#Extruded Heatsinks

[dhaatufabex]

Aluminum heat sink manufacturers produce high-quality heat sinks that efficiently dissipate heat from electronic components. Utilizing advanced techniques and durable aluminum materials, they create lightweight and custom designs for various industries, including electronics and automotive. Their focus on superior thermal conductivity ensures the reliability and longevity of electronic devices. For More Details Visit Us.

[ryuuka-balaen]

alright! I promised it sorta earlier, so here it is; Ender3 V2 FDM printer disassembly for repair.

this is what a not, disassembled hot end looks like. it's got it's fan hood on and while it's a little dusty it's lookin good. not workin good tho so let's see what's goin on inside the hood.

first; how I know that there's a problem. the print stopped midway because the extruder gear (that brass gear there that pushes the plastic filament into the machine) chewed through the filament strand trying to push it because the filament would not go in

this normally means a clog of some sort, so with the removal of one screw, the fan hood comes easily off

heeere we goo! there's some internals. so at the very bottom you can see the tip of the brass nozzle, most of which is covered together with the heating block by a silicon sock, above that is the red heatsink, and you can see the Bowden tube that feeds the filament in coming out the top. don't worry about that disconnected wire there that's just the grounding wire that I forgot to reattach last time.

got the silicon sock off, and... it's hard to see but on the top of the nozzle there there's a sorta blotch. that's plastic that's oozed out through the threading. that's not good, so the nozzle comes off

little bit of discolouration on the top of the nozzle that's fine, but on the threads and feed end of it we can see a good deal of grey plastic. less fine, but not enough to cause a clog, so next I'll need to remove the heating block

which, ah... well. there's the problem. so at the bottom of that is the heating block, screwed into the feed tube of the heatsink, which has been pulled up the bowden tube when I tried to remove the tube, because. well. that tube is in there good. melted right in. right fucked.

heating block unscrews with a small effort, it's dirty and will need a cleaning too, but. we know that's not the issue.

ah damn. only 10 photos per post on mobile. more to follow.

[ledheatsink]

Efficient Heat Dissipation for Brighter, Longer-Lasting LEDs

Maximize your LED lighting performance with our high-quality aluminum heatsinks.

Designed for optimal thermal conductivity, our heatsinks ensure reliable cooling, reduce light decay, and extend the lifespan of your LED systems.

1. Precision-extruded aluminum for excellent heat transfer 2. Ideal for street lights, flood lights, high bays, and panel lights 3. Lightweight, corrosion-resistant, and eco-friendly 4. Custom sizes and finishes available

Keep your lights cool. Keep your performance high.

Shanghai Glary www.glarysh.com WhatsApp: +86 13501781413

[hetaijingjiang]

Extruded Aluminum alloy Energy storage heatsink housing

The Extruded Aluminum alloy Energy storage heatsink housing is a extraordinary product designed to offer efficient cooling and safety to energy storage systems.

Made from durable extruded aluminum alloy, this heatsink housing gives wonderful thermal conductivity, taking into consideration the efficient dissipation of heat generated in the course of electricity storage operations. Its sturdy creation ensures sturdiness and long-lasting overall performance, making it suitable for traumatic commercial applications.

The housing features a sleek, contemporary layout that now not most effective enhances the cultured appeal but additionally optimizes warmth dissipation. The extruded profile offers a large surface area, which enables rapid warmness switch, preventing overheating and ensuring the most useful functioning of energy storage systems.

With its precision engineering, the heatsink housing correctly comprises specific forms of energy storage devices, which include batteries or capacitors, presenting a steady and nicely-ventilated surroundings. It is also equipped with various mounting options, taking into consideration easy set up and integration into existing systems.

Furthermore, this heatsink housing boasts advanced safety in opposition to outside environmental factors, including dirt, moisture, and physical impact. It correctly shields the touchy internal components of strength garage systems, making sure their reliable operation and prolonging their lifespan.

[govindhtech]

ADATA Legend 970 PRO And SC720 Outstanding Performance

The Compact Power to ADATA Legend 970 PRO and SC720 External SSD Win Two Good Design Awards and Provide Unprecedented Speed in Small Form Factors.

The top memory module and flash memory company in the world, ADATA Technology, today revealed two winners of the Japan Institute of Design Promotion’s 2024 Good Design Awards. In addition to winning honors for product design, the ADATA LEGEND 970 PRO PCIe Gen5 SSD and SC720 External SSD provide previously unheard-of speed and performance in a very compact chassis. The SC720 is the smallest external SSD available today, and the elegant ADATA Legend 970 PRO can be installed into smaller PC configurations without affecting other components.

