#diy instruments

[koko-mariano]

24 inch rain maker instrument made from PVC found in an old urban planning map. Inside is filled with rice.

[technician-the]

It's bandcamp Friday!

 Most of my music is downloadable for free, but I still think today is a good day to check it out!

[amerkloster]

Cleaning a fretboard

[kofeklub]

[docileeffects]

[bivouacrecording]

The Instrument : Part 2: Components

<- Go to Part 1

Cables

The veins and arteries. As is tradition with any new idea I have, I make new cables. Mostly because the cables I made previously were all custom that the lengths or connectors just cannot be used anywhere else. Coming off of the relay box, I kept the solder gun warm and went straight into making cables. I used Canare wires and Yongsheng connectors. Easy to source for me and good quality.

I never made a MIDI cable before and believe me, they look really beautiful with these metal connectors (see above).

I made a total of 37 analog/midi cables.

I also made:

Four 10 pin remote control cables for the Revox units.

One 15 pin extension cable for the Fostex D2424

One DB25 AES I/O cable for communication between the DM1000 and SPX units.

This makes a grand total of 43 finished cables, 93 connectors, and about 90 meters of cable. All93 heat shrunk and perfectly made. 93

You can b93elieve me when I say 93 that I was counting 93down Every. Last. One. 9.3.

Phew. 93

Of course after you finish with something, you always think of how it could be better. After connecting it all up, I am really wanting to have a more polychromatic palette of cables rather than just a rat's nest of black (boring). Maybe I can sell the black cables and make a more colorful back-end (gulp).

MOTU Midi Express XT

So now I needed something to manage the MIDI messages between all of my equipment. I have used MOTU software and hardware for 20 years and their MIDI patchbays were always affordable and reliable so I found a used one for a reasonable price and wired it up.

In my research I found this article and decided MOTU was the way to go.

RME Digiface USB

Connecting the DM1000 to the computer took a bit of consideration.  I knew that once the audio was converted in the DM1000, I wanted it to stay in the digital domain wherever it went until it was output again. So I needed a multichannel USB interface that didn't take up another rack space and had a reasonable cost. I didn't need any other preamps or other extra things, just a digital I/O. The RME was the best solution and had the best reputation. This was the only thing that I bought new.

The DIGIface has 32 digital I/O via 4 banks of ADAT I/O which allows me to input/output sound from the computer (to the recorders) and manage the audio routings throughout the instrument using the included RME TotalMIX software. Every single connection was used like it was made just for this.

Tech 21 NYC Midi Mongoose

A small MIDI foot pedal that can output 128 MIDI program change messages. So far I have programmed it to start the Freeze layer playback in each internal effect. The foot pedal is a bit fiddly when you want to go from say, 3 to 65, but it should make you arrange the programs in such a way that makes it easier for you. To make it more dynamic and user friendly, I will program more functions in the MIDI translator program.

Speaking of which...

Computer and Software

This is the climax of this post. At least for me. Best take a seat for this one. <br><br>

Welcome to the Brain. The computer exclusively manages all MIDI and audio routing.  For the MIDI translator, I use Bome MIDI Translator PRO (BMT). An amazing program that allows you to translate anything to anything (really, i mean it) and more.

I hired the Bome forum moderator, Steve Caldwell, to help me make a program using BMT that remembered the fader, button, and knob positions between each USER DEFINED layer on both REMOTE layers. The USER DEFINED layer on the DM1000 has 4 banks but they are only overlays that are meant to be used one at a time. With this custom program, I now have a total of 8 INDEPENDENT banks over two REMOTE layers (384 controls total) that can be recalled with a button press and be used to control anything via MIDI. This was not how Yamaha intended it but this is the kind of power MIDI can have.  This rack mountable DM1000 just got a whole lot BIGGER.

[Techie side note: The only drawback for this is that you cannot exclude (Recall Safe) these faders from a scene change like you can for the top level faders. Still searching for a solution or workaround...]

As an example, I mapped all of the parameters of each SPX2000 unit AND all 4 internal effects to the faders and knobs allowing live control of multiple parameters at the same time in any combination using BMT. The controls can also be automated with the internal automation on the DM1000. The sky's the limit.

