What is half-adder and full-adder combinational circuits?

So this question came up in the codeblr discord server, and I thought I would share my answer here too :3

First, a combinational circuit simply means a circuit where the outputs only depends on its input. ( combinational means "Combine" as in, combining the inputs to give some output )

It is a bit like a pure function. It is opposed to circuits like latches which remembers 1 bit. Their output depends on their inputs AND their state.

These circuits can be shown via their logic gates, or truth tables. I will explain using only words and the circuits, but you can look up the truth tablet for each of the circuits I talk about to help understand.

Ok, so an in the case of electronics is a circuit made with logic gates ( I... assume you know what they are... Otherwise ask and I can explain them too ) that adds 2 binary numbers, each which have only 1 character.

So one number is 1 or 0

And the other number is 1 or 0

So the possible outputs are are 0, 1 and 2.

Since you can only express from 0 to 1 with one binary number, and 0 to 3 with 2, we need to output 2 binary numbers to give the answer. So the output is 2 binary numbers

00 = 0

01 = 1

10 = 2

11 = 3 // This can never happen with a half adder. The max possible result is 2

Each character will be represented with a wire, and a wire is a 0 if it is low voltage (usually ground, or 0 volts) and a 1 if it is high voltage (Voltage depends. Can be 5 volts, 3.3, 12  or something else. )

BUT if you only use half adders, you can ONLY add 2 single character binary numbers together. Never more.

If you want to add more together, you need a full adder. This takes 3 single character binary numbers, and adds them and outputs a single 2 character number.

This means it have 3 inputs and 2 outputs.

We have 2 outputs because we need to give a result that is 0, 1, 2 or 3

Same binary as before, except now we CAN get a 11 (which is 3)

And we can chain full adders together to count as many inputs as we want.

So why ever use a half adder? Well, every logic gate cirquit can be made of NAND (Not and) gates, so we usually compare complexity in how many NAND gates it would take to make a circuit. More NAND gates needed means the circuit is slower and more expensive to make.

A half adder takes 5 NAND gates to make

A full adder takes 9 NAND gates.

So only use a full adder if you need one.

Geeks for Geeks have a page for each of the most normal basic cirquits:

I hope that made sense, and was useful :3
