[leiditechelectonicpublishing]

Bring it back for scanning TVS advantage

Shanghai leiditech is helping customers with the rectification process，Often encountering clientsDC-DC (such as：TOLL TMI3494）Easy to be penetrated by surges，perhapsIC Easy to be broken down by static electricity。In selectingESD andTVStime，I found that only the ones I brought back for scanningESD andTVSTo meet certain needscircuit boardProtection requirements。

Shanghai leiditech R&D has launched a series of back to back scanning functionsESD andTVS ，For customers to choose from。The following curve chart and product details table Please refer to：

routine ESD Characteristic curve chart

1.Bring it back for scanning ESD The biggest feature is that when the voltage reachesVTAfter triggering the voltage，InstantlyESDThe clamping voltage at both ends is pulled down to the working voltageVRWMAnd trigger voltageVTBetween 1，This voltage is calledVh，Afterwards, as the current increases, the voltage gradually increases。

2.routineESDThe voltage varies withIPPAn increase in proportion to an increase in。

3.Bring it back for scanningESD advantage：

3.1 in the same wayIPPIn the case of，VCClamp voltage is higher than conventionalESDDevice low 30%more than，Achieve early release of energy，Greatly protectedICEven the safety of the entire circuit，Effectively reducing residual voltage in the backend。

3.2 HigherESDProtection level：Having better performanceESDProtection level，Capable of withstanding higher temperaturesESDVoltage pulse。

3.3 Lower leakage current：Has lower leakage current，Can achieve more energy-efficient designs。

Part Number ESD per IEC61000–4–2 (Air)/(Contact) “Vrwm

(V)” Vb(V） Vc（V)@1A VCmax@A Ir(uA) C(PF) Package Do you want to bring it back for scanning

ULC0321S ±25kV/±20kV 3.3 6.3 5.5 15V@5A 0.1 0.2 DFN0603 Bring it back for scanningESD

ULC0521CDN ±25kV/±20kV 5 8 5 6V@5A 0.2 1 DFN0603 Bring it back for scanningESD

ESD0521C ±25kV/±22kV 5 6 8 12V@3.5A 0.2 5 DFN0603 ordinaryESD

ULC0322P10LV ±30kV/±30kV 3.3 3.5 4 5V@10A 0.2 0.6 DFN0603 Bring it back for scanningESD

ESD3321C ±30kV/±30kV 3.3 3.8 6 10V@8A 0.01 25 DFN0603 ordinaryESD

ULC2421CS ±15kV/±15kV 24 30 4 6V@5A 0.2 0.5 DFN0603 Bring it back for scanningESD

ULC0342P26LV ±30kV/±30kV 3.3 3.5 6.5V@6A 10V@26A 0.5 1.5 DFN1006 Bring it back for scanningESD

ULC0542CDNH ±25kV/±20kV 5 8 5 6V@5A 0.2 0.5 DFN1006 Bring it back for scanningESD

ESDA05CP30 ±30kV/±30kV 5 6 7.5 12.5V@6A 0.5 15 DFN1006 ordinaryESD

ULC1811CDNH ±15kV/±15kV 18 22 4 6V@5A 0.2 0.5 DFN1006 Bring it back for scanningESD

ESDA05CP ±30kV/±30kV 5 6 8 8.5V@18A 0.5 25 DFN1006 Bring it back for scanningESD

ULC2442CS ±15kV/±15kV 24 30 4 6V@5A 0.2 0.5 DFN1006 Bring it back for scanningESD

ULC0342P ±30kV/±30kV 3.3 3.5 4 5V@10A 0.2 0.6 DFN1006 Bring it back for scanningESD

SDA3311DN ±30kV/±30kV 3.3 3.6 7.7@30A 9V@65A 0.5 120 DFN1006 Bring it back for scanningESD

SDA0301P ±30kV/±30kV 3.3 4 6 13V@16A 200 200 DFN1006 ordinaryESD

LC03CILVC ±30kV/±30kV 3.3 3.8 6 16V@25A 0.1 1 SOD-323 Bring it back for scanningESD

USSD0571P6W ±30kV/±30kV 5 6 7 11V@110A 1 350 DFN1610TN Bring it back for scanningESD

PUSB3FR4 ±15kV/±15kV 3.3 6 2.5 4V@7A 0.1 0.7/0.35 DFN2510P10 Bring it back for scanningESD

LM10S26CAT ±30kV/±30kV 26 28.9 ~ 31.9 24–27 300A 1 _ DO-218AB Bring it back for scanningTVS

LM10S28CAT ±30kV/±30kV 28 31.1 ~ 34.4 26–29 290A 1 _ DO-218AB Bring it back for scanningTVS

SM8S28CA ±30kV/±30kV 28 31.1 ~ 34.4 45.4 145A 5 _ DO-218AB ordinaryTVS

ShanghaiLei Mao ElectronicsTechnology Co., Ltd，Established in 2011，brandLeiditech，It is a national high-tech enterprise。The company’s R&D team consists of Dr. Liu from the United States andTIEstablishment of the original development manager，With a skilled R&D team and experienced electromagnetic compatibility industry experts，Mainly providing anti-static measuresTVS/ESDAnd relatedEMCcomponent（Discharge tubeTSS/GDT、Stabilizing tubeZENER、VaristorMOV、rectificationdiodeRECTIFIER、Self recovery fusePPTC、Field-effect transistorMOSFET、inductance）。

LeiditecharoundEMCEMC service customers，Self built free laboratory for testing static electricity for customersESD（30KV）、Group pulseEFT(4KV)、surge（8/20，10/700 10/1000）、Car load shedding（7637 5a/5b）Performance testing of components, etc。LeiditechKeeping up with the pulse of domestic and international technological updates，Continuously innovatingEMCProtection scheme and related devices，Target direction is small packaging，High power，Provide reliable solutions and components for domestic substitution。

Table information：

Product Information：Information of ESD

Electrostatic Discharged Protection Devices, referred to as ESD. It is mainly used to protect the Electrostatic Discharge of communication interface .

The reason of Electrostatic Discharge：

a. Two substances via the contact friction and loss of electrons or the electron, the charge band (no flow) termed static;

b. Due to switch electricity or lightning induced surge also indirect causes static electricity;

c. Temperature and humidity affect the turboelectric charged, at less than 45℃, it will produce higher humidity greater voltage more than in 55℃, damaging also relatively large.

The selection tips of ESD

1. The Vrwm is bigger or equal to the circuit working voltage is better;

2. The Cp of ESD is confirmed by the rate of data port, the data transfer more faster ,the Cp of ESD should be more smaller;

3. Selecting suitable Ipp for your circuit, the suitable Vc for your circuit and power=Ipp*Vc*power factor;

4. According to the PCB to select package (1-channel or multi-channels).

If you’d like to learn more or have any questions, don’t hesitate to reach out:

[sales16@leiditech.com]

Visit us at [en.leiditech.com]
