Alarm Management Software

[bliiot]

ARMxy Edge Computing for Smart Tunnel Monitoring and Emergency Response

As urban infrastructure grows in complexity, tunnel systems—whether for traffic, rail, or utilities—require intelligent, resilient monitoring and fast-response mechanisms. Traditional centralized systems often struggle with latency, connectivity issues, and real-time responsiveness, especially in enclosed or remote tunnel environments. This is where edge computing steps in as a transformative solution.

Why Edge Computing for Tunnel Monitoring?

Edge computing enables data processing at or near the source—in this case, within the tunnel itself. By deploying rugged industrial edge gateways, like our ARMxy series, directly in the tunnel environment, data from sensors can be collected, processed, and acted upon in real time without relying on cloud or remote servers.

This architecture supports:

Low-latency event detection (e.g., fire, gas leaks, structural stress)

Reliable local control of ventilation, alarms, lighting, and signage

Offline operation during network outages

Data filtering and compression before sending to cloud SCADA or platforms

Integrated Tunnel Monitoring Capabilities

A smart tunnel solution may integrate:

Environmental sensors: temperature, humidity, CO/CO₂, air flow

Safety sensors: smoke, gas, vibration, intrusion

Video surveillance with AI inference for object detection or congestion analysis

Emergency system integration: fire suppression, evacuation signals, public address systems

With an edge device like ARMxy, all of this can be managed locally. Logic engines like Node-RED, data logging with SQLite or InfluxDB, and visualization through tools like FUXA or Grafana can be embedded right on the device. Moreover, protocols such as Modbus, OPC UA, MQTT allow for flexible and standardized data communication across diverse equipment.

Enhancing Emergency Response

In the event of a critical incident—fire, flood, or equipment failure—edge computing enables immediate localized decisions:

Triggering alarms and ventilation automatically

Sending real-time alerts via SMS or voice gateways

Logging events for diagnostics and compliance

Coordinating evacuation routes through smart signage

Final Thoughts

Smart tunnel systems demand more than traditional SCADA setups can deliver. Edge computing, combined with modular I/O and modern communication protocols, empowers real-time, intelligent infrastructure. Our ARMxy industrial edge gateways are purpose-built for such high-stakes environments, bridging the gap between sensors and smart decision-making at the edge.

[chriswu08]

BLIIoT Remote Monitoring RTU Gateway S275 Provides an Efficient Solution for Pipeline Monitoring

Foreword

Pipeline systems play an important role in various industries such as water supply, natural gas transportation, and chemical production. However, the safety and reliability of pipelines are crucial to ensuring the normal operation of the system.

The use of IoT technology can not only achieve the goal of visualizing and digitizing pipeline integrity management, but also minimize time and space risk factors to ensure safe and smooth operation of pipelines.

Pipeline Monitoring Requirements

In pipeline monitoring applications, the following parameters typically need to be monitored:

Liquid Level Monitoring: Make sure the liquid in the pipeline is at a safe level to avoid leaks or excessive water discharge.

Temperature Monitoring: Monitoring the temperature within pipes can help prevent overheating or undercooling.

Pressure Monitoring: Maintain normal pressure within the pipeline to ensure normal operation of the system.

Leak Detection: Detect leaks promptly to avoid environmental damage and personnel safety issues.

Valve Status Monitoring: Monitor the opening or closing status of the valve to achieve remote control.

etc.

Application of Remote Monitoring Gateway S275 in Pipeline Monitoring

Data Collection and Monitoring

Remote Monitoring Gateway S275, which supports RS485 and multiple IO channels, the sensor can be easily configured to monitor various parameters of the pipeline system in real time. By connecting analog and digital sensors, the device can collect data such as level, temperature, pressure, etc. and save it in an internal database for subsequent analysis and reporting. This helps identify potential problems early and take appropriate action.

Alarms and Notifications

Remote Monitoring Gateway S275 has a powerful alarm function, and users can set alarm thresholds based on monitoring data. Once these thresholds are exceeded or dropped, the device will trigger an SMS alarm to notify relevant personnel. This real-time alert can help take quick action to reduce potential risks.

Remote Control

Maintaining the safety and reliability of your pipeline system is not just about monitoring, but also about real-time control. The relay outputs of Remote Monitoring Gateway S275 can be used to control valves, pumps and other equipment to remotely close or open them when necessary. This remote control capability helps reduce risk and improve operational efficiency.

Data Upload and Integration

Remote Monitoring Gateway S275 supports multiple communication protocols such as SMS, Modbus, MQTT, etc., and transmits data to cloud platforms, SCADA, etc. This means pipeline monitoring data can be integrated into cloud solutions, enabling remote access, data visualization and analysis. In addition, the device is also compatible with multiple public cloud platforms such as Huawei Cloud and Alibaba Cloud, as well as users' private cloud platforms.

Summarize

Remote Monitoring Gateway S275 is a powerful IoT terminal device that can be widely used in the field of pipeline monitoring. Provides comprehensive data collection, monitoring, alarm and control functions, while supporting multiple communication protocols and cloud platform integration to ensure the safety and reliability of the pipeline system. Whether it is water supply, natural gas transmission or chemical production, Remote Monitoring Gateway S275 can provide efficient solutions for pipeline monitoring.

