#SystemOnModule

[forlinx]

Forlinx Launches New FET-MA35-S2 System on Module Based on Nuvoton MA35D1 Series

Forlinx, a leading embedded solutions provider, is excited to announce the release of the FET-MA35-S2 System on Module, based on the Nuvoton NuMicro® MA35D1 series.

The MA35D1 series is renowned in high-end industrial control, edge IoT gateways, and HMI applications. Forlinx's FET-MA35-S2 module builds on this success, offering enhanced development ease.

It features two 64-bit ARM® Cortex-A35 cores at 800MHz and an ARM Cortex-M4 core at 180MHz. The compact LCC+LGA (48mm×40mm) package has 260 pins, including 4 CAN-FD, 17 UART, 2 Ethernet, and 8 ADC interfaces, ensuring flexibility and expandability. Rigorously tested in Forlinx labs, it guarantees stability.

Security is top-notch with TSI, TrustZone, secure boot, and encryption accelerators. Key storage and OTP memory protect data.

Suitable for various industries, with the OK-MA35-S21 dev board for easy development. Contact our sales engineers for more details.

[millenniumsemi]

Advantages of System on Module

A System on Module (SOM) is a compact, integrated computer system that combines the most essential components of a computer, including the central processing unit (CPU), memory, and input/output interfaces, into a single module. SOMs are widely used in embedded systems, such as industrial control systems, consumer electronics, and automotive applications, as well as in more complex systems, such as drones and robotics. There are several advantages to using a System on Module over a traditional, standalone computer system. Here are a few of the most significant benefits:

Space savings: SOMs are much smaller than traditional computer systems, making them ideal for applications where space is at a premium. This compact size also makes them easier to integrate into other systems, such as in the case of drone applications.

Increased reliability: SOMs are designed for industrial-grade applications and are built to withstand harsh environmental conditions. They are also typically more reliable than traditional computer systems, due to the reduced number of components and the use of high-quality materials.

Simplified system integration: SOMs are designed to be plug-and-play, making system integration much simpler and faster. They provide a common platform for different applications and can be used across multiple systems, reducing development time and costs.

Improved performance: SOMs are optimized for specific applications and are designed to maximize performance while minimizing power consumption. They are also often equipped with advanced features, such as multiple USB ports, Ethernet connectivity, and high-speed memory interfaces.

Increased flexibility: SOMs can be customized to meet specific requirements, making them ideal for a wide range of applications. They can also be easily updated or reconfigured as needed, providing greater flexibility in the long term.

In conclusion, if you're looking for a compact, reliable, and flexible computer system, look no further than a System on Module. And when it comes to finding the best SOM manufacturer and supplier, Millennium Semiconductors stands out from the rest. With a wide range of SOM solutions, advanced technology, and a commitment to quality, they are the ideal partner for all of your embedded system needs. So, what are you waiting for? Contact Millennium Semiconductors today to learn more about how a System on Module can benefit your application! Also Checkout - millenniumsemi.com

[millenniumsemiconductors]

System on Modules (SOM) & Computer on Modules (COM) are complete embedded computers with a computer processor, memory, chipset, and peripherals. These are designed into a single board with a small footprint. They combine the complete functions of a computer into a single module.

A system on a module is a board-level circuit that integrates a system function in a single module. It may integrate digital and analog functions on a single board.

These compact and powerful devices are a great value addition to embedded development and design teams around the globe are optimizing the development process by applying it in their IoT and smart devices.

Read More:https://www.millenniumsemi.com/products/system-on-module-som

[agilecircuit]

Allwinner R16 Quad-core Cortex -A7 Linux Android Smart Home Quad-core Cortex -AQuad-core7，528 MHz 256KB L1 Cache,512KB L2 Cache 16 bit DDR3/DDR3L, up to 2GB Supports 8-bit NAND Flash controller LVDS, Resolution up to 1280×800 8/10/16/24 bit parallel camera sensor interface One 10 / 100 Ethernet, supporting the IEEE 1588 protocol Support 1080p@60fps vedio display Switchable headphone mode / phone mode #Allwinner #Quad-core #embedded #controlmodule #R16 # Cortex™-A7 #controller #systemonmodule # iMX6 # NXPFreescale # SoM # CoM #manufacturing # i.MX6UL #ARM #developement #OEM https://www.instagram.com/p/By4oIRvnw49/?igshid=1evr6y262xhw8

[bitstream24]

System-On-Module (SOM) Dedicated To Commercial Vehicles Supports Two CAN FD Interfaces

Microsys Electronics announced its Miriac MPX‑LX2160A, a System-On-Module (SOM) dedicated to commercial vehicles and mobile systems. The module supports two CAN FD interfaces.

