Business in the front, party in the back. Yes, I'm leaving the button like that. It's fine.
This is a Qualcomm Quickcharge Trigger, based loosely on this design, but only rigged for 12V.
When you press the button, it negotiates up from 5V to 12V from any QC 2.0 compatible charger.
Why? The 12V supply that runs my desk is a noisy, cheap pile of garbage that whines at 18kHz all the time, and my hearing is still good enough to hear that all goddamn night. Finding quiet 12V supplies that don't develop inscrutable hums a few months down the line is a crapshoot. On the other hand, cellphone chargers are usually impossibly quiet. I have a loose QC phone charger that I don't need for anything else, so if I can convince it to pump out 12V I can use that to run my desk. Hence, this pile of junk.
Tested and working, all I have to do is press the button to get it to put out 12V. Eventually I might get a 9V zener diode and an LED and set up an indicator that tells me if it's in 12V mode, but for now I'll lean on the fact that I built it and I know how it works.
This is NOT fully wired correctly, as in if you plug the USB cable in upside down it will not trigger correctly. Fixing this is not too hard but would require me to fuck around with the protoboard more than I already have and dealing with protoboard is miserable. I'll just put some alignment markers on the cable I'm using I guess.
I'll have to sit later with a hacksaw and cut this section of protoboard out. Bleh. Building a case for things like this is what makes me wish I had a 3D printer. The exposed pins on the bottom are a short risk so this will get a chunk of cardboard two-way taped to the bottom.
If you ever get a chance to stock up on industry standard barrel jacks, do it, I use these things everywhere.
Quickcharge is a dying protocol, being replaced almost wholly by USB-PD, but USB-PD requires putting an actual microcontroller in the mix whereas this can be done fully analogue, and I believe that even QC 3.0 is still simple enough that a human with some buttons and a few resistor ladders could query basically any voltage it can supply (which is many)
71 notes
·
View notes
Today is Not About 5G! Today is About 6G Technology? Really? "YES"
I know we are not still over with 5G technology! Now Immensphere is discussing 6G technology? Yes, it is about 6G technology today!
Okay! lets us go into the detail.
If you live in a country like India, Russia, or Mexico, you must be thinking, we haven’t even seen 5G yet, and you are talking about an overview of 6G technology.
Yes, that is because 72 countries, such as South Korea, the USA, China and Japan, had already launched 5G back in 2019, and now the world is headed towards 6G, the next decade’s technology.
The upgradation in technology from 5G to 6G will be much higher and faster than what we saw in the transition from 4G to 5G.
To understand better about 6G, We have discusse about 5G also.
So 5G vs 6G
Low latency
5G: 5 milliseconds.
6G: 1 microsecond.
Speed
5G: 40 Up to 1,100 Mbps.
6G: Up to 1 Tbps. (1,000,000 Mbps)
Spectrum
5G: 0.4 GHz and 114 GHz.
6G: 95 GHz to 3 THz.
Does 6G Exist?
Currently, 6G is in its initial research and development stage.
Leading telecom companies like Samsung and Qualcomm are working on it and have published research on 6G.
Next is 7G Technology?
What we know is very little about 7G and are only speculations compared to the previous networks while knowing little about the division for 6G.
But we know, when G's technologies will be launched.
5G Technology has been launched in 2020.
6G Technology will be launched in 2030.
7G Technology will be launched in 2040.
*according to reports.
Whatever G's Technology comes out, it will make things super fast, instant, and everything will be just available without a moment.
For now, Immensphere is signing off about 5G, 6G and 7G Technology!
Follow @immensphere for more content like this.
4 notes
·
View notes
Snapdragon X Plus Platform: Qualcomm’s Latest PC Weapon
Qualcomm’s addition of the Snapdragon X Plus Platform Continues to Upend the PC Industry
Qualcomm Oryon
The Qualcomm Oryon CPU, a specially integrated processor that offers up to 37% quicker CPU performance than rivals while using up to 54% less power, powers the Snapdragon X Plus. Users are able to do more tasks more effectively thanks to this incredible improvement in CPU performance, which raises the bar for mobile computing.
The Snapdragon X Plus, which is equipped with the fastest NPU for laptops in the world, the Qualcomm Hexagon NPU, which can achieve 45 TOPS, is also made to satisfy the demands of on-device AI-driven apps. This platform is poised to revolutionise the PC market and represents a major advancement in computer innovation.