More information about BLIIoT Remote Monitoring RTU Gateway S275: https://www.bliiot.com/m2m-rtu-p00175p1.html

[albgroupmy]

FOUR-FAITH 5-38KV Line Fault Indicator is fully functional and easy to install. It can detect grounding and short-circuit faults quickly and effectively, and realize intelligent monitoring and management of power equipment. The following are two hot-selling types: 1. JYZ-HW Remote Overhead Line Fault Indicator: The fault signal is indicated by three ultra-bright blinking LEDs with 360º sight. The fault information and current value can be uploaded to the SCADA by 2.5G/3G/4G networks. 2. DYO-FF Wall Mounted Fault Indicator: The red LED in display unit will blink when short circuit or earth fault happens. The fault information will also be sent to SCADA system by external connected IP Modem or RTU/FRTU. Advantages: 1. Support 2 SIM Cards/2 Remote Centers 2. IEC101/IEC104/DNP3.0/MODBUS Protocol 3. 2G/3G/4G/5G or Serial Port Communication 4. Licence-Free Radio: 433Mhz/868Mhz/2.4Ghz 5. Time-Stamped Alarms And Event Log 6. Support 5 SMS Numbers Contact our sales team to find out more about FOUR-FAITH 5-38KV Line Fault Indicator products range and solutions: 📧 eMail Us: info@albgroup.com.my 📱WhatsApp Us: +601.9728.9506 ☎️ Call Us: +603.8081.9560 🔮 Find more at: https://www.albgroup.com.my #faultindicator #linefaultindicator #fourfaith https://www.instagram.com/p/Ckxc3Fdp_78/?igshid=NGJjMDIxMWI=

[edacelectronuicsaustralasia]

EDAC Electronics Australasia supplies remote monitoring, control and alarming equipment to industry and end users around Australia and overseas. We offer best products & services: Online Wireless Sensors, Wireless modems. SMS/data logs, Scada Alarm Solution and much more. Our aim is to remain extremely competitive in all aspects of our business. We value your support and we look forward to being of service to you in the near future.

[messunggroup]

MONITOR & OPTIMISE YOUR VILLA’S ELECTRICAL SYSTEM WITH MESSUNG’S SPDS

Messung, pioneer of the indigenous PLC and leader in PLC-based automation, brings you smart power distribution control panels. Messung develops Industry 4.0 compatible, smart Cloud-based electrical panels incorporating automation products like PLC, HMI, SCADA along with special Busbar power distribution products.

Messung offers the total low voltage power distribution control system for different applications. Be it a machine, water treatment plant, hospital, hotel, farmhouse or villa, Messung studies the requirements of the customer and proposes an efficient, cost-effective solution. Messung’s team provides programming, engineering, training and documentation services as part of the total deliverables.

Requirements of luxury homes

Every luxury villa, bungalow or farmhouse requires a convenient Electrical Panel to terminate the various sources of power. Typically, these residences use power from four main sources: main power grid, Diesel Generator, UPS and Solar.

These homes also need a Controller to help maintain and monitor all the various elements and provide uninterrupted power to the occupant. Messung works with clients to offer them the safest and most efficient solution ensuring that every panel is made to order for the client’s specific requirements.

Typically, luxury villas, bungalows and farmhouses require the following:

· Water pump system

· Boiler/Geyser/Solar operation

· Sprinkler system for lawns

· Timer control for outdoor and indoor lighting

· UPS to Generator switching with fuel level monitoring of generator

· Energy metering and monitoring (allowing auto changeover and shutdown of large consumption sources during power outage)

· Alarm indications with app-based notification

· Synergy with security, surveillance and Smart Automation systems already existing in the house

· Easy integration with Home Automation Systems like KNX, etc.

· A neat and elegant visual display made specifically to provide accurate status of all systems

Messung’s Smart Power Distribution Solution (SPDS)

Messung’s SPDS (Smart Power Distribution Solution) for villas, bungalows & farmhouses is a smart electrical panel designed as per IEC 61439 Standards. It provides unmatched safety for distribution and monitoring of electrical power. It connects various power sources to a single point, with PLC controls for switching the source.

Messung’s Smart Power Distribution Solution is designed to be the center for connected power in the luxury villa. It is an intelligent control panel with compact power distribution for space saving and PLC controls for switching the source.

Features of Messung’s Smart Power Distribution Solution (SPDS)

· Safe and easy termination of various power sources - grid, DG set, UPS, Solar

· Automation & control for intelligent Power Distribution and Control to suit the villa’s specific needs

· Intelligent supervision and alarm systems for the entire electrical system of the villa

· Intelligent solar energy management with battery management

· IoT Interface possible (alarm & notification through SMS)

· Easy integration with existing home automation systems like KNX, Crestron, etc.

· Auto changeover of the incoming sources through PLC and monitoring by HMI

· Compact power distribution with space saving

· Individual power consumption from different sources

· Alarm indications like low fuel level, solar and UPS battery status

· Cloud connectivity and remote monitoring on mobile and laptop through OPCUA & MQTT PROTOCOL

· Power management panel ranges from 25kw to 75kw

· PLC Control Description

· MODBUS TCP/RTU, PROFIBUS, ETHERNET IP, MQTT, OPCUA communication available

· PLC will continuously monitor availability of power source and in case of failure will automatically change the source in predefined way

· Can easily monitor the system through HMI, SCADA and also through mobile app

· User friendly screens to guide the user for diagnosis

Conclusion

Experience the superior functionality and aesthetics designed for the modern, luxury home with Messung’s SPDS. The electrical panel connects cutting-edge hardware with innovative software to improve operational efficiency and ensure smooth changeovers for the comfort, convenience and safety for residents.

Call Messung to customise your own SPDS today – and enjoy Cloud connectivity, 100% uptime and fail-safe operations of your home’s electrical system.

