#ATtiny85

[pulpob0t]

Prototype time!

My first project in 2025. It was nice trip down memory lane, returning to 8bit micro controller. I am still trying to get the hang of the printing setup and new filament so the printing is pretty poor on this one.

[synths-and-sensibility]

Somewhat unrelated to the vactrols, I decided to sit down and try to figure out how the hell to program the attiny's.

Good news is I got it working!

Great news is the attiny85 that I thought I fried is doing the thing!

[neververy4]

First ATTINY85 project!

(warning: video has actual flashing LED lights)

[ Video ID: A breadboard with a Blue LED on top of an 8-pin DIP Integrated Circuit on it. The Blue LED is flashing rapidly. There are other components on the breadboard in the background. End ID ]

Last week I bought some ATTINY85 Microprocessors to experiment and work with :) With my W65C02 project on hold until I can afford an oscilliscope, and my Radio project delayed because I can’t quite figure out how to reverse engineer the 8 pins on the volume knob, I wanted something else to work with. I’ve been wanting to mess with Atmel microprocessors (Arduino Uno runs on an Atmel ATMEGA328), and now’s a good chance!

I’m jumping straight to assembly with the ATTINY85; I don’t know any C/C++ code, and also I’m familiar with other processor Assembly languages, so I might as well. And other than different names for functions, it’s been pretty easy so far! Something I’m not used to is that this processor, despite being pathetically tiny, has 32 registers; I’m used to working with 8 Max.

Anyways, for the code explanation: When the processor first starts, it turns on PINB0, which is physical pin 5 on the processor. Then, after counting to 256 256 times, it turns off PINB0 for another 256^256 counts. I’m away from home while writing this, so my notes arn’t here, but if I remember correctly it came up to 200k microseconds? That adds up to about 400 nano seconds per on/off cycle, or 2.5 flashes per second. I can add in another loop to make it last longer, but before I do that I’d like to look about to see if there’s a smarter way to tackle this.

My next step after this, is to figure out how to get this processor to read digital inputs: My next project is to finally do something with my box of telephone rotary dials. I already have one spec’ed out for breadboard testing. I would LOVE to show it, but Tumblr has a One Video Per Post limit :(

[quartz-components]

You can purchase the ATTINY85 USB Development Board for just Rs. 255.00 on quartzcomponents.com. This affordable and versatile development board is perfect for your microcontroller projects. It features an ATTINY85 microcontroller and USB connectivity, making it a cost-effective choice for DIY electronics enthusiasts and hobbyists. Don't miss out on this great deal for your electronics projects!

[draegerit]

DIY Servotester für SG90 Servomotoren

In diesem Beitrag möchte ich dir zeigen, wie du dir einen kleinen Servotester für Servomotoren vom Typ SG90 erstellen kannst.

DIY Servotester für SG90 Servomotoren

Wozu benötige ich einen Servotester?

Mit einem Servotester kannst du einen verbauten Servomotor testen, ohne dass du eine Fernbedienung anschließen / aktivieren musst. Mit dem verbauten Drehpotentiometer auf dem Servotester kannst du den Servo zwischen 0° und 180° bewegen.

Servotester von Conrad Electronic

Du kannst dir auch einen fertigen Servotester von der Firma Conrad Electronic kaufen und hast alles gleich auf einer kleinen Platine. Im Lieferumfang ist alles, was du benötigst enthalten, jedoch kann man mit dem Set keine SG90 Servos zuverlässig steuern, denn die Frequenz bei diesem Set liegt bei 18Hz und der SG90 Servo arbeitet mit 50Hz.

Laut Anleitung benötigen man dafür wiederum zwei andere Bauteile, welche separat erworben werden müssen. Diesen Hinweis hätte ich gerne vorher gehabt. In dem kurzen Video zeige ich dir wie man mit dem Servotester einen kleinen Microservo 4.3 g steuern kann. https://youtu.be/V82SkNnVGhk

Benötigte Ressourcen

Wenn du den hier vorgestellten Servotester nachbauen möchtest, dann benötigst du: - einen ATtiny85*, - ein Drehpotentiometer*, - eine Lochrasterplatine*, - ein 400 Pin Breadboard*, - ein Powersupply für das Breadboard*, - eine 9 V Blockbatterie*, Hinweis von mir: Die mit einem Sternchen (*) markierten Links sind Affiliate-Links. Wenn du über diese Links einkaufst, erhalte ich eine kleine Provision, die dazu beiträgt, diesen Blog zu unterstützen. Der Preis für dich bleibt dabei unverändert. Vielen Dank für deine Unterstützung! Um den ATTiny85 zu bespielen, benötigen wir entweder ein kleines Board, auf welchen wir diesen stecken können oder wir bauen uns dieses selber. In letzterem Fall benötigen wir noch einen Arduino UNO, um diesen als ISP Programmer zu nutzen.