The PC market is poised for a revolution because to the groundbreaking experiences offered by the Snapdragon X Series platforms. In this era of rapid research and deployment, the Snapdragon X Plus will power AI-Supercharged PCs that allow even more users to excel as radical new AI experiences emerge, according to Kedar Kondap, senior vice president and general manager of Qualcomm Technologies, Inc.’s computing and gaming division. “They are once again pushing the envelope of what is possible in mobile computing with our cutting-edge CPU performance, AI capabilities, and power efficiency.”
Qualcomm Technologies showcased new AI-optimized features and applications for the 45 TOPS NPU during the Snapdragon X Plus launch.
These included:Visual Studio’s code generation Code from Code gen uses on-device generative AI to help programmers by producing new code instantaneously.
Using Riffusion on-device AI, Audacity’s music generation feature creates new music based on prompts or previously recorded tracks.
Using Whisper on-device, live captions in OBS Studio can automatically translate 100 spoken languages into live captions in 100 languages in real-time during livestreams.
Beginning in mid-2024, OEMs are anticipated to release PCs running the Snapdragon X Plus alongside devices running the Snapdragon X Elite.
Snapdragon X Plus
Rethink the Possible
Utilize the new Snapdragon X Plus Platform to unleash the potential of a Next-Gen AI PC. With its incredible performance and efficiency, lightning-fast connection, and ground-breaking on-device AI, the Snapdragon X Plus transforms your digital experience on even more of your favorite devices. With day-long battery life and ultra-portable laptop designs, experience unmatched productivity.
Revolutionary Performance and Effectiveness
The performance of your laptop reaches new heights with this powerful processor. Because to the Snapdragon X Plus’s best-in-class 10-core Qualcomm Oryon CPU, users may optimize workloads for uninterrupted productivity. Reject lag with lightning-fast reaction. Presentations and enjoyment with a high graphic quality are provided by the integrated Qualcomm Adreno GPU. With a multi-day battery life, all of this capability is powered by incredibly efficient technology, allowing you to use it for longer periods of time between charges.
Designed with AI in mind
The upcoming generation of AI PCs is powered by the Snapdragon X Plus. With its premium integrated Qualcomm Hexagon NPU, it is outfitted with the industry-leading Qualcomm AI Engine (CPU, GPU, and NPU). The NPU is the fastest NPU available for laptops, with processing up to 45 TOPS. With significant power savings, use artificial intelligence (AI) on your device to bring your ideas and chores to life.
With the Snapdragon X Plus, you can take advantage of simple AI productivity solutions that streamline your processes, help you save time, and simplify multitasking. Upgrade your appearance and audio quality with the latest audio and camera features. With support for Windows Studio Effects and numerous other AI-accelerated programmes and experiences, the Qualcomm AI Engine offers a plethora of uses.
More Intelligent User Interfaces
The Snapdragon X Plus transforms how you use your laptop. Every action streaming, downloading, or syncing is more seamless, responsive, and interconnected. Maintain your connection while on the go with 5G and Wi-Fi 7 with HBS Multi-Link for blazingly quick and jitter-free connections from almost anywhere. With the Snapdragon Seamless experience, switching between your preferred devices is simple and doesn’t require a wire.
Wireless headphones can be used to enjoy lossless music and entertainment thanks to the immersive and high-fidelity audio experience provided by the Snapdragon Sound Technology Suite. With features including complete memory encryption, Microsoft Secured-core PC compatibility, and the Qualcomm Secure Processing Unit, which powers the Microsoft Peloton TPM, the Snapdragon X Plus helps keep your computer safe from chip to cloud.
Features
Top-tier CPU with exceptional performance and energy efficiency.
Offers remarkable energy savings and a battery life of many days.
Qualcomm AI Engine leads the industry with up to 45 TOPS AI performance.
Top-tier performance in terms of CPU, GPU, NPU, and Micro NPU processing.
Qualcomm Oryon Processor.
GPU Adreno.
NPU Hexagon.
Sensing Hub from Qualcomm
AI on-device for revolutionary intelligent experiences, with 30 tokens per second support for generative AI.
A top-notch integrated GPU produces amazing visuals performance.
With 5G and Wi-Fi 7 connectivity, you can download, stream, and synchronise data incredibly quickly.