[messungelectricalengineering]

Messung Smart Power Distribution solution for Villas

Every luxury villa, bungalow or farmhouse requires a convenient Electrical Panel to terminate the various sources of power. Typically, these residences use power from four main sources: main power grid, Diesel Generator, UPS and Solar.

These homes also need a Controller to help maintain and monitor all the various elements and provide uninterrupted power to the occupant. Messung works with clients to offer them the safest and most efficient solution ensuring that every panel is made to order for the client’s specific requirements.

Typical requirements of villas, bungalows & farmhouses

Luxury villas, bungalows and farmhouses come with many electrical and safety elements that require constant maintenance and seamless interoperability to ensure comfort and convenience. The list of requirements includes:

•UPS to Generator switching with fuel level monitoring of generator

•Energy metering and monitoring (allowing auto changeover and shutdown of large consumption sources during power outage)

•Water pump system

•Boiler/Geyser/Solar operation

•Sprinkler system for lawns

•Timer control for outdoor and indoor lighting

•Alarm indications with app-based notification

•Synergy with security, surveillance and Smart Automation systems already existing in the house

•Easy integration with Home Automation Systems like KNX, etc.

A neat and elgnat visual display made specifically to provide accurate status of all systems

Messung’s Smart Power Distribution Solution (SPDS)

Messung’s Smart Power Distribution Solution is designed to be the center for connected power in the luxury villa. It is an intelligent control panel designed as per IEC 61439 standards with compact power distribution for space saving and PLC controls for switching the source. The entire system can be monitored locally with HMI and Scada system and remotely with IoT interface and Cloud connectivity.

Features of Messung’s Smart Power Distribution Solution (SPDS)

•Individual sources from grid, DG set, UPS, Solar

•Auto changeover of the incoming sources through PLC and monitoring by HMI

•Compact power distribution with space saving

•Individual power consumption from different sources      •Alarm indications like low fuel level, solar and UPS battery status

•IoT interface possible (alarm & notification through SMS) and Cloud connectivity

•Cloud connectivity and remote monitoring on mobile and laptop

•Power management panel ranges from 25kw to 75kw

 PLC Control Description

•MODBUS TCP/RTU, PROFIBUS, ETHERNET IP, MQTT, OPCUA communication available

•PLC will continuously monitor availability of power source and in case of failure will automatically change the source in predefined way

•Can easily monitor the system through HMI, SCADA and also through mobile app

•Mobile app and PLC communication is possible through OPCUA & MQTT PROTOCOL

•Can be interfaced with Cloud connectivity for data storage & analysis

•SMS & notification for alarm and critical events

•User friendly screens to guide the user for diagnosis

Typical Load Calculation (Sample table)

Every luxury villa, bungalow or farmhouse requires a convenient Electrical Panel to terminate the various sources of power. Typically, these residences use power from four main sources: main power grid, Diesel Generator, UPS and Solar.

These homes also need a Controller to help maintain and monitor all the various elements and provide uninterrupted power to the occupant. Messung works with clients to offer them the safest and most efficient solution ensuring that every panel is made to order for the client’s specific requirements.

                                      QTY           kW        TOTAL kW

Motor                                2              2            4

Ac                                       5             2.5        12.5

Boiler                                 1             1.5          1.5

Indoor lighting                 20          0.009     0.18

Outdoor lighting              20          0.012     0.24

Home appliances             10           0.3          3

Sprinklers                          2           0.18        0.36

Total kW                           21.78

Recommended panel as per above chart: Smart Power Distribution Solution 25kW

Conclusion

Messung’s SPDS provides all the safety features of a standard panel with added functionality and aesthetics designed for the modern, luxury home.  It connects cutting-edge hardware with innovative software to enable users to pinpoint overloads & inefficiencies, make informed decisions, improve operational efficiency and ensure smooth changeovers to provide comfort, convenience and safety for residents.

SPDS helps to protect people and equipment, and allows you to monitor the property in real time. SPDS is available in ranges from 25kw to 75kw, to suit individual requirements. Through Cloud connectivity, you can monitor and access the status of your home’s electrical system on your smart device or computer, helping you to optimise energy expenses, ensure 100% uptime and fail-safe operation.

Messung Electrical Engineering is Master Distributor-India for Wohner Gmbh. Messung partners with OEMs and end users to deliver the most efficient electrical panel components and solutions that answer today’s critical electrical power distribution & management challenges.

Messung provides turnkey solutions to OEMs and end users by manufacturing smart low voltage electrical distribution control panels using the latest Wohner Busbar solutions for safe, compact installations as per IEC 61439 standard. These panels are also fitted with world class IoT based Smart Energy Management Systems and Analysers with solutions to remove Harmonics and ensure clean power to end user applications. For the most advanced power distribution and control solutions, and versatile energy management systems, contact Messung Electrical Engineering.

[cooldavidkentposts]

DeltaBlack IoT edge remote monitoring solution

DeltaBlack is an easy-to-use cellular 4G/3G/2G remote monitoring, alarming and logging solution which is suitable for use in a range of industrial applications.

The Industrial IoT edge device is designed to work in the cloud with SCADA systems or via simple user-friendly SMS commands.

With multiple I/O channels, wide operating supply voltage, DIN-rail mount and integrated RE232 modem, the device includes various sensor types including temperature and humidity, level, flow, pressure, pulse meters — electrical, water and gas — and CT current transducers.

Other features include: integrated 7-channel data logger including one relay output; customised SMS alerts; and LED indication for cellular signal quality and communication status.

The unit weighs 250 g and comes with a pre-provision SIM card. Users can remotely manage the device and access measured data anywhere by connecting the sensors and logging into ETM’S IoT Cloud Dashboard (EWO).