I should add that even on the top layers, each control for the audio channels 1-48 (faders, knobs,  buttons) can be used exclusively as a MIDI controller (no audio thru the channel) or mixed together (MIDI fader next to an audio fader) side by side, as desired. For example, I am using faders 9-16 to exclusively send MIDI messages to control the A77s (for now). Additional buttons (72 buttons) can be programmed on the USER DEFINED KEYS section. So taking all of this into account, you can have a grand total of 600 controls* for other MIDI instruments from a single console. (Not counting all the other function buttons on the console that transmit MIDI. Even the headphone level knob sends MIDI!)

* Note: I think there is a limit with the amount of unique MIDI messages that can be programmed, but using BMT you can program a computer keystroke to control software, use SysEx, and so on.

Studio

Okokok. Deep breaths.

I had to get some furniture to put all this stuff. I had a custom table made per my specifications and  got rid of all the old furniture (green desk).  For monitors, I bought a pair of JBL Studio 2 speakers. These are powered by my old, underused Yamaha Hi-fi amplifier (RX-V357) and subwoofer that I woke up after a very long, dusty, moldy, sleep in storage.

The JBL speakers are designed to be recessed in a wall but I custom made an aluminum enclosure for them and hung them on speaker wall mounts. This was a cost saving measure but also a space saving one, as these speakers are not as expensive, deep, and boxy as a typical monitor.

I opted for a standing studio to practice a 'live' performance. After so much soldering, I really didn't mind standing and its good practice for the future. I found I move faster that way, though I do have to take breaks more often. I had to put the DM1000 on sturdy packing paper boards to prop it up.

Sonosax Mini R82

My trusty Sonosax. This and my other recorders, are the breath that give this instrument life. I don't create sound.

I made a new custom cable that connects to the digital stereo out of the DM1000 for quick sketches and stereo recordings. At the end of the day I take it on the road to listen to the daily recordings and take notes.

Fostex D2424 LV

Last but not least. This was the last thing I bought. It was pretty much a new unit and very reasonably priced for a 24-track recorder. I only needed to get a compatible HD, replace the lithium battery, and change the FAN which was SO noisy. I replaced it with a Noctua NF-A8 ULN (Ultra low noise) and now it lives silently under my desk. If you have one of these HD recorder units, I HIGHLY recommend this upgrade. I found out that the reason that the fans are so loud is because the unit does not have a thermometer that regulates fan speed. So the fans are just running at its maximum speed all the time, hence all the noise. With research, I found that the Noctua was one of the quietest fans on the market at its highest RPM.

I remember these Fostex units way back when and it was the remote that caught my eye. All of the controls and display are contained in a removable unit that can be extended and used as a remote control. I contacted Fostex and their great customer service answered any questions I had with this long discontinued unit. I have my eye on another one just for parts for the future.

The D24 + DM1000 will essentially be my DAW. To tell you the truth I have been on the fence about using this. On one hand it's a solid piece of equipment. On the other its discontinued. I reassure myself saying that many people still use vintage synths so this should be no different, no? I assume, vintage synth owners always have something in the back of their mind hoping that their synth doesn't die before they sell it. Even the A77 has a better chance of lasting longer than this unit (and it has). By using a computer it will be future proof but it also has its shortcomings. In any case, since the DIGIface is managing the audio via my computer, I can also use my DAW to playback and record files if needed. I guess it is reassuring that these equipment are built within their capabilities so there will be fewer surprises during use. I have evolved to embrace and enjoy the fleeting nature of sound, maybe I should also embrace and enjoy the finite life of recording equipment.

There is some housekeeping that needs to be done with this machine. The HD is cloned to another one after each session and also backed up on a computer. NOS compatible hard drives for the unit are still easily bought at the moment. I'd better stock up. The manual is very extensive and a little crazy at times, but easy to read. Once you start using it, it gets pretty easy and there is just something about pressing a physical click-y button that just makes things more fun. The audio can also be recorded in real time to a DAW.

