#EmbeddedDevelopment

[adafruit]

Metro RP2350 take 5 🔄🌟🤞

Sometimes mistakes are made in prototyping; that's why they're prototypes. The error in rev D was funny: while making the QFN80 footprint, the pins got placed clockwise rather than widdershins. Not surprisingly, that board didn't come up at all, so here's a full rip-up and reroute, with the correct pinout this time! Fingers crossed. Hopefully, this is the final revision, and we can move on to other RP2350 boards we have cooking.

[blevoice]

KT1025A and Bluetooth Data Transmission: Efficient Applications of BLE and SPP

In today's interconnected world, Bluetooth technology meets not only audio transmission needs but also plays a key role in data transfer. The KT1025A chip offers excellent Bluetooth data transmission features, supporting two main modes: BLE and SPP.

BLE Transparent Transmission: A Power-Efficient Solution

Designed for low-power applications, BLE is ideal for devices requiring long operation times with minimal power consumption. KT1025A supports standard BLE data transmission, ensuring stable connections and data interaction between devices. This makes it a top choice for smart home and health monitoring devices.

SPP Transparent Transmission: A Classic and Reliable Option

Based on the classic Bluetooth protocol, SPP provides higher data transfer rates and stability. It's perfect for applications needing fast and reliable data transmission, such as industrial control and medical data collection.

Flexibility and Reliability in Data Transmission

Whether using BLE or SPP mode, KT1025A ensures efficient and reliable data transmission. The built-in protocol stack handles the complexities of Bluetooth connections, allowing developers to focus on application development.

Practical Application Cases

In smart home systems, KT1025A can connect various sensors and controllers via BLE for seamless communication. In medical devices, SPP mode can transmit high-precision monitoring data, ensuring accuracy and timeliness.

Conclusion

With its BLE and SPP data transmission capabilities, KT1025A provides developers with flexible and powerful tools. It can meet various needs, whether for low-power BLE applications or high-stability SPP transfers, driving the development of innovative products.

[jameswill01]

Trusted Local Experts for Embedded Software Projects

We deliver top-quality Embedded Software Development Services through our local team of experienced engineers. From firmware to real-time systems, get reliable solutions tailored to your product—right near you.

[forlinx]

Having trouble with your Forlinx AM62x development board?

Our latest troubleshooting guide covers common interface issues including power checks, I2C & SPI communication, USB & SDIO signal integrity, and more!

Get practical tips to quickly diagnose and fix boot failures and interface glitches.

Perfect for embedded developers working with OK62xx-C boards.

Stay tuned for Phase 2 with UART, CAN, PCIe, and LVDS troubleshooting!

[coredata123]

Top Embedded Systems Development Services for Smart Solutions

 Unlock the potential of technology with expert embedded systems development services. Our solutions are tailored for industries like automotive, healthcare, and industrial automation, offering efficient hardware-software integration and real-time applications. From product design and firmware development to system testing and support, we ensure innovation and reliability. Partner with us for scalable, high-performance embedded systems that drive smart and connected solutions for your business needs

[newnews24]

Microcontrollers: Deciphering Types and Memory Configurations

Microcontrollers serve as the backbone of embedded systems across a multitude of applications, with varying types and memory configurations to meet diverse needs. This article provides an in-depth analysis of microcontrollers, categorizing them based on their bit architecture (8-bits, 16-bits, 32-bits, and 64-bits) and memory configurations (embedded and external). By examining the characteristics, capabilities, and applications of each type, this article offers insights into selecting the most suitable microcontroller for specific embedded system requirements.

Microcontrollers play a crucial role in powering embedded systems, ranging from consumer electronics and automotive applications to industrial automation and IoT devices. Understanding the different types of microcontrollers and their memory configurations is essential for engineers and developers to design efficient and reliable embedded solutions.

Types of Microcontrollers

2.1. 8-bit Microcontrollers:

8-bit microcontrollers are known for their simplicity, low cost, and suitability for handling basic control tasks. They find applications in entry-level consumer electronics, home appliances, and simple automation systems.

16-bit Microcontrollers:

16-bit microcontrollers offer improved processing power and memory capabilities compared to their 8-bit counterparts. They are commonly used in more advanced consumer electronics, automotive systems, and medical devices.

32-bit Microcontrollers:

32-bit microcontrollers provide enhanced performance, higher computational capabilities, and support for complex algorithms. They are widely deployed in industrial automation, networking equipment, and high-end consumer electronics.

64-bit Microcontrollers:

64-bit microcontrollers represent the pinnacle of processing power, enabling advanced computation, multitasking, and handling of large data sets. They find applications in high-performance computing, embedded servers, and data-intensive applications.

