Best GI/MS Bend Supplier & Manufacturer in Delhi – Quality, Stock & Fast Delivery

GI (Galvanized Iron) and MS (Mild Steel) bends are essential pipe fittings used to change the direction of flow in plumbing, water supply, fire fighting, HVAC, and industrial pipeline systems. The choice of the right bend supplier ensures strength, long life, perfect dimensions, and timely delivery.

This 1500-word article explores everything you need to know about GI/MS bends — their types, applications, price range, and why Udhhyog is considered the best bend manufacturer and supplier in Delhi.

What is a GI/MS Bend?

A bend is a pipe fitting used to change the direction of a pipeline, typically available in 45° and 90° angles. When made of GI or MS, they offer excellent corrosion resistance (GI) and mechanical strength (MS).

🔩 Key Features:

Strong weldable construction

Rust-resistant zinc coating (for GI)

Available in short-radius and long-radius bends

Conforms to IS standards and thickness grades

Types of Bends Available at Udhhyog

Bend TypeMaterialAngleSize RangeApplicationsGI Bend (Hot Dip)GI90°½" to 6"Water pipelines, residentialGI Bend (3 Layer)GI90°2" to 4"Fire systems, borewell outletsMS Welded BendMS45°, 90°½" to 10"Industrial gas, water & air linesMS Long Radius BendMS90°3" to 12"Oil & chemical pipelinesHeavy GI/MS ElbowGI/MS90°CustomFabrication, high-pressure lines

GI/MS Bend Price List – Delhi Market (2024)

Size (Inch)TypeThicknessApprox. Price (INR/pc)1"GI Bend 90°1.6 mm₹35 – ₹552"GI Bend 90°2.0 mm₹65 – ₹952"MS Bend 90°3.2 mm₹80 – ₹1103"MS Welded Bend3.6 mm₹150 – ₹1904"GI Long Bend2.5 mm₹200 – ₹2506"MS Elbow5 mm₹450 – ₹550

📥 Download full bend catalogue PDF: GI/MS Bends – Udhhyog

Why Udhhyog is the Best Bend Supplier in Delhi

🏭 In-House Manufacturing

Udhhyog manufactures MS bends with high-precision welding machines and offers hot-dip galvanized bends with rust-proof finish.

🧰 Wide Size Range Available

From ½ inch to 12 inch

Custom elbows, 3D & 5D bends available

Heavy-duty MS pipe bends for fabrication

🚚 Fast & Reliable Delivery

1–3 day delivery across Delhi NCR, Haryana, UP, Punjab, J&K

Strong packaging to avoid transit damage

🧾 100% Quality Guarantee

All GI/MS bends checked for dimension, finish & coating thickness

Supplied with test certificates on request

💰 Wholesale Rates + Bulk Discount

Direct from manufacturer pricing

Discounts on bulk orders and long-term projects

Applications of GI/MS Bends

🚿 Plumbing and residential water supply

🧯 Fire fighting pipelines

🛢️ Oil & gas transport pipelines

🌾 Agriculture and irrigation lines

�� Chemical and process industries

🏭 HVAC and ducting systems

Udhhyog’s Quality Control Process

Raw material cutting (IS-grade MS or GI)

Manual/automatic welding & angle precision

Surface finishing (hot-dip or spray coating)

Measurement and visual inspection

Packaging and labelling

Ordering from Udhhyog

📞 Call Us: +91-XXXXXXXXXX 🌐 Website: https://udhhyog.com 📥 Get Quotes: Contact Form 📦 Dispatch: Within 24–72 hours depending on location & quantity

Testimonials

⭐️⭐️⭐️⭐️⭐️ “Udhhyog’s GI bends are the most accurate we’ve received—perfect radius and no leaks.” – Plumbing Contractor, Delhi

⭐️⭐️⭐️⭐️⭐️ “Our fabrication unit orders only MS elbows from Udhhyog. Quality + delivery = excellent.” – OEM Supplier, Rajasthan

FAQs

Q1: Can I order bends with custom angles? A: Yes, we offer 22.5°, 30°, 45°, and 90° bends on order.

Q2: Do bends come with test certificates? A: Yes, TC and thickness reports are provided for bulk orders.

Q3: What’s the difference between GI and MS bend? A: GI bends are coated with zinc for rust protection, MS bends are plain steel used in heavier-duty systems.

#GIBend #MSBend #PipeBend #DelhiSupplier #BendManufacturer #GIPipeFittings #IndustrialFittings #WeldedBend #PipeElbow #Udhhyog #BestBendDelhi