The module is based on the NXP LX2160A processor and offers 16 Arm Cortex-A72 cores, which are twice as many as its predecessors. The configuration meets the requirements of (artificial intelligence) edge server applications, autonomous driving, and situational awareness in cobot applications. Typical use cases are for V2X (Vehicle-to-Any) communications, e.g., edge servers in trains, planes, commercial vehicles, autonomous mobile systems, and functional safety applications.

https://copperhilltech.com/blog/systemonmodule-som-dedicated-to-commercial-vehicles-supports-two-can-fd-interfaces/

[forlinx]

Advantages of Using FETA40i-C in Laser Coding Machines

1. Introduction to Laser Coding Machines:

Laser coding machines use high-energy lasers focused directly on the surface of objects to induce physical and chemical changes, creating markings.

As the laser beam's focus moves systematically across the marking surface, controlling the laser's activation allows for the creation of specific marking patterns on the object's surface.

Laser marking offers advantages such as non-contact marking, high speed, minimal pollution, no consumable loss, and clear, permanent identification. These benefits give it a competitive edge, leading to its gradual replacement of traditional ink-jet coders.

2. Structure of Laser Coding Machines:

A laser coding machine primarily consists of the following components:

Control System: The core component responsible for editing and processing marking content, generating marking data, transmitting it to the galvo system and laser system, and handling external input.

Laser System: Responsible for generating and transmitting the laser to the galvo system.

Galvo System: Quickly and precisely rotates mirrors to alter the laser beam's path, focusing it into a spot on the marking surface.

Power Supply System: Provides power to the entire laser marking machine, including the controller, laser, and galvo system.

Conveyor Mechanism: Moves items to be marked and uses speed measurement devices to monitor real-time item movement, feeding this data back to the control system.

3. ARM+FPGA-Based Control System Design:

ARM processor manages the human-machine interface, complex data processing, and communication, while the FPGA handles the reception, storage, conversion of marking data, and controls the marking equipment.

The marking control is managed by the marking card, with real-time performance mainly relying on the FPGA. ARM SoM is used for interface display and higher-level computation.

4. Folinx Solution

Forlinx Embedded recommends the FETA40i-C SoM as the ARM platform for laser coding machines, offering notable advantages: Notable advantages:

High Performance Processing: The A40i platform, with its 1.2GHz high frequency, rapidly processes complex coding tasks. In laser coding machines, a high-performance processor ensures speed, precision, and efficiency in coding, with the A40i's high frequency reducing response time, enhancing productivity.

Excellent Display Capabilities: A40i platform supports multiple display interfaces, making the coding interface more intuitive and visually appealing. A clear and user-friendly interface is crucial for operators, who can more easily view and edit coding content via a large screen, improving work efficiency.

Robust Communication Capabilities: A40i features dual Ethernet ports and a 4G communication module, supporting various communication methods. This allows easy data transfer and communication with other devices, meeting the networking needs of modern industrial production, and facilitating future interface upgrades.

Extensive External Expansion Interfaces: A40i platform offers numerous native external expansion interfaces, including 8 x serial ports and 3 x USB. These provide ample connection options for external devices, enabling easy integration and interaction with various peripherals.

Industrial-Grade Stability and Reliability: A40i is an industrial-grade CPU known for its stable and reliable quality. Stability and reliability are critical in laser coding machines, ensuring long-term stable operation in harsh industrial environments, reducing failure rates, and extending equipment lifespan.

In summary, Forlinx Embedded A40i platform offers numerous advantages as the hardware control platform for laser coding machines, meeting the high-performance, high-stability, and high-reliability demands of modern industrial production.