LEGEND 970 PRO PCIe Gen5 SSD

Express Creativity Like Never Before

The ADATA LEGEND 970 PRO supports the most recent AMD and Intel platforms and adheres to the NVMe 2.0 standard by using the most recent PCIe Gen5 x4 communication interface. It creates graphics or animation with never-before-seen ease.

Unlimited Performance

How long does it take for a file to load? At a sequential read/write speed of 14,000/11,000 MB per second, the ADATA LEGEND 970 PRO is eight times faster than typical Gen3 SSDs and twice the performance of PCIe Gen4 SSDs. Both PCIe 4.0 and 3.0 systems are completely backward compatible with it. Finish each activity in a few of seconds!

Active Cooling Makes Creation a Snap

Image Credit To ADATA

Does your computer’s performance slow as a result of overheating? A heatsink shaped like a double-layer extruded aluminum fin is used by the ADATA LEGEND 970 PRO! After separating hot from cold air, this hollow air duct accelerates heat discharge with an integrated micro fan. When compared to fanless heat sinks, this special “active cooling” drastically lowers drive temperature by up to 20%. Your system runs smoothly with to air conditioning!

Do More with Less Hassle

Image Credit To ADATA

Complicated installations are a real pain, and cable management is a pain! An separate power connection is not needed for the ADATA LEGEND 970 PRO‘s built-in fan, and the SSD is operational as soon as it is inserted into the M.2 slot. The best answer is to simplify complexity.

QuiKTIPS: The secret to consistent performance is active cooling

Why is active cooling necessary? Standard heatsinks can no longer adequately dissipate the heat produced by high-speed PCIe 5.0 transmission, and excessive temperatures will impact data reading and writing speeds. Moreover, unchecked heat will cause the system to malfunction in a matter of seconds. Several thermal models have been used to examine and improve the active heat dissipation of the ADATA LEGEND 970 PRO. Even while running at maximum speed for extended periods of time, it can tolerate a high temperature environment while still performing steadily.

QuiKTIPS: Analysis of active cooling operations

What is the process of active cooling? Active cooling transfers heat from the SSD upward to double-layered aluminum fins utilizing a metal heat dissipater and a heat spreader that is firmly bonded. Cold air is drawn from the nameplate’s apertures by an integrated fan and sent into the top section of the aluminum fins. Hot and cold air collide as hot air rises and cold air descends, and the fan’s spin swiftly removes the heat from the aluminum fins’ two sides. When compared to fanless heatsinks, this design offers better heat dissipation.

Superior Chips Overcome Large Files

The ADATA LEGEND 970 PRO has an ultra-large capacity of up to 4TB with to carefully chosen 232-layer 3D TLC NAND flash memory, and the SSD employs a range of data security and error correction algorithms to significantly increase TBW (Total Bytes Written) and endurance to satisfy high load needs.

Above and Beyond Excellence

Image Credit To ADATA

The ADATA LEGEND 970 PRO has a DRAM cache buffer and the SLC caching method. Up to 1,800K/1,300K IOPS may be achieved with 4K random read/write, increasing the effectiveness of multi-file processing. To guarantee data transfer accuracy and file security, the SSD additionally uses advanced encryption methods including TCG OPAL and the LDPC (Low Density Parity Check Code) error correcting technique.

Read more on govindhtech.com

[regretsretrotech]

The afters.

The mainboard got air blasted and scrubbed to knock loose dust that had accumulated. The CPU fan reminds me of a radiator fan on a car, and that's no accident, it's designed to keep the hot running Pentium 4 cool assisted by a massive extruded aluminum block of a heatsink. Fresh thermal paste and it's locked down. A fresh CR2032 battery for the CMOS/RTC is also installed.

The videocard needed more work than it appeared, the same thing that caused rust spots on the case seemed to have gotten on the card and wouldn't come off, needing it to be scrubbed in warm soapy water and hung up to dry! The GPU fan was cleaned and the heatsink air blasted, fresh paste and it was ready to go in.

The Soundblaster Audigy ZS2 it had unfortunately died and was replaced with a Soundblaster Live 5.1.

Something often lamented with older systems is how much of a pain the ribbon cables are, and they are right. Instead of just tossing the cables in at random and hoping for the best, I go one cable at a time. I fold the cable, and if I have to turn, I fold the cable at 45 degrees, making a crisp corner.

The floppy drive cable only has to connect to one drive so it's got the simplest path, the DVD drive is at the end of it's run, the cable folds and goes up, the opposite for the HDD. It creates a cluster of folded cables at the headers but those can be worked around as you'll see.

The next in is the power supply, this supply doesn't have the detachable cables and as you saw in the befores is an octopus of wiring. I tamed it with zip ties and bundling the cables together, inspired a bit by the wiring found in vastly more complicated machines. If I had lacing twine I would have probably laced the cables up instead, but zip ties work just the same here.