Suitable applications include: pump, fan, generator and motor; refrigeration and freezer systems; metering, HVAC and indoor climate; tank measurements; fire panels and intruder alarms; data centre monitoring; and agriculture.

source http://sustainabilitymatters.net.au/content/water/hot-product/deltablack-iot-edge-remote-monitoring-solution-995954064

from WordPress https://davidkent.home.blog/2019/11/06/deltablack-iot-edge-remote-monitoring-solution/

[inovn]

HWg-SNMP Web relay (Model: Damocles MINI)

Vui lòng liên hệ với chúng tôi– chúng tôi sẽ liên hệ lại với khách hàng bằng điện thoại hoặc email.

Lưu ý: Tham khảo ý kiến của nhân viên INO sẽ giúp bạn tiết kiệm được thời gian và chi phí khi cần mua sắm. ​​Với sự tư vấn của chúng tôi, bạn sẽ không gặp khó khăn khi tìm hiểu về đặc tính của sản phẩm cần mua.

Damocles MINI is Web-relay with 4 digital inputs and control 2 NO/NC relay outputs over the Web and M2M (SNMP, XML, Modbus/TCP). Dry contact event email or SNMP Trap alert.

Control two remote relays and four digital inputs (dry contacts) with a Web interface. Switch a relay or check the input states over an IP network.

The Damocles MINI is a SNMP / WEB relay that is typically used to remotely switch On/Off other devices or to measure energy consumption (using pulse counters at the inputs). When an input contact is closed, Damocles sends an email with customized text. Optionally, the email can be sent after a defined delay (for example, to send an alert if a freezer door stays open for more than 5 minutes).

A typical application is the sending of an email based on Dry contact inputs, remote restart or remote relay control. Relay outputs can be controlled over M2M protocols SNMP, XML over http or Modbus/TCP.

4 DI digital inputs for contact connecting

2 DO relay outputs relay contacts (NC and NO)

Sensor value out of range: sending Email or SNMP Trap to several recipients.

foto 1   foto 2    foto 3

Damocles MINI Flyer

Features

Online demo

Ethernet: RJ45 (10BASE-T)

WEB: Built-in web server

Inputs: 4 digital inputs (dry contact)

Pulse Counter: 32. bit counter on each Digital Input (for connecting S0 pulses)

Outputs: 2 digital outputs (relays, 24VDC)

Box-2-Box mode: Outputs are activated by alerts from other devices (Poseidon / Damocles)

M2M communication protocols: SNMP, XML, Modbus/TCP

Reaction to changes at the input: SNMP trap, Email (editable text)

Mechanical: dimension 35 x 102 x 76 [mm]

Support for programmers: HWg SDK

Supported software

HWg-PD Trigger: Controls other IP devices, redirects alarms to SMS

HWg-PDMS: Logging,conversion of pulses to energy, export to MS Excel, reports

CapTemp: Visualization on a map, control of outputs, alarm redirection to SMS

>> Third-party SNMP software (Nagios, The Dude, Zabbix, IBM Tivoli, HP OpenView, OpManager, IMM (Intellipool Network Monitor), Monitor one, Cacti, MRTG, Opsview, LoriotPro, Axence nvision, Ipswitch WhatsUp, Paessler IPCheck, MSC Operations Manager 2007)

Box-2-Box mode

Changes at a dry contact input of one device (A) are sent over the network (SNMP Trap) and reflected at the relay output of the other device (B). Damocles MINI can react to changes at the inputs of another Poseidon or Damocles unit (without any additional software).

Example: Too high temperature in the datacenter (measured by Poseidon 3266) turns on a warning red light in the IT department in another building (relay output of Damocles MINI).

AN37: Box-2-Box Connection: Poseidon >> Damocles

Applications

Control the relay over network – switch relay by three clicks on the mouse

Remote Web-Relay controlled over IP (snmp / xml / Modbus/TCP)

Pulse counter: energy consumption measurement over IP. Reading of the consumption in time from electrometers, flow meters, gas meters, ..

Monitoring of sensors of door opening, motion detectors, dangerous gas, etc.

Connecting of external inputs to SCADA systems

Remote control over IP – Opening of entry points (doors, gates, pikes and connecting of passage sensors)

Monitoring of back-up power supply like UPS and Diesel-engines

Camera systems (door contacts, PIR sensors)

Measurement of number of persons/vehicles – counting of indoor state and number of passage of persons/vehicles

Which software to use

Configuration: UDP Config  – IP address configuration

Event processing: PD Trigger – reacts to events

Monitoring and logging: HWg-PDMS – Monitoring software with MS Excel reporting

Simple Visualization: SNMPcap – I/O and sensors

Visualization: CapTemp – Process monitoring and control

Command line control: PosDamIO – Command-line control of inputs and outputs (see AN29)

Other applications: Third-party software for Poseidon & Damocles

For programmers: HWg-SDK contains interface descriptions and examples of using M2M protocols in several programming languages (JAVA, PHP, Borland C++ Builder 6.0, Microsoft Visual C++ 6.0, Borland Delphi 6.0, Microsoft Visual Basic & Excel VBA, VB.NET, C code for Linux, JavaScript (AJAX) Microsoft Visual C# 2005 (.NET)

 Topology

WEB (HTML) The state of digital inputs and outputs is displayed on WWW page. The page is automatically reloaded every 5 seconds. On the main HTML page there are links to Flash Setup, update FirmWare and others..

XML All values, the information about alarm state including, are accessible in .XML file (values.xml) and any application can easily log it from XML tags – more informations..