ATtiny85 Board

ATtiny85 auf dem Prototype Shield Dies kleines Projekt wird zunächst auf einem Breadboard aufgebaut und später, wenn es die Reife erreicht hat, auf eine Lochrasterplatine aufgebaut. Mit einem 3D Drucker kann man dann zusätzlich noch ein kleines Gehäuse drucken, welches dann die Schaltung besser schützt.

Aufbau des DIY Servotester für SG90 Servomotoren

Die Schaltung ist so klein, dass diese locker auf ein 170 Pin Breadboard passt.

Schaltung - DIY Servotester mit ATtiny85 Zusätzlich benötigst du noch zwei lange Breadboardkabel für die Spannungsversorgung. In meinem Fall nutze ich ein einfaches Powersupply Modul für ein min. 400 Pin Breadboard, somit baue ich diese auch auf ein solches auf.

Schaltung - ATTiny85 mit Drehpotentiometer und Servomotor Pinout des ATTiny85 Hier nun das Pinout des ATTiny85 Chips.

Pinout ATTiny85 chip

Programmieren

Zum Programmieren benötigen wir wie bereits erwähnt eine kleine Schaltung. Ich verwende hier meine Schaltung für den Arduino UNO. Installieren des Boardtreibers für den ATTiny85 Zunächst müssen wir den Boardtreiber für den ATTiny85 installieren, dazu fügen wir die nachfolgende URL zu den "zusätzlichen Boardverwalter URLs" in den Einstellungen hinzu. https://raw.githubusercontent.com/damellis/attiny/ide-1.6.x-boards-manager/package_damellis_attiny_index.json Wenn dieses geschehen ist, dann können wir im Boardverwalter nach dem Board attiny85 suchen und den Treiber installieren.

Boardverwalter der Arduino IDE mit ATTiny85 Exkurs - Upload eines Sketches mit dem Arduino UNO auf einen ATTiny85 Im Beitrag ATtiny85 mit dem Arduino UNO beschreiben habe ich dir bereits gezeigt, wie du ein Programm für den ATTiny85 mithilfe des Arduino UNO hochlädst. Im nachfolgenden YouTube-Video habe ich dir das noch einmal erläutert und im Detail gezeigt, wie dieses mit dem selbst gelöteten ISP Programmer funktioniert. https://youtu.be/2OXltNSuAmw Erstellen des Programmes in der Arduino IDE Das kleine Programm erstellen wir wie folgt: #define servoPin 0 #define potiPin A1 void setup() { pinMode(servoPin, OUTPUT); } void loop() { int potiValue = analogRead(potiPin); int microseconds = map(potiValue, 0, 1023, 400,2400); digitalWrite(servoPin, HIGH); delayMicroseconds(microseconds); digitalWrite(servoPin,LOW); delayMicroseconds(20000-microseconds); } Wenn man das kleine Programm auf den ATTiny85 hochgeladen hat, sollte sich dann ein angeschlossener Servo über den Drehpotentiometer steuern lassen. Read the full article

[ainow]

Attiny85 Development Board

The ATtiny85 development board is similar to the Arduino, but cheaper and smaller (of course a bit less powerful). With a whole host of shields to extend its functionality and the ability to use the familiar Arduino IDE, this ATTINY85 Development Board is a great way to jump into microcontroller electronics. ATtiny85 development board come with the USB interface. Coding is similar to Arduino, and it uses the familiar Arduino IDE for development. This is a digispark clone. It has 6 port with several functions. Depending on the programming (with Arduino IDE) can it have 6 digital I/O, 4 analog inputs or 3 PWM outputs. It can be powered by a USB port or an external power supply of 6-35V DC.

Features:

Support for the Arduino IDE 1.0 (OSX/Windows/Linux).

Power via USB or External Source or 7-16 v to 5 v (automatic selection).

The On – board, 150 ma 5 v Regulator.

Built – in USB and serial was debugging).

6 I/O Pins (2 inform the for USB only if your program actively communicates over USB, otherwise you can use all 6 even if you are programming via USB).

8 k Flash Memory (about 6 k after bootloader).

The I2C and SPI (vis USI).

PWM on 3 pins (more possible with Software PWM).

The ADC on 4 pins.

The Power LED and the Test/Status leds.

[fuzzkaizer]

MiniMo

"The miniRacks are full modular systems including a complete set of soldered miniMOs, an enclosure (power adapter plus power rails and a miniRack Case), and a free set of accesories -a portable, convenient and self-contained modular lab 😀

miniMO is an 8-bit synthesizer Modular synth built around the ATtiny85 processor, a relative of the popular Arduino. All miniMOs are identical; you load them with different programs according to the system you want to make. If you have three modules, you can program them to be three oscillators, or two oscillators and a filter, or a sequencer, an oscillator and an envelope generator, or any other configuration that suits your fancy."

cred: minimosynth.com

[vulpes-aestatis]

trick or treat!

You get: ATtiny85 microcontroller