Installed is the fresh air duct and then the system is closed up. The second DVD drive is a place holder, the system doesn't need a second drive and the motherboard does not support SATA, I would need a bridge card with the option ROM installed to boot. (Apparently some SATA bridge cards expect the system to already know how to boot from SATA.) For this machine, UDMA 100 PATA is plenty fast.

Then signs of life POSTING with no OS installed and then finally, a fresh install of Windows XP Pro.

Specs for those that want them.

Motherboard: ASUS P4GE V w/845g chipset AGP/PCI

Processor: Pentium 4 @2.8 Ghz. 533Mhz FSB.

RAM: 2 GB DDR1

Video: ATI Radeon AG3850 w/512MB of VRAM on AGP 8x*

Sound: Creative Soundblaster Live 5.1

HDD: Seagate 160GB Barracuda

PSU: 700w Thermal Take

Case: LiteOn HT 761S

*AGP is weird and a rabbit hole if you fall into it, the board reports both 4x and 8x simultaneously.

Todo:

Games and software

If you have suggestions leave them in the comments

Long Term Todo:

Upgrades

CPU upgrade to K class or 3.2Ghz with 533 FSB. Max RAM to 4GB? SSD? On drive PATA to SATA? I have options here. Creative Soundblaster Audigy ZS2

[crypto-chronicles]

Hot End Heatsink Block For CR-10 Extruder Heat Sink Aluminum Tube 3D Printer GDB

Hot End Heatsink Block For CR-10 Extruder Heat Sink Aluminum Tube 3D Printer GDB Price : 29.94 – 27.84 Ends on : View on eBay

[mipsourcing]

3.24"×1.61" wide aluminum extruded heatsink for led street light

-width: 3.24" -height: 1.61" -precise length: 39.5" -weight: 6.50lb... -material: AL6063-T5 -secondary processes: CNC machined, drilling holes, tapping, milling, turning, etc. -surface: color anodized, powder coating, sand blasting, matte, etc. -any customized designs are supported.

Please contact sales@mipindustry.com if you have any questions. Please view more designs on mipindustry.com.

[formlab]

Extruded Heatsink

[dhaatufabex]

Elevate Your Thermal Solutions with Dhaatufabex’s Custom Heatsink Extrusions

Since aluminum is lightweight, strong, and durable, it is a popular choice for a variety of industries, including the electronics and electrical industries. This makes aluminum a suitable material for a wide range of applications. Here at Dhaatufabex, as the top manufacturers of aluminum heat sinks in the business, we set the bar for perfection. Their higher-quality products are carefully and accurately manufactured to guarantee the best potential heat dissipation for electronic devices. For durable and effective cooling solutions, trust Dhaatufabex. Their heat sinks are expertly designed to maximize heat dissipation, ensuring that electronic equipment work at their best.

Unmatched Quality and Performance

Our aluminum heat sinks at Dhaatufabex are designed with the best thermal management in consideration. We create heat sinks that effectively dissipate heat, improving the functionality and durability of electrical gadgets, using advanced manufacturing processes and premium aluminum. Highest standards have been met in the design of our products, assuring dependability and efficiency in an array of applications.

Precision Engineering

Every heat sink that we manufacture is crafted using precision engineering techniques by our team of experts. Our goal is to provide heat sinks with superior thermal conductivity and constant cooling through the whole production process. Our heat sinks are perfect for high-performance electronics because of their careful attention to detail, which guarantees that they will meet strict thermal requirements.

Custom Solutions

Understanding that different applications have unique cooling needs, Dhaatufabex offers customized heat sink solutions. Our flexible manufacturing capabilities allow us to produce heat sinks in various shapes, sizes, and configurations to meet specific customer requirements. Whether you need standard designs or bespoke solutions, we are equipped to deliver products that match your exact specifications

Applications of Heat Sinks

Heat sinks are crucial components used in various electronic and mechanical systems to manage and dissipate heat, ensuring optimal performance and longevity. Here’s an overview of their key applications:

Electronics Cooling- Heat sinks are most commonly used in electronics to prevent overheating of components such as CPUs, GPUs, and power transistors. By transferring excess heat away from these components, heat sinks maintain stable operating temperatures, which helps prevent thermal damage, improve performance, and extend the lifespan of electronic devices. In computers, heat sinks are typically attached to processors and graphics cards to ensure efficient cooling.

LED Lighting-   In LED lighting systems, heat sinks play a vital role in managing the heat generated by LEDs. LEDs are sensitive to high temperatures, which can reduce their brightness and lifespan. Heat sinks are used to absorb and dissipate this heat, ensuring that LEDs operate efficiently and have a longer service life.