SNMP SNMP is protocol for management of telecommunication devices, network infrastructure and related technologies. Damocles is fully controlled over SNMP – more informations..

Modbus/TCP Modbus/TCP is industry standard for input of sensor values and sensors into visualization and SCADA systems. All sensors values are accessible over Modbus/TCP – more informations..

Alarms

SNMP Traps In a case of Alarm, the device will send you SNMP Trap with a description of Alarm state to defined IP address – more informations..

Email Apart from SNMP Trap, in a case of alarm the device can send you Email with a description of Alarm state – more informations..

>> Damocles – communication protocols.

Technical specifications of Damocles MINI

Ethernet: RJ 45 (10BASE-T – IEEE802.3)

4x Digital inputs: prepared for direct contacts connecting

2x Relay outputs: relay contacts NC and NO

Device configuration:

UDP Config – IP address configuration, etc.. – remotely functions over the network, but only on the local segment of the network,

Over HTTP – graphic Flash interface – ensured by access password and defined range of IP addresses.

Ethernet port + Interface RJ45 (10BASE-T) – 10 Mbit or 10/100 Mbit network compatible + Supported protocols IP: ARP, TCP/IP (HTTP, Modbus over TCP), UDP/IP (SNMP) + SNMP compatibility Ver:1.00 compatible, some parts of the ver 2.0 implemented Digital inputs + 4x Digital Inputs Dry contact / Wet contact directly + Pulse counter Yes, 32 bits per DI Digital outputs + 2x Relay contacts up to 5A/110V AC or 5A/24V DC 1x NC and 1x NO for every output LED Status indicators + POWER Green – power OK + LINK & Activity Green – Ethernet connectivity DIP SWITCH configuration + DIP1   Not used + DIP2   – Security ON   = Security mode – remote configuration disabled OFF = Non-Security mode – remote configuration enabled Physical parameters + Voltage requirements 12-24 V/ 600 mA DC- coaxial power connector (barrel), GND on the shield + Dimensions / Weight 35 x 102 x 77 [mm] (H x W x D ) / 500 g

Sample ordering

How long it takes to supply ordered samples? We keep the Damocles MINI units permanently on stock and supply them during 24 to 48 hours. If you confirm the order, we will send you an E-mail and inform you about approximate delivery date.

What kind of guarantee do you provide? Standard guarantee is 2 years, it´s possible extend it by contract.

Where I can find the prices of devices? You can ask our distributors or ask for price (by Email or form).

Where I can find the price of Damocles and accessories for my project? Send us email (see Contacts), or Demand form. Introduce more informations about your project, how many Damocles unities and which accessories do you need. Don´t fotget write us in which software data will be processed or what do you expect from the program. Write us where are you come from too. We can recommend you the installation company in your neigbourhood.

How you will deliver my order? We use a couple of delivery companies, for express delivery we use FedEx.

>> Ways of product ordering

>> Fulfill on-line order

Ordering numbers

OID Popis typu 600 289 >Quotation Damocles MINI set (photo) Recommended start set for the work with Damocles MINI:   – Damocles model MINI [600 250]   – EU Power adaptor [600080] (photo) (can be replaced by US or UK type)   – manual, CD 600 250 >Quotation Damocles MINI (photo) 600 339 >Quotation Damocles MINI 48V (photo) Damocles MINI powered from -48V DC telco standard. Power supply galvanic isolated from Dry Contact Inputs and relay Outputs.

 Damocles accessories

DB9 LapLink cable 2m [600 063] Communication cable RS-232 LapLink for PC connecting.

Power adapter

European version – 12V / 0,5A [600 080]

USA version – 12V / 0,5A [600 081]

UK version (Great Britain) – 12V / 0,5A [600 082]

Back-up power adapter (EU plug) [600 251]

PowerEgg – (photo) [600 237] Detection of external AC voltage (110 up to 230V), controllable AC output (110 up to 230V)

Inputs and Outputs

DIN relay – 1x switch contact 10 A [600 084]

DIN relay – 2x switch contacts 10 A with optical signalization [600 085]

3x Door contacts (plastic design) [600 120] 3x sensors for detection of door opening – small, light plastic design, apart from test set, we supply them only like multiple of 3rd pieces

Resource & Download

Damocles MINI

Damocles MINI Specifications

Damocles MINI Starting Guide

Configuration: UDP Config

Latest firmware: Firmware v.1.0.11 MIB available for download from the product GUI

Lưu ý: Nếu một thiết bị nào đó không được liệt kê ở đây, điều đó không có nghĩa rằng chúng tôi không hỗ trợ được bạn về thiết bị đó. Hãy liên hệ với chúng tôi để biết danh sách đầy đủ về thiết bị mà chúng tôi có thể hỗ trợ và cung cấp.

INO: Bán, Báo giá, tư vấn mua sắm và cung cấp, tư vấn sản phẩm thay thế; tương đương, hướng dẫn sử dụng, giá…VNĐ, …USD info@ino.com.vn | 02873000184 | HWg-SNMP Web relay (Model: Damocles MINI).

Calibrator http://www.calibrator.vn/khac-do-luong-kiem-tra/hwg-snmp-web-relay-model-damocles-mini/

[historicalalarms-blog]

What Is not to Enjoy about Cloud Established IoT Platforms?

View Live and Historical Alarms with Open Standards Library

Nothing, if You're familiar with relying on additional services and Infrastructure to handle, secure and maintain your information. If missing or lost information is OK, if a person misses a telling of a tune download or on a new product launch, or perhaps even when you're low on milk. But if you rely on up-to-date real time information for critical decisions, then present cloud-based IoT platforms might not be the ideal alternative. When seconds count, are you convinced of your IoT infrastructure supplier?

