#front panel

[commodorez]

A little bit of soldering later, and the new Cactus front panel is coming together nicely.

Did a few power-on smoke test, then installed the IC's.

After that, the only thing left to do was plug it into the Cactus SBC and see if it works.

Damn, that's 【 æｓｔｈｅｔｉｃ】（く内ラ） as fuck.

After I figured out that my bench supply was causing brown-outs, I swapped it for a simple wall wart, and magically things started working right.

So far, I've identified a few faults that need fixing, but the bulk of things are working as intended. Hell yeah. Only took me 5 years to get around to it...

One feature that has never worked right on the hand-wired prototype now works: Memory Protect. It effectively prevents both the CPU and user from writing to RAM while the Protect light is illuminated, assuming that the RAM in question has the appropriate circuitry installed. It's a feature I stole from ...that was inspired by the OSI-300.

Anyway, I'm hype as fuck right now.
