my other accumulated guns. This original to me and my very good friend Woodsman, now has a home in my nephew's gun vault.

Colt Woodsman Serial Numbers

To save time and frustration, on both your and my parts, you might consider to also look at this article of mine giving an illustrated drawing of this gun if you need help getting it back together,CLICK HERE.

Over the years if you look long enough, irregularities may appear on any mass produced firearm. This could also be the case with these Colts. Probably top of the list could be miss-stamped parts including barrels, slides or even frames. These would not be considered rare, but more in the category of abnormalities. You can also see guns with parts being changed somewhere during it's previous life, (and usually not done at the factory) this would include grips, barrels, or sights. Gunsmiths can be ingenious at times.

Colt Woodsman Serial Number Lookup