View Live and Historical Alarms with Open Standards Library

Some of the Significant questions or issues with the present cloud-based IoT platforms are:

How do I get my information from my apparatus to the Cloud established IoT environment? A great deal of industrial devices don't encourage IoT protocols. Do I need to replace every one of these devices I have spent in only to receive my information to Cloud? What if my information source is a spread sheet, a database or an present program? What if I wish to do calculations on the information before transmission?  You will find over a few. Which do I pick? As it'll be a sizable investment, what happens within a couple of years when there's a new protocol demanded by my IoT supplier? Will the older protocol still work or will I need to innovate in converting all of my apparatus to the new protocol. If I choose to change to a unique cloud-based IoT supplier, will my current apparatus / system still function? Safety. Is my information likely to be protected from hackers, and who's controlling my information? What 3rd party partners will get access? Is SSL safe?  Which one is going to work together with my IoT Provider? How can I handle the certifications needed by my cloud-based IoT supplier? How protected will be the cloud-based servers? The significant players from the IoT stadium are a prime target for hacking due to the abundance of information available and also the visibility of the servers and servers, so one breach could expose tens of thousands of consumers such as you.  What happens when the online link or even the cloud-based servers return? Can my company be blind for choice making? What happens when my cloud established IoT supplier is under a DDOS attack? Can I be losing information that can not get moved into the cloud?  What happens when my supplier makes the decision to increase its subscription cost or worse nonetheless decides to escape this IoT marketplace? For the large players, IoT is merely a side business.  What tools do I use to access, display, analyze, and save my personal information? Just the tools supplied by my own subscription?

Imagine if there is a stage that provides you all of the Benefits of linking not just to IoT certain platforms and devices, but literally 10s of thousands of present real time and heritage devices? Imagine if this stage could quickly, safely and cost-effectively transfer tens of thousands of data points per minute and assure that you have all of the data kept even if the communications between the origin and destination is down, while still supplying N amounts of redundancy? And even better, what if it did not rely on 3rd parties solutions to manage and disseminate your information, allowing the platform to be wholly handled by your own IT department or hosted from the cloud? What about a system that provided interfaces to SQL Server, Oracle, MySQL database and also the capacity to create real time and historic software based on . Web, HTML, JS, and iPhone and Android OS?

Open Automation Software Option

OAS has been fulfilling All These prerequisites for centuries and is In use in a number worldwide fortune 100 companies, atomic and military applications and as little as single site places. For Reliable data transmission, rescuing historic data, Evaluation, Big Data, Dashboards, Reporting, Data Analysis, Trending, Alarm and Occasions, Alarm Notification, SCADA/HMI, OEE and a Lot More.

OAS relies on DNA (Distributed Network Architecture)

Constructed in protocols for major brands of Industrial PLCs and apparatus.

Allen Bradley, Siemens, Modbus and much more.   OPC UA, DA, AE MQTT, AMQP MS Excel SCADA / HMI software Databases . Web or Internet Programs, REST and many others

What Protocol to choose for my apparatus:

No need to decide on what protocol to use or should You Need to convert All your apparatus. OAS supports each of the main device protocols and when your device isn't supported OAS includes a universal driver port.

Safety:

With OAS just you control your own data. OAS also provides built in user security to varying degrees. OAS utilizes secure encrypted and encrypted protocol, also approved by not just the nuclear sector but also the US army. You are able to host OAS in your own servers or onto any cloud base service supplier of your choice. You may also have several servers in various places or from different suppliers. Supplying varying degrees of redundancy. Want secure one way phoning (Info Diode) OAS has that covered too.

OAS doesn't presume that a constant relationship. Actually Lots of our Clients choose OAS for their information transmission for this purpose especially. For example if you're logging information to a remote database using OAS and the network link is missing all data is buffered in the origin. Not only for moments but for months or days. When the link is restored, the buffered data is automatically moved into the remote database. OAS can also transfer data to multiple destinations via multiple networks simultaneously. Redundancy is simple using OAS.

IoT Service suppliers:

With OAS you have the program. No worries about costs moving up or Cloud established IoT service suppliers leaving you high and dry.

Together with the OAS Platform you have open and effortless access to your information with a number of applications and development applications.

Easily log and recover information with Microsoft SQL, SQL Express, Access, Oracle or MySQL. Easily create interactive software using VB.Net or C# in Visual Studio with historical or live data. Software that operate safely over Easily make secure Web applications using HTML and/or JS to Interact with Live or historic data. Web programs That Aren't Dependent on a particular browser or development stage so that you may see And interact with the web application in the verity of different Platforms like iPhone and Android apparatus. Interact with historical and live data with OAS REST interface. Interface with existing software programs through Web Services, APIs or Databases. Read and write information to present SCADA/HMI program via APIs, OPC Client or Server.   (Unlimited Client Software) Programmatically read and compose historical or live data with VB.Net C# or even JS. Programmatically configure OAS for quick installation of your system modifications, updates and attributes Create analytical or business program to interact with live or historic information. Insert Live and historic data to your present software Trend reside or historic data in desktop or web software. Produce IOS or Android Certain software using OAS PCL and Xamarin forms. View, admit, log and preform notifications (Mail, SMS or Voice) on almost any alert or occasion Automatically create reports based on time or events and automatically email the report to some amount of recipients.