One thing is that new HDs need to be formatted in the unit before use. This takes FOREVER. 160 GB took about 12 hours to format. So its best to format all your HD ahead of time to save time. I probably didn't need to get the 160GB HD. I think 40 or 80 GB would have been more than enough for me.

Special Mention:

Deity V-Lav Microphones

In my recent recording tests, I realized that although you can hear the tape machines in a 'live' setting, you miss this experience in the audio recording. This means you cannot distinguish the edits recorded to the tape and the edits made by stopping/ starting the machine. I tried several options from mounting microphones on stands, or on the desktop but they were in my way and were going to be pretty expensive if I got 4 of them. I needed a smaller, affordable solution.

I had made some videos for Deity a few years ago and they gave me a sampler of all their microphones at the time to try out. The D2 and D3 are great short shotgun microphones and great for field recording. They also gave me one V-Lav and I was amazed how easy it was to use. Its built-in 'smart' power supply means you can plug it anywhere which is great because some pro lavaliers usually require a 10V phantom supply via a special adapter.  I gave my contacts at Deity a ring and asked if I could have some more for my new sound project. They graciously sponsored 3 more microphones and D-XLR adapters for the project. Now the recordings all have the tape machine sounds which indicate stop/start of the audio and a sense of movement. I know you haven't heard any sounds yet but trust me it is just the right touch.

Which brings us back to...

Today. One year after our journey, and the beginning of a new one. As you can see the amount of thought and hours put into creating this instrument were many but worth it. I feel that it is truly an extension of me and reflects the way I think and move.

Stay tuned for sounds, articles, and videos of how this instrument evolves as well as a more in depth look at how I configure my components and creation process.

Thanks for reading!

In Winter 2021 I was able to finally present this instrument to the public during the Vital performance in Shanghai. Read about it here.

[wickedwitchoftheweigels]

doohickey improvisation (6/2/25)

items used

digitech death metal

peavey backstage 30

peavey xrd 680

and doohickey

[koko-mariano]

Process of making modern day Luntang instrument made from found objects; Luntag 3033

[culmaer]

I've had a waterbuck horn lying around since last year, and I've finally gotten round to drilling an aperture in the end to receive my Siem vd Veen cornetto mouthpiece. it comfortably blows a beautifully full and resonant Ab

the horn is only just 60cm in length which is apparently, luckily, the approximate length of a treble cornetto (oboes, flutes, tenor recorders are all approx. 65cm long), but of course, the horn bore is irregular and significantly more conical than a cornetto

now I've not yet dared to drill in any finger holes; I wouldn't know where to put them (although recorder maker Tim Cranmore has suggested that the size of the holes is more important than the placement, for flutes at least). so it's effectively got "all the finger holes covered" for testing purposes.

referring to the Monk instruments/Jeremy West fingering chart above, the pitches we want are G, Ab and A below the stave, Bb on the stave, F on the fifth line, and B♮ above the stave (I find this very irritating btw, that A overblows to B-flat overblows to B-natural. recorder and flute have trained me to expect octaves (this is also why I found clarinet so frustrating))

as mentioned, it does naturally sound a low Ab ! it's a little tricky to lip it up for the A, but I think that's just because I lack the technique and it should be doable with practice. lipping down to G sounds very bad. weak and hollow. maybe this is also down to technique ?

overblowing does get somewhere around an unstable A, we want Bb, so that's not too bad. and above that the F is pretty damn in tune and stable (though I lack the stamina to do it consistently). I have not been able to get anything higher than that. But I think the move now is to practice and get my lips trained before I start adding finger holes. otherwise I won't be tuning them properly and that would be silly

[gaboon-vampire]

Now I'm practicing rosining my bow with good bow-hand position.

Not much to listen to at the moment.

New bow, new rosin, new strings, nothing is sticking to anything.

Bowing a string is alternating stick-slip behavior. The sticking is not happening yet.

This shit's not easy.

