SECS/GEM on Canon MPA 600 Super Aligner Through the EIGEMBox

In the dynamic world of semiconductor manufacturing, ensuring that legacy equipment can keep up with modern communication standards is essential for maintaining productivity and efficiency. The Canon MPA 600 Super Aligner, a widely used piece of equipment in semiconductor fabs, often lacks the native SECS/GEM capabilities required for seamless integration into contemporary manufacturing systems. Enter EIGEMBox, a patented, plug-and-play solution that brings SECS/GEM compliance to legacy equipment without the need for extensive hardware or software installations.

In this blog, we will explore the benefits of using EIGEMBox to enable SECS/GEM on the Canon MPA 600 Super Aligner and how this can revolutionize your manufacturing process.

What is SECS/GEM?

SECS/GEM (SEMI Equipment Communications Standard/Generic Equipment Model) is a set of protocols developed by SEMI (Semiconductor Equipment and Materials International) to standardize communication between semiconductor manufacturing equipment and host systems. These protocols are critical for enabling automation, real-time data collection, and equipment control, which are essential for the efficiency and productivity of modern semiconductor fabs.

The Importance of SECS/GEM Compliance SECS/GEM compliance offers several significant benefits for semiconductor manufacturing: Automation: SECS/GEM protocols enable the automation of equipment operations, reducing the need for manual intervention and minimizing the risk of human error. This leads to higher throughput and more consistent production quality.

Data Collection and Analysis: SECS/GEM allows for real-time data collection from equipment, which can be analyzed to monitor performance, optimize processes, and predict maintenance needs. This data-driven approach helps in making informed decisions that improve overall efficiency.

Equipment Control: With SECS/GEM, equipment can be controlled remotely by the host system, allowing for better coordination and scheduling of manufacturing tasks. This ensures optimal utilization of resources and reduces downtime.

Interoperability: SECS/GEM provides a standardized communication framework, ensuring that equipment from different vendors can work together seamlessly. This interoperability is crucial for maintaining a cohesive and efficient manufacturing environment.

Challenges with Legacy Equipment

While SECS/GEM offers numerous advantages, many legacy equipment like the Canon MPA 600 Super Aligner lack native SECS/GEM capabilities. Upgrading these machines to meet modern standards can be a complex and costly process, often requiring significant hardware and software modifications. This is where EIGEMBox comes into play.

Introducing EIGEMBox

EIGEMBox is an innovative, patented solution designed to bring SECS/GEM capabilities to legacy equipment without the need for additional hardware or software installations. This plug-and-play device makes it easy to upgrade older machines, ensuring they can communicate effectively with modern control systems and integrate seamlessly into automated manufacturing environments.

Key Features of EIGEMBox

Plug-and-Play Convenience: EIGEMBox is designed for easy installation and operation. Simply connect the device to your legacy equipment, and it starts working immediately, without the need for extensive configuration or setup.

No Hardware or Software Installation Required: Unlike traditional SECS/GEM integration solutions that often require complex hardware and software installations, EIGEMBox eliminates these hassles. This makes it a cost-effective and time-saving solution for upgrading your equipment.

Patented Technology: EIGEMBox utilizes patented technology to ensure reliable and efficient communication between your legacy equipment and modern control systems. This guarantees seamless integration and improved operational efficiency.

Enhanced Data Exchange: With EIGEMBox, your legacy equipment can exchange data in real-time with control systems, enabling better monitoring, analysis, and optimization of manufacturing processes.

Benefits of Using EIGEMBox with Canon MPA 600 Super Aligner

Upgrading the Canon MPA 600 Super Aligner with EIGEMBox offers several significant benefits:

Extended Equipment Life: By enabling SECS/GEM compliance, EIGEMBox extends the operational life of the Canon MPA 600 Super Aligner, allowing you to maximize your investment in this equipment.

Improved Efficiency: Enhanced communication and control capabilities lead to better coordination of manufacturing tasks, increased throughput, and reduced downtime. This results in the overall improved efficiency of your manufacturing process.

Cost Savings: EIGEMBox eliminates the need for costly hardware and software upgrades, providing a more affordable solution for integrating SECS/GEM protocols into your manufacturing processes.

Seamless Integration: EIGEMBox ensures that your Canon MPA 600 Super Aligner can communicate effectively with modern control systems, enabling a smoother and more efficient manufacturing operation.