Originally published at www.forlinx.net.

[forlinx]

MIPI-CSI Debugging for RK3576 Processor — Channel Analysis

#HowTo #Debug #MIPICSI for RK3576 Processor

Forlinx OK3576C SBC supports up to five camera inputs simultaneously via 5 x CSI-2 interfaces, so how to configure camera interfaces, whether it's for a single input or all five? Check out our latest blog to get the full instructions.

Learn Now:

[forlinx]

Forlinx FET3568-C SoM: The Efficient and Intelligent Main Control Choice for Vending Machines

1. Product Description

Vending machines, combining modern technology with the idea of convenient shopping, have become essential in our lives. It breaks through the constraints of time and space, providing us with round-the-clock uninterrupted product purchasing services. Whether in busy transportation hubs or quiet residential areas, you can always find its presence.

2. Components:

Body Compartment: Made from high-strength, corrosion-resistant metal materials to ensure the stability and durability of the vending machine. The warehouse's interior is well-designed and can be adjusted according to the size of the goods to maximize the use of storage space.

Payment System: Integrated with multiple payment methods including coins, bills, card swiping, and mobile payments, satisfying various consumer payment needs.

Display and operation: HD touchscreen shows product information and purchase process, simplifying steps to enhance user experience.

Product Delivery System: Uses precise mechanics and sensors for accurate, fast delivery to the outlet after payment.

Communication Management System: Enables real-time monitoring, sales data analysis, and remote fault diagnosis and repair of vending machines via wireless network.

Business Logic Topology

The vending machine's main control system acts as its operational core, akin to its "brain", overseeing and coordinating each module's functions. With the ongoing development of IoT, big data, and AI, automation has become an inevitable trend in the vending machine industry. This has led to new demands for the main control systems, focusing on:

Core Controller: It is essential to choose a stable, reliable, and high-performance core controller to ensure the overall logic control and data processing capabilities of vending machines.

Device Stability: It requires 24/7 uninterrupted operation, necessitating high stability and durability in both hardware and software. Specifically, the software system should have fault self-check and automatic recovery capabilities.

Scalability and Compatibility: To meet various scenarios and demands, the main control system of vending machines needs to be scalable. As products evolve, the main control system should be compatible with new hardware and software standards.

Payment Security: As payment methods diversify, ensuring the security of the payment process has become increasingly important. Vending machines need to guard against various security threats, such as data breaches and fraudulent activities.

AI Integration: Vending machines need to have intelligent recognition capabilities and data analysis abilities to recommend products based on users' purchasing preferences.

FET3568-C system on module(SoM) from Forlinx Embedded Systems offers high performance, low power consumption, and rich functionality, making it ideal for vending machines for these reasons:

Powerful Performance: FET3568-C SoM is based on the Rockchip RK3568 processor, which features a quad-core 64-bit Cortex-A55 architecture with a clock speed of up to 2.0GHz. It supports lightweight edge AI computing and delivers strong computational and processing capabilities. Such performance meets the high demands of logic control and data processing for vending machine control systems, ensuring efficient and stable operation of the vending machines.

Rich Interfaces and Expandability: The FET3568-C SoM offers 3 x PCIe slots, 4 x USB ports, 3 x SATA3.0 controllers, and 2 x Gigabit Ethernet ports. It supports 5 x display interfaces including HDMI2.0, eDP, LVDS, RGB Parallel, and MIPI-DSI, with up to three simultaneous display outputs. These interfaces provide great convenience for expanding the functionality of vending machines, enabling customized development to meet various scenarios and requirements.

Multi-OS Support: FET3568-C SoM supports multiple operating systems including Linux, Android 11, Ubuntu, and Debian 11. This flexibility allows developers to choose the most suitable operating system according to actual needs, thereby simplifying the software development process and improving development efficiency. Meanwhile, Forlinx Embedded has made numerous optimizations in software, such as introducing a 4G watchdog process. This design ensures that the 4G communication function can automatically recover after a disconnection, significantly improving the stability and reliability of the vending machine's network communication.