[chillbeatsblogrusland]

Погружаясь в вечер с приглушенным светом, слушая любимый чилл трек, задумайтесь: что связывает вас с чем-то большим, чем вы сами? Вы всё еще сосредоточены на собственных целях и выживании? Музыка вас окружает, отражая внутреннее состояние. Что вы строите своим временем, усилиями, жизнью? Это что-то трансцендентное или личное путешествие? И как этот выбор влияет на ваши чувства, действия, даже привычки прослушивания? Где ваш фокус, и что он создает? 🎶✨ #lofi #ambient #интроспекция

Новейшие лоу-фай музыкальные вибрации и интроспективные мысли от ChillBeats

[hwinn]

All sticker club subscribers get the twisty mic, sticker club plus subscribers get all 5. Check me out on patreon

[iantarby]

GUESS WHO FOUND AN ORGAN FOREVER AGO?

Found an organ (psure it's an AceTone B-422) on the side of the road one day while some guy was clearing out his dad's house, and managed to get this organ for free. Dude said he didn't get a chance to try it out, nabbed it anyway and stuffed it in my room.

Turns out, it doesn't work.

Turns out, it has a bunch of built in features that DO work.

There's a built in vibrato, a built in reverb, a built in Rhythm Ace Drum Machine, and a God Damn Leslie-branded rotary speaker built in. The drum machine, speaker, and rotary speaker all for sure work, and since it's a 60s organ that reverb is pmuch guaranteed to be a spring tank, which is easy to repurpose. The vibrato would be cool to mess with, too. Lastly, there's a "Brilliance" switch which I'm really curious about.

As for the rest of the organ, I have a bunch of options:

1. I rip out all the keys, replace them with modern midi controllers, and turn the whole thing into a custom recording station. Problem is, the two keyboards are 44 keys each, which is pretty rare for midi controllers. They're also bigger keys than normal, so maybe there's a way to make them work, but that also makes the depth of the keys an issue I'll have to tackle. It also means the 13 bass pedals would be useless.

2. I get 1-4 Arduino boards, and rewire the keyboards so I have 2 44-key controllers, 13-pedal controller, and if I wanna get crazy with it the swell pedal and whatever other knobs I want for midi controls. Problem is, I know nothing about Arduino or digital midi, and I'm already diving headfirst into several unfamiliar disciplines for this project as is. DOUBLE problem is, from what I can tell it would be difficult if not impossible to make the original keybeds velocity sensitive. Triple problem is, if I do decide to toss the key beds, I can't go back and Arduino it up later. I'm not gonna be able to hold onto those parts, and there's no way I could justify having a whole second house organ just to reattempt it.

3. I cut my losses, rip out the relevant electronics, and toss the rest

If I go with either of the first two (read: fun) options, it's also worth considering all the space around the keys, where I can theoretically add whatever. I've tossed around the idea of putting a 2x4 group of drum pads, maybe some knobs or even a ribbon controller somewhere. I could even put a screen there, either with real time feedback or built in synths or digital effects (maybe a raspberry pi or small computer affordable to run soundfonts or even VSTi's natively; imagine having a DIY touch screen with drawbars next to the keyboard to adjust settings, that'd be sick)

And none of that takes into consideration the multitude of cosmetic modification options possible; Paint, veneer, upholstery, LEDs, lights, VU meters, metalwork, leather, the list goes on.

I've got a bunch of ideas and I'm in the process of getting the tools together to move forward with this project.

I'm sure I can also upgrade stuff in the future.

But I'm seriously considering turning this thing into the ultimate keyboard performance desk, both for YouTube stuff as well as live (since, theoretically, it'll be a LOT lighter once the speakers and motor(s) are pulled out)

If anyone has experience with doing any of this sort of thing, I'd love to pick your brains for more info on all this stuff. Working on researching for a YouTube video about the project, including a history of the Ace Tone company that made it (with probably too much emphasis on it being founded by the same dude who founded Roland several years later).

It's a big project, but I think it'd be worth it. I'm more excited about this than I have been about virtually anything else in years.

[babilano-celentano]

i soldered my first diy kit, a noise generator designed by Paul Tas. It has light- and touch sensors and nice big chicken head knobs.

gnarly!

[nepacala]

[tenshunnoise]

Uploaded some minimalist beats for scratching.

check it out