[seozelenka]

Alarm Management Application

[bliiot]

Modbus RTU to MQTT Modbus TCP RTU AWS IoT 4G RS485 DTU SMS Alarm Gateway for Electric Power Control

IoT gateway BL100 is a Modbus to MQTT gateway that converts Modbus RTU to MQTT protocol. BL100 is a Modbus to MQTT gateway based on cellular network. It supports Modbus RTU, MQTT Protocols. The Modbus Gateway supports Modbus Slave and Modbus RTU Master with up to 48 Modbus Slave devices for data acquisition. BL100 Modbus gateway support remote monitoring, configuration, inquiry and control with SMS. Built-in timer function to perform scheduled automatic data reporting, SMS, Arm/Disarm and device restarting. The Modbus to MQTT gateway supports Alibaba Cloud, HUAWEI Cloud, BLIIoT Cloud, custom platform, and transparent data transmission, data retransmission. Users can connect it to third-party server, cloud platform and SCADA easily.

[bliiot]

Battery pack monitoring module BMS100 is specially developed for battery pack monitoring in unmanned rooms and unattended scenes. It adopts 9-60VDC wide voltage power supply and can measure 12 single battery voltages of 2V, 6V and 12V, and can measure battery packs in groups, up to 6 groups, the total battery pack voltage that can be measured is 300V, and 2 analog inputs are reserved for measuring Battery pack total current total voltage and battery pack temperature. It can be connected to BLIIoT IOT cloud and seamlessly connected to SCADA.

1.Can measure 12 way basic voltage, 1 way total voltage; support 12 sections of 2V, 6V, 12V single battery voltage monitoring, total voltage Max. 300VDC; 2.Support 2 analog inputs, optional 4-20mA or 0-5V, plus the corresponding instrument supports battery pack total current, total voltage, temperature real-time measurement; 3.1 ESD protection RS485 serial port , support Modbus RTU protocol, add BLIIoT Modbus gateway can upload all the data of the device to the cloud, and realize SMS, phone and WeChat alarm for over limit threshold; 4.Support battery series, cascade, parallel, grouping a variety of wiring methods; 5.Cascade to monitor small battery packs of more than 12 cells; 6.Support group monitoring of battery pack voltage, up to 6 groups.

[inovn]

Thiết bị định vị – HWg-Ares 12 – HW Group Việt Nam

Ares 12 is an industrial unit for remote monitoring and alarming over GSM for locations without LAN access. Includes battery backup. Connect up to 14 external sensors and 2 dry contact detectors.

Ares monitors the readings of connected sensors. When a value reaches the alarm threshold, the device sends an e-mail or a text message (SMS), or dials specified numbers. Use the free SensDesk portal to view measured data in a complex dashboard.

Ares products support FOTA (Firmware Over The Air) for remote firmware updates.

Features:

14x 1-Wire UNI/1-Wire Input; 2x Digital Input with S0 pulse counters; Data Logger for more than 250.000 recordss; Digital Inputs feature 32-bit pulse counters that retain their value even if the power fails

5x E-mail; 5x “SMS+Ring”

Internal battery provides back-up power for up to 24 hours.

Use the USB interface to configure the device from a PC with no need to install any additional software. Remote configuration also possible via the “AresConf” tab in the SensDesk portal.

Remote firmware upload (FOTA) capability makes Ares devices ideal for large-scale deployments.

Connected via GSM/GPRS.List of APN available worldwide.

A sensor value out of a set safe range as well as a DI state change sends an alert by e-mail or “SMS+Ring”, or activates a relay (via connected accessory “Relay Output 1-Wire UNI”).

Data can be sent in e-mail attachments or downloaded via USB.

With the HWg-PDMS software, S0 pulses can be converted to cost per time period and exported to MS Excel.

Compatible with a range of third party SW (SCADA etc.). Examples for programmers on using the product are available in the HWg-SDK (Borland C++, MS Visual, VB, C#, PHP, JAVA and more).

First steps with GSM/GPRS thermometer Ares set from HW group

Applications and usage:

GPRS monitoring of machines and their  environment

ATMs – environment monitoring without tampering with the  connection

Art exhibits and  depositories

Storages of food or  materials

Cooling systems and coolers

Download tài liệu: Tại đây!

Model tương tự:

Cổng giao tiếp HW Group Việt Nam Poseidon2 3266 Cổng giao tiếp HW Group Việt Nam Poseidon2 3268 Cổng giao tiếp HW Group Việt Nam Poseidon2 3468 Cổng giao tiếp HW Group Việt Nam Poseidon2 4002 Cổng giao tiếp HW Group Việt Nam Damocles2 1208 Cổng giao tiếp HW Group Việt Nam Damocles2 2404 Cổng giao tiếp HW Group Việt Nam Damocles2 MINI Cổng giao tiếp HW Group Việt Nam HWg-STE Cổng giao tiếp HW Group Việt Nam HWg-STE plus Cổng giao tiếp HW Group Việt Nam STE2 Thiết bị định vị HW Group Việt Nam HWg-Ares 10 Thiết bị định vị HW Group Việt Nam HWg-Ares 12 Thiết bị định vị HW Group Việt Nam HWg-Ares14 Cổng giao tiếp HW Group Việt Nam HWg-PWR3/12/25 Cổng giao tiếp HW Group Việt Nam IP WatchDog2 Industrial Cổng giao tiếp HW Group Việt Nam IP WatchDog2 Lite Cổng giao tiếp HW Group Việt Nam HWg-WLD Cổng giao tiếp HW Group Việt Nam I/O Controller 2 Cổng giao tiếp HW Group Việt Nam IP Relay HWg-ER02b

  Calibrator http://www.calibrator.vn/hw-group/thiet-bi-dinh-vi-hwg-ares-12-hw-group-viet-nam/

[inovn]

HWg-PWR3/12/25 – Cổng giao tiếp Ethernet – HW Group Việt Nam

INO Measure Co., Ltd có khả năng tư vấn mua sắm, sử dụng, lắp đặt và cung cấp các thiết bị đo lường và tự động hoá. Nếu bạn có nhu cầu mua sắm hoặc cần sự hỗ trợ về kỹ thuật cho một thiết bị không được liệt kê ở đây, xin vui lòng liên hệ với chúng tôi.