Advanced Security: In terms of security, the FET3568-C hardware can integrate encryption chips and trusted root modules. These hardware-level security measures provide solid protection for system information security. The ability to verify software integrity and authenticity from the hardware level effectively prevents the intrusion of malicious software and the risk of system tampering.

High Stability: FET3568-C has undergone rigorous environmental temperature testing, stress testing, and long-term stability operation testing, ensuring stable and reliable performance in various terminals and operational environments. This is crucial for vending machines that require 24/7 uninterrupted operation, as it can significantly reduce failure rates and enhance user experience.

In summary, the FET3568-C SoM not only features robust performance and stability, but also offers flexible operating system options, optimized software design, rich interfaces, and powerful expandability. These features make it an ideal choice for vending machine control solutions, capable of meeting the evolving needs of the industry.

Originally published at www.forlinx.net.

[forlinx]

[ForlinxLab] Curious why our embedded boards undergo high and low temperature tests?

[ForlinxLab] 🌡️ Curious why our embedded boards undergo high and low-temperature tests? 🌡️ Discover how we ensure reliability from -60°C to 150°C, simulating extreme environments to verify stability. Watch our process and see the dedication to quality in action! More info: https://www.youtube.com/watch?v=kvouO9nx6I8

[forlinx]

High-Performance and Low-Power Consumption Industrial-Grade SoM

🎉Amazing Product! The Forlinx SoM iMX8M Plus System-on-Module is Here!🎉

💥Powered by the robust NXP i.MX 8M Plus processor with 4 A53 cores and an M7 core, running at up to 1.6GHz for exceptional performance!

💡A variety of storage configurations are available, including 1GB/2GB/4GB LPDDR4 memory and 16GB eMMC storage to meet your diverse needs.

🌟Rich high-speed communication interfaces such as 2 USB 3.0, 1 PCIe 3.0, 2 SDIO 3.0, 2 CAN-FD, etc., easily handling 5G networks, high-definition videos and more challenges!

��4K picture quality and high-fidelity voice. The HDMI interface supports 4K display output, along with LVDS and MIPI-DSI display interfaces, and the audio technology is newly upgraded!

🤖Advanced multimedia technology with 3D/2D graphics acceleration, machine learning and vision functions. Built-in NPU (AI computing power up to 2.3TOPS) and image signal processor (ISP).

💪The supporting OKMX8MP-C development board helps you evaluate quickly. The base board has super computing and multimedia capabilities with a wide range of interfaces.

📄Comprehensive download resources are available and accessories are optional. Enjoy high-quality technical support upon purchase!

Come and experience this innovative product and embark on a new chapter of smart technology! 🔗

[forlinx]

FET3576-C: Upcoming System on Module Based on Rockchip RK3576 Processor

The FET3576-C is an upcoming high-performance, low-power system-on-module (SoM) powered by the Rockchip RK3576 processor.

Running on Linux 6.1.57, this SoM features 4 ARM Cortex-A72 cores and 4 ARM Cortex-A53 cores, plus a built-in 6TOPS NPU, making it well-suited for AIoT and industrial applications.

The board-to-board connection design makes it easy to set up, and Forlinx has rigorously tested it for stability in industrial conditions. With a 10 to 15-year life-cycle, it ensures continuous supply.

Stay tuned for more updates on the upcoming release of the FET3576-C!

More details:

[forlinx]

Industry Event | Forlinx Embedded at Embedded World 2024

[forlinx]

Unveiling the innovative Forlinx FET7110-C System on Module!

🚀 With a powerful quad-core 1.5GHz RISC-V JH7110 processor, advanced GPU, and dynamic power control, it's tailor-made for demanding industrial vision applications like computer vision, deep learning, and graphics rendering.

Elevate your projects with cutting-edge technology!

[forlinx]

Introducing the FET-G2LD-C System on Module (SoM) powered by the high-performance Renesas RZ/G2L processor! 🚀 Featuring a Cortex-A55 CPU, Mali-G31 GPU, and a variety of display interfaces, this SoM is perfect for industrial, medical, and transportation applications. Operating at industrial-grade temperatures from -40°C to +85°C, it's built to withstand harsh conditions.