Memory Configurations

Embedded Memory:

Microcontrollers with embedded memory integrate non-volatile memory (e.g., flash memory) directly onto the chip, offering a compact and cost-effective solution. Embedded memory is suitable for applications requiring fast access to program code and data storage.

External Memory:

Some microcontrollers utilize external memory interfaces to connect to additional storage devices such as RAM, EEPROM, or SD cards. External memory configurations provide flexibility for expanding storage capacity and accommodating larger datasets in embedded systems.

Applications and Use Cases

Microcontrollers, with their diverse types and memory configurations, cater to a wide range of applications including:

Consumer Electronics: Smartphones, wearables, home automation devices.

Automotive Systems: Engine control units (ECUs), infotainment systems, driver-assistance systems.

Industrial Automation: PLCs, motor control, human-machine interfaces (HMIs).

IoT Devices: Sensors, actuators, edge computing devices.

Medical Devices: Patient monitoring systems, diagnostic equipment, implantable devices.

[industrydesignservices]

Decrease your time to market by leveraging our end-to-end Embedded Software Engineering Services for different OS platforms and hardware architectures. To know more about browse: https://teksun.com/ Contact us ID: marketing@teksun.com

[adafruit]

Fruit Jam RP2350B credit-card mini computer with all the fixin's 🍓🍇💾

We were catching up on a recent Hackaday hackchat with Eben Upton (https://hackaday.io/event/202122-raspberry-pi-hack-chat-with-eben-upton) and learned some fun facts: such as the DVI hack for the RP2040 was inspired by a device called the IchigoJam (https://www.hackster.io/news/ichigojam-combines-strawberry-and-raspberry-to-deliver-a-raspberry-pi-pico-powered-educational-micro-66aa5d2f6eec). We remember reading about this back when it was an LPC1114, now it uses an RP2040. Well, we're wrapping up the Metro RP2350 (https://www.adafruit.com/product/6003), and lately, we've been joking around that with DVI output and USB Host support via bit-banged PIO, you could sorta build a little stand-alone computer. Well, one pear-green-tea-fueled-afternoon later we tried our hand at designing a 'credit card sized' computer - that's 3.375" x 2.125", about the same size as a business card (https://hackaday.com/2024/05/07/the-2024-business-card-challenge-starts-now/) and turns out there's even a standard named for it: ISO/IEC 7810 ID-1 (https://www.iso.org/standard/70483.html).

Anyhow, with the extra pins of the QFN-80 RP2350B, we're able to jam a ridonkulous amount of hardware into this shape: RP2350B dual 150MHz Cortex M33 w/ PicoProbe debug port, 16 MB Flash + 8 MB PSRAM, USB type C for bootloading/USB client, Micro SD card with SPI or SDIO, DVI output on the HSTX port, I2S stereo headphone + mono speaker via the TLV320DAC3100 (https://www.digikey.com/en/products/detail/texas-instruments/tlv320dac3100irhbt/2353656), 2-port USB type A hub for both keyboard and mouse or game controllers, chunky on-off switch, Stemma QT I2C + Stemma classic JST 3-pin, EYESPI for TFT displays, 5x NeoPixels, 3x tactile switches, and a 16-pin socket header with 10 A/D GPIO + 5V/3V/GND power pins. The PSRAM will help when we want to do things like run emulations that we need to store in fast RAM access, and it will also let us use the main SRAM as the DVI video buffer.

When we get the PCBs back and assembled, what should we try running on this hardware? We're pretty sure it can run DOOM. Should that be first? :) We also need a name. Right now, we're just calling it Fruit Jam since it's inspired by the IchigoJam project.

[blevoice]

KT148A Voice Chip: A Powerful Tool to Enhance the User Experience of Smart Soymilk Makers

The KT148A voice chip from Qingyue Electronics significantly enhances the user experience of smart soymilk makers with its unique advantages. It has a large - capacity voice storage space, allows users to change voices by themselves, features a low - power design, and can be reprogrammed.

Smart soymilk makers emerged from modern people's pursuit of a healthy lifestyle and a convenient home life. In the fast - paced urban life, soy milk is popular among consumers of all ages due to its rich nutrition and easy absorption. With the advancement of technology and the popularity of intelligence, smart soymilk makers not only meet the demand for a healthy diet but also integrate elements of convenient operation and intelligent experience. The KT148A voice chip adds a voice - broadcasting function to it, further improving the user experience.

The KT148A is a 32 - bit DSP voice chip with a standard SOP8 package. It has an internal 420KByte voice space, can support a maximum voice length of 420 seconds, supports multi - segment voices, can directly drive a 0.5W speaker, and allows users to change voices independently.

Chip Advantages

High Cost - effectiveness: Compared with traditional OTP chips, the process improvement reduces costs, and it can be reprogrammed.

Convenient Voice Replacement: Users can change voices by themselves through the computer - side serial port without expensive tools.