HBS Multi-Link reduces latency and provides jitter-free entertainment.
Enterprise-level security to improve defence from the chip to the cloud Up to 4K HDR video streaming is supported with AV1 encode and decode support.
Enjoy high-fidelity music and entertainment with wireless headphones that offer immersive, lossless audio thanks to the Snapdragon Sound Technology Suite.
Up to three external UHD displays can be supported at 60 Hz, which results in smoother and faster display experiences.
LPDDR5x memory for effective multitasking and quicker AI experiences with 135 GB/s bandwidth.
Improved MIPI camera support for intelligent features and high-quality images with reduced power consumption, including background blur, auto-framing, and facial authentication.
Details
Processor
Qualcomm Oryon is the name.
Ten cores in all.
64-bit architecture
Maximum Clock Speed of 3.4 GHz
GPU
Adreno by Qualcomm
Up to 3.8 TFLOPS, or tera floating point operations per second
DirectX 12 APIs
NPU
Name: Hexagon Qualcomm
45 TOPS or tera operations per second
Recall
LPDDR5x in type
Bit Width: sixteen bits
Eight channels are available.
Rate of Transfer: 8448 MT/s
135 GB/s of bandwidth
Maximum capacity of 64 GB
Keepsake
SD: 3.0 SD
SSD/NVMe Interface: PCIe 4.0 x NVMe
UFS: Version 4.0
Technology and Process Node
Node of Process: 4 nm
Present
Qualcomm Adreno is the name of the display processing unit (DPU).
Maximum Resolution for On-Device Display: 120 Hz at 4K Ultra HD
Maximum Resolution for an External Display: 4K at 60 Hz
HDR10 is the High Dynamic Range (HDR).
31 concurrent displays are available.
Type of Interface: Display Port 1.42
VGA
The Qualcomm Adreno Video Processing Unit (VPU) is its name.
Resolution of Encoding: 4K at 60 Hz
Bit Depth of Encoding: 10-bit
Encoding Formats: H.264, AV1, and Others
Decoding resolution: 4K/120 Hz
Encoding Bit Depth: 10
Encoding Formats: H.264, AV1, and Others
Decoding resolution: 4K/120 Hz
Decoding Bit Depth: 10
Decoding formats: VP9, AV1, H.265 (HEVC), H.264.
Continuity: 4K decode: 60 Hz; 2K encode: 30 Hz
Snapshot
The image signal processor is Qualcomm Spectra.
ISPs, or dual image signal processors
ISP bit depth: 18 bits
36MP+36MP dual
A 64-megapixel camera
4K video capture
H.264 and H.265 are video capture formats.
Video Capture Features: HDR
Sound
Powered by Qualcomm Aqstic sound technology
Qualcomm audio technology include aptX.
RF Cellular Modem
Qualcomm Snapdragon X65 5G Modem
Top Download Speed: 10 Gbps
Upload Max: 3.5 Gbps
Cellular modem RF specifications: 1000 MHz (mm wave) and 300 MHz (sub-6 GHz) bandwidth.
Qualcomm AI-Enhanced Signal Boost adaptive antenna tuning, Qualcomm Smart Transmit, Qualcomm 5G Power Save, and Qualcomm Wideband Envelope Tracking improve performance.
Cellular technologies include LTE, WCDMA, CBRS, sub-6 GHz, 5G NR, HSPA, and mm Wave.
WiFi
Bluetooth and Wi-Fi system: Qualcomm Fast Connect 7800
Generation: 6E/7E, Wi-Fi 6.
Standards include 802.11b, 802.11g, 802.11n, 802.11ac, 802.11a, 802.11ax, and 802.11be.
2.4GHz, 5GHz, 6GHz
Up to 4 spatial streams
Maximum QAM: 4K
Mira cast, Voice-Enterprise, HBS, 8×8 Sounding, Target Wake Time, MLO, Pass point, TDLS, OFDMA (UL/DL), Wi-Fi Quos Management, MU-MIMO, Wi-Fi Optimised Connectivity, Wi-Fi Location
Bluetooth
Specification: Bluetooth 5.4
Connection technology is Bluetooth Low Energy.
USB Universal Serial Bus
Three USB-C ports
USB43 specification
Interfaces
Platform add-ons: WiFi, 5G