Consumer Electronics- In consumer electronics, heat sinks are used in devices such as smartphones, tablets, and home appliances. They help manage the heat generated by processors and other components, ensuring that these devices operate efficiently and comfortably for the user.

Automotive Industry-Heat sinks are employed in the automotive industry to manage heat in various components, including engine control units (ECUs), power electronics, and lighting systems. They help maintain optimal operating temperatures for these critical components, enhancing performance, reliability, and safety. For example, heat sinks in electric vehicles manage the heat generated by battery packs and electronic control systems.

Aerospace and Defense-In aerospace and defense applications, heat sinks are used to manage the thermal loads of sensitive electronics and avionics systems. They ensure that high-performance equipment, such as radar systems and communication devices, remains within safe temperature limits despite operating in challenging environments.

Conclusion

Heat sinks are essential in a wide range of applications where managing heat is critical to performance and reliability. From electronics and LED lighting to automotive and industrial systems, heat sinks play a vital role in ensuring that components operate within their optimal temperature ranges, thereby enhancing their functionality and lifespan.

Explore our range of aluminum heat sinks and experience the excellence that makes Dhaatufabex the best in the industry. Contact us today to discuss your needs and discover how our heat sink solutions can enhance your technology.

For more details visit :  https://www.dhaatufabex.com/

[ledheatsink]

Aluminum Heatsink for led lighting Efficient Cooling. Extended Lifespan. Superior Performance.

Upgrade your LED lighting solutions with our high-performance aluminum heatsinks, engineered to deliver exceptional thermal management in demanding lighting applications. Whether you're designing street lights, high bays, flood lights, or industrial LED fixtures, our heatsinks are optimized for maximum heat dissipation, minimal weight, and long-term reliability.

1. High Thermal Conductivity Made from premium-grade aluminum (6063-T5 or 1070), ensuring rapid heat transfer and consistent cooling performance. 2. Custom Fin Designs Optimized fin structures - extruded or CNC-machined - to increase surface area and airflow efficiency. 3. Corrosion Resistance Anodized or powder-coated finishes provide excellent protection for outdoor and industrial environments. 4. Lightweight & Strong Aluminum’s superior strength-to-weight ratio helps reduce fixture weight without compromising durability. 5. Precision Machining & Customization Custom hole drilling, mounting features, and size options available to fit your LED board layout and fixture design.

Shanghai Glary www.glarysh.com

[myheatscape-blog]

Extruded aluminum heatsinks are an effective way to cool heat producing components in a cost effective manner. 318 Digital Drive Morgan Hill CA 95037

[fenan-aluminum-foen]

Fenan aluminum aluminum extrusion die workshop

Fenan(FOEN) aluminum -aluminum extrusion molds production and maintenance onsite on our own

Compared with steel and copper, aluminum profiles are quite different. Because aluminum has low hardness and good deformability, it is suitable for extrusion production. Aluminum alloys are also one of the few alloys that can be extruded. The cost of extrusion molds for aluminum profiles is low, so many customers are willing to open molds for customization.

Aluminum profile molds are divided into flat molds(solid die) and split molds(hollow die-porthole die), and there is also an integral mold for extrusion production of seamless pipes, which is relatively rare. Today we focus on the flat molds(solid die) and split molds(hollow die-porthole die). The flat molds(solid die) is used for profiles without a cavity, and the split molds(hollow die-porthole die) is used for profiles with a cavity. The split molds(hollow die-porthole die) is composed of two upper and lower molds, so the price is more expensive.

The larger the section, the larger the profile mold. The material of the aluminum profile mold is generally H13 steel. The larger the mold, the higher the price. That is to say, the larger the cross-section of the aluminum profile mold, the higher the price.

The cross section of the aluminum profile has a very simple square tube or round tube, as well as a complex radiator or multi-cavity profile. Although they all use a split molds(hollow die-porthole die), the development cost of the die is different. The more complex the cross-section of the mold, the higher the cost.

The above is a brief introduction to the aluminum profile mold, I hope the content in the article can help you.

We,Fenan(FOEN) aluminum has a professional mold production and maintenance team, which can quickly and accurately produce the extrusion molds required by customers for the production of their aluminum profiles.

Hope we can cooperate with each other regarding the extrusion aluminum.

#aluminiummanufacturing #aluminiumprofilesupplier #profilealuminum #aluminiumwindows #aluminiumdoor #aluminumpergola #aluminumtube #aluminumextrusion #slidingdoor #bifolddoors #anodizingaluminum #aluminiumframe #extrusionaluminumprofiles #aluminumprofilemanufacturer #solarmounting #aluminumpipe #aluminumslidingdoors #aluminumstrip #aluminiumbox #heatsink #perfilesdealuminio #solarcarportsystem #aluminiumledprofile #aluminumfoldingdoors #fenanaluminum #foenaluminum