High - quality Sound Pursuit: The chip has sufficient built - in space to achieve a higher sound quality effect.

Functional Features

Built - in Flash Memory: With an ultra - small SOP8 package, it has a built - in 420KByte voice storage space, supports multi - segment voice storage of up to 420 seconds, ensures smooth voice broadcasting, simplifies hardware design, reduces costs and integration application difficulties, and is easy for engineers to get started.

User - changeable Voice: The firmware of the chip opens this function, enabling flexible voice customization, such as "Welcome to use XXX intelligent voice soymilk maker", "Turn on the power", etc.

High - quality Sound Playback: It uses advanced audio processing technology to ensure clear and natural voice broadcasting, avoiding misunderstandings or operational errors caused by poor sound quality.

Low - power Design: The standby power consumption is less than 25ua. Optimized for the energy - saving needs of smart home appliances, the power consumption in the low - power mode is less than 1.5uA, extending the service life of the soymilk maker and conforming to the modern family's pursuit of environmental protection and energy - saving.

Application

The KT148A chip is applied to smart soymilk makers, with clear sound, loud volume, simple operation, and no pressure on lithium - battery power supply.

Reasons for Engineers to Select the Chip

It is a 32 - bit DSP voice chip with an internal oscillation of 5MHZ and a PLL up to 120MHZ.

The operating voltage is 2.0 - 5.5V, and there are hardware details differences when the power supply is less than 3.3V.

The standby power consumption is less than 25ua, and there is a low - power mode of 1.5uA.

It has a 16 - bit PWM output and can directly drive an 8 - ohm / 0.5W speaker.

It provides tools to convert audio formats by oneself, and the operation is simple.

It can support up to 200 seconds at 16KHZ and up to 400 seconds at 8KHZ.

Customers can directly change the voice content through the computer - side tool software and the serial port.

It supports one - wire serial port control and can customize various protocols as needed.

It supports 224 - segment addresses and can be expanded as required.

It has hardware iic and UART interfaces and can customize various functions for customers.

The chip can be reprogrammed, so there is no need to worry about batch problems caused by incomplete testing.

The KT148A voice chip has two versions: one - wire serial port and button - triggered. With a small SOP8 package, it is flexible and easy to integrate into scenarios such as toys, home appliances, industrial control, and security alarms, and there are already a large number of successful application cases.

For complete technical data, such as datasheet, schematic, pcb diagram, user manual, quick application guide: KT148A Voice Chip technical resource

For Product details, product information, and sample acquisition and ordering links: KT148A

#VoiceChip #KT148A #SmartSoymilkMaker #VoiceBroadcasting #LowPower

[viraj096]

Points To Consider When Developing Embedded Software

Debugging is the process of fixing errors from a specific piece of software. It also looks for any software issues and fixes them. The majority of the time, this is done to prevent errors or unexpected behavior.

Read full article: https://articlescad.com/points-to-consider-when-developing-embedded-software-76304.html

[technoscriptsemb-blog]

Many Companies hiring in Embedded Systems Get Trained, Become Expert and Get Placed New Batch starting from 28 june 2021 Confirm your admission now!! Follow @technoscripts Follow @technoscripts Follow @technoscripts For more details about the course or project DM us --------------------------------------------- Follow @technoscripts for more technical stuff --------------------------------------------- Follow @technoscripts Follow @technoscripts Follow @technoscripts For more details about the course or project DM us --------------------------------------------- #embeddedplacement #technology #engineering #code #electronicmusic #techhouse #coding #embeddedsystems #embedded_system #embeddedproject #placement #bestinstitute #bestembeddedinstitute #projects #embedded_programer #embeddeddesign #technoscripts_projects #technoscripts_placement #embeddeddevelopment #embeddeddeveloper #embeddedprogramming #clanguage #engineers #pcb #roboticelectronics #diyprojects #iot #iotdeveloper #clanguageprogramming #cdeveloper https://www.instagram.com/p/CQaT7mxrqF4/?utm_medium=tumblr

[forlinx]

Buildroot App Integration on Allwinner A40i: Step-by-Step

1️⃣ Create package/helloworld directory

2️⃣ Write Config.in + helloworld.mk (case-sensitive!)

3️⃣ Enable in sun8iw11p1_hf_defconfig

4️⃣ make menuconfig → compile → pack

💡 Key Insights:

.mk scripts glue Buildroot’s build system to your app’s Makefile

Error Alert: Directly overwriting .config breaks builds! Use savedefconfig instead

Final binary lands in /bin post-compilation 📦

Allwinner A40i system on module

👉 Contact us: sales@forlinx.com

[electronicsbuzz]

https://electronicsbuzz.in/microchips-mplab-ai-coding-assistant-enhances-embedded-development/