Vui lòng liên hệ với chúng tôi– chúng tôi sẽ liên hệ lại với khách hàng bằng điện thoại hoặc email.

Lưu ý: Tham khảo ý kiến của nhân viên INO sẽ giúp bạn tiết kiệm được thời gian và chi phí khi cần mua sắm. ​​Với sự tư vấn của chúng tôi, bạn sẽ không gặp khó khăn khi tìm hiểu về đặc tính của sản phẩm cần mua.

Features:

Connects 3 / 12 / 25 external meters equipped with the M-Bus (EN 13757-2) interface, can log 170.000 values (3 values every 15 minutes = 590 days).

Converts the consumption (e.g. from [kWh] to a currency) without a need for computer or additional software.

M2M communication protocols Modbus/TCP, SNMP and XML allow integration into more complex monitoring systems.

Connected via LAN. Configuration via built-in web server.

Sends an energy consumption report for user specified period as an e-mail attachment.

Connected meter failure or out of specified range value sends an alert by e-mail, SMS or SNMP Trap.

For Ring or SMS alarm use the HWg-Trigger software (external GSM modem required), or a HWg-SMS-GW3 gateway in the same LAN.

With the HWg-PDMS software, logged data can be exported to MS Excel.

Compatible with a range of third party SW (SCADA etc.). Examples for programmers on using the product are available in the HWg-SDK (Borland C++, MS Visual, VB, C#, PHP, JAVA and more).

List of supported (tested) accessories/meters

  Applications and usage:

Remote monitoring of electricity meters in small server rooms and BTS

Monitoring of energy consumption in rented premises

Reading out energy consumption in remote or inaccessible areas

Control over energy costs

Checking for individual line overloads in three-phase wirings

Checking for undervoltage in electric wirings

Monitoring the flow of liquids

HWg-PWR 3/12/25 monitors energy consumption using standard external energy meters produced by well-known manufacturers. It is possible to mix electricity meters, water meters, gas meters etc. by different manufacturers. Depending on version, HWg-PWR supports 3, 12 or 25 external meters with the M-Bus interface (EN 13757).

HWg-PWR 3 / 12 / 25 – Energy monitoring gateway:

Sends an alarm in the event of failure or value out of a specified range (E-mail, SNMP Trap, SMS)

Logs selected values (displays graphs over the WEB interface)

8x Digital Inputs for detecting single-phase 110/230VAC outage

Converts the consumption (e.g. from [kWh] to [€]) without a computer or additional software

Periodically sends an energy consumption report for the given period as an e-mail attachment

Actively uploads data to a “portal” using the HWg-Push protocol

Advantages of using third-party M-Bus meters

Vast range of meters with the EN 13757 (M-Bus) interface to choose from. It is easy to use special-purpose meters (non-standard form factor or measured range, e.g. indirect electricity meters rated up to 1000 A).

M-Bus meters frequently provide extended information (total consumption and immediate values, voltage at different phases, power factor, etc…).

Values from certified meters can be used for billing purposes.

► Các câu hỏi, thắc mắc, thông tin liên quan đến sản phẩm từ khâu mua sắm, lựa chọn, sử dụng, cài đặt hay thay thế, vui lòng liên hệ với INO team để được hỗ trợ và tư vấn kịp thời.

► Công ty Giải pháp và Công nghệ Đo lường INO, nhà cung cấp các thiết bị đo lường và tự động hóa công nghiệp

►Web: www.ino.com.vn  |  Mail: sales1@ino.com.vn

►Tel: 028 73000184  |  Hotline: 0917 496 446

►Website: http://www.ino.com.vn

Model tương tự:

Cổng giao tiếp HW Group Việt Nam Poseidon2 3266 Cổng giao tiếp HW Group Việt Nam Poseidon2 3268 Cổng giao tiếp HW Group Việt Nam Poseidon2 3468 Cổng giao tiếp HW Group Việt Nam Poseidon2 4002 Cổng giao tiếp HW Group Việt Nam Damocles2 1208 Cổng giao tiếp HW Group Việt Nam Damocles2 2404 Cổng giao tiếp HW Group Việt Nam Damocles2 MINI Cổng giao tiếp HW Group Việt Nam HWg-STE Cổng giao tiếp HW Group Việt Nam HWg-STE plus Cổng giao tiếp HW Group Việt Nam STE2 Cổng giao tiếp HW Group Việt Nam HWg-Ares 10 Cổng giao tiếp HW Group Việt Nam HWg-Ares 12 Cổng giao tiếp HW Group Việt Nam HWg-Ares14 Cổng giao tiếp HW Group Việt Nam HWg-PWR3/12/25 Cổng giao tiếp HW Group Việt Nam IP WatchDog2 Industrial Cổng giao tiếp HW Group Việt Nam IP WatchDog2 Lite Cổng giao tiếp HW Group Việt Nam HWg-WLD Cổng giao tiếp HW Group Việt Nam I/O Controller 2 Cổng giao tiếp HW Group Việt Nam IP Relay HWg-ER02b

  Calibrator http://www.calibrator.vn/hw-group/hwg-pwr3-12-25-cong-giao-tiep-ethernet-hw-group-viet-nam/