Case Study: Successful Integration of EIGEMBox with Canon MPA 600 Super Aligner

One of our clients, a leading semiconductor manufacturer, faced challenges in integrating SECS/GEM protocols into their Canon MPA 600 Super Aligner. After implementing EIGEMBox, they experienced a significant improvement in production efficiency. The plug-and-play nature of EIGEMBox allowed for a quick and hassle-free integration process, resulting in a 20% increase in equipment utilization and a 15% reduction in downtime. The client was able to extend the life of their existing equipment while achieving substantial cost savings. How to Get Started with EIGEMBox Ready to revolutionize your semiconductor manufacturing processes with EIGEMBox? Here’s how you can get started:

Contact Us: Reach out to our team for a consultation. We’ll assess your current equipment and provide tailored recommendations for integrating EIGEMBox into your manufacturing environment.

Easy Installation: Once you’ve decided to move forward, our team will guide you through the simple installation process. No need for extensive configuration or setup – just plug it in and start reaping the benefits.

Ongoing Support: Our commitment to your success doesn’t end with installation. We offer comprehensive support to ensure that your EIGEMBox operates seamlessly and delivers the desired improvements in efficiency and productivity.

Contact Us Today! Don’t let outdated equipment hold back your semiconductor manufacturing operations. With EIGEMBox, you can achieve modern communication and control capabilities without the need for costly hardware or software installations. Contact us today to learn more about how EIGEMBox can transform your Canon MPA 600 Super Aligner and drive your manufacturing processes forward.

[inspheretechnology]

Factory Automation Solution

https://www.insphere.com.sg/ We believe that every equipment in the factory can be connected and data can be made available to increase productivity, reducing costs and human errors and ultimately improving quality. Our customers value their alliance with us because of our product reliability, simplicity, expertise and professional support. ​

[einnosys-blog]

Global leader in SECS/GEM, GEM300, Smart Factory & Industry 4.0.

SECS/ GEM, the communication interface protocol for communication between a semiconductor equipment and fab host. Fab host is a software application that is controlling and monitoring equipment processing using SECS/GEM protocol. SECS/GEM compliant equipment can communicate with the fab host using either TCP/IP (using SEMI standards E37 and E37.1 - HSMS) or RS-232 (using SEMI standard E4 – SECS-I). The SECS/GEM standard interface is used to start as well as stop equipment processing, collect measurement data, select recipes for products and change variables. With SECS (SEMI Equipment Communications Standard)/GEM (Generic Equipment Model), all this can be performed in a standard way. SECS/GEM protocol has been standardized by the non-profit association SEMI (Semiconductor Equipment and Materials International). Check www.SEMI.org to learn more about SEMI standards and SECS/GEM protocol.

In simple words, the SECS/GEM standard defines messages, state machines and scenarios to enable factory host applications to control as well as monitor manufacturing equipment. GEM standard is officially designated as SEMI standard E30, but frequently referred to as the GEM or SECS/GEM standard. The GEM is beneficial for both device manufacturers and equipment suppliers as it defines common set of equipment behavior and communication capabilities to provide functionality as well as flexibility to support manufacturing. Since GEM standard has only a few semiconductor-specific features, it has been adopted by other manufacturing industries as well, such as PV.

Among the capabilities offered by the SECS/GEM standard is –

For a fab host to start and stop processing

For a fab host to select, download and upload recipes     from/to the equipment

For a fab host to query the equipment for values of     various process parameters and equipment configuration

For a fab host to set equipment configuration parameter     values

For equipment to send alarms to the fab host

For a fab host to define reports of various variables and     associate them with events such as lot start or wafer complete

For equipment to send various events and associated     reports to the fab host

Since SECS/GEM is a communication protocol, it is platform and technology as well as programming language independent. The host side of a connection is executing on a computer system provided by the factory, and the equipment side of a connection is running on a controller computer provided by the equipment manufacturer. This gives both – the fab as well as the equipment manufacturer interoperability, flexibility, and platform independence. Both, the fab and the OEM can develop their software application without having to worry about communication compatibility, as long as both of them are adhering to SECS/GEM standards.

EINNOSYS Inc offers software solutions for both - the FABs to integrate with FAB host as well as for the OEMs to integrate with their controller software. By integrating EIGEM – Einnosys SECS/GEM software, the equipment or fab host becomes SECS/GEM capable without having to learn the details of various SEMI standards.

SECS describe the communication between a host computer and the equipment using a single connection. In the original concept and even today in the most common scenario, the equipment provides a single SECS interface for exclusive use by a single host. The message types defined by SECS are partially asymmetric - some message types are defined only for host use, others are defined only for equipment, but also many of them are defined for the same use by either side.

However, there is a provision in the SECS standards for sharing a connection by specifying the device identification value in each message. The practice of connection sharing is not recommended for new deployments. It is a common practice that a connection is maintained for long periods of time and only interrupted if the equipment or host is rebooted. SECS connections are lightweight and don’t use much network bandwidth. It is possible to run several SECS connections on a typical desktop computer.

Products for Semiconductor Equipments:

   EINEM: SECS/GEM software for equipment and fabs

   Mobile Monitor: Monitoring critical equipment/recipe parameters on the mobile device

   Modbus Library for Android: Modbus library for Android platform

Products for Semiconductor Fabs:

   EINEM: SECS/GEM software for equipment and fabs

   Recipe Server/ Stepper Job Server: Manages recipes, including versions and audit trail of recipe changes across different equipment types

   Barcode Guardian: Prevents the wrong pour of chemicals and manages chemical inventory in the fab

   Reticle Tracker: Manages reticle inventory across multiple locations and offers time and cost saving reports

   Manual Wetbench Automation: Prevents wrong wafer dips on manual wet benches without an expensive upgrade

[einnosyssecsgem]

Introduction to SECS/GEM: Revolutionizing Semiconductor Manufacturing

What is SECS/GEM?

SECS/GEM (SEMI Equipment Communications Standard/Generic Equipment Model) is a set of standards developed by SEMI (Semiconductor Equipment and Materials International) to facilitate communication and control in semiconductor manufacturing. It allows equipment and factory systems to interact seamlessly, enabling automated processes, real-time data collection, and precise control over manufacturing operations.

History and Evolution of SECS/GEM

The SECS/GEM standards emerged in the 1980s to address the growing complexity and automation needs in semiconductor manufacturing. Initially, SECS-I (SEMI Equipment Communications Standard 1) used RS-232 serial communication. As technology advanced, the need for faster communication led to the development of HSMS (High-Speed SECS Message Services), which utilizes TCP/IP for quicker and more reliable data transmission.

Importance of SECS/GEM in the Semiconductor Industry In the semiconductor industry, precision and efficiency are crucial. SECS/GEM ensures that equipment from different manufacturers can communicate using a standardized protocol, reducing integration time and costs. This standardization enhances productivity, minimizes downtime, and improves yield by enabling precise monitoring and control of manufacturing processes.

How SECS/GEM Enhances Equipment Communication and Control

Detailed Overview of SECS/GEM Protocols

SECS/GEM consists of two main protocols:

SECS-I (SEMI Equipment Communications Standard 1):

Uses RS-232 for serial communication.

Suitable for environments where high-speed communication is not critical.

HSMS (High-Speed SECS Message Services):

Uses TCP/IP for faster communication.

Ideal for modern manufacturing environments requiring high-speed data exchange.

GEM provides a standardized model for equipment behavior, including status reporting, data collection, and control commands, making it easier to manage and integrate various equipment. Benefits of Using SECS/GEM for Equipment Communication Standardization: Facilitates seamless integration of equipment from different vendors.

Real-Time Data Collection: Enables continuous monitoring of equipment performance and process parameters.

Enhanced Automation: Reduces manual intervention, leading to higher efficiency and productivity.

Improved Yield: Precise control and monitoring help identify and rectify issues promptly, enhancing overall yield.

Examples of SECS/GEM in Action

Wafer Fabrication: SECS/GEM is used to monitor and control processes such as etching, doping, and deposition.

Assembly and Test: Ensures that testing equipment communicates effectively with the MES (Manufacturing Execution System) to provide real-time results and feedback. Implementing SECS/GEM in Your Manufacturing Process

Steps to Integrate SECS/GEM with Existing Equipment

Assessment: Evaluate your current equipment and determine SECS/GEM compatibility.

Selection: Choose appropriate SECS/GEM software and hardware solutions.

Integration: Install and configure the SECS/GEM interfaces with your equipment and factory systems.

Testing: Conduct thorough testing to ensure proper communication and control.

Training: Provide training for staff on the new system and its functionalities.

Challenges and Solutions in SECS/GEM Implementation

Compatibility Issues: Ensure that both old and new equipment can communicate using SECS/GEM standards.

Technical Expertise: Invest in training and, if necessary, consult with experts to facilitate smooth integration.

Cost: While initial implementation might be costly, the long-term benefits in efficiency and yield outweigh these expenses.
