#DIY electronics with Raspberry Pi

[operator-4rch4ng3l]

[CYBERDECK PROJECT ACTUAL NAME YELIEL ONLINE]

My cyberdeck is functional, I included an internal shot as well. I have plans on adding a power switch to the front cover, a retractable USB cable (EG Ghost in the Shell), a modular system for the back to house Extra Battery banks and other accessories. This project was a long time coming and instead of 3d printing a shell I found that this container I had full of sharpies was a suitable housing and adds to the "Jank" Factor. I also plan on stickerbombing the back, possibly a hanging charm, and possible LED lights inside the housing.

[numbpill]

need a bit of advice on something rather new to me... i have been DYING to get into some semblance of diy electronics/robotics, specifically regarding the idea of building a flipper zero knockoff with a raspberry pi/esp32/arduino. or a hack rf one ripoff, etc. u get it? i wanna make a lil handheld pwnagotchi pet style device for rolljam rf shit, something that can copy and paste and send and receive rf signals, but homemade by my self....

please if anyone has experience, resources, ideas, anything at all= hit me up right now immediately asap today please.... i am so passionate and ready to do this please help me make device go beepboop

[alphachromeyayo]

I made a thing! It's a DIY synth, shoved in an old junction box and given the most lurid paint job imaginable 🎨

Basically 8 DX7s combined, like a Yamaha TX816 except it cost me like 50 bucks instead of 2k

Looks mad, sounds fantastic!

Project is Minidexed, if you want to make one yourself

(You can probably make it a lot neater than mine)

[sb-components]

The Ultimate Pocket Computer For Innovators, Coders, Hackers

piPocket is a revolutionary new pocket computer that is perfect for innovators, coders, hackers, and anyone else who wants to create and build amazing things. piPocket is small enough to fit in your pocket, but it is powerful enough to run a wide range of software, including coding environments, development tools, and even full-blown operating systems.

Features

piPocket is packed with features that make it the perfect pocket computer for innovators and creators. Some of the key features of piPocket include:

Powerful processor: piPocket features a powerful quad-core ARM processor that can run even the most demanding applications.

Large memory: piPocket comes with 4GB of RAM and up to 128GB of storage, giving you plenty of space to store your code and projects.

Versatile I/O: piPocket features a variety of I/O ports, including USB-C, HDMI, and micro SD. This allows you to connect piPocket to a variety of devices, including displays, keyboards, and sensors.

Long battery life: piPocket has a long battery life, so you can work on your projects all day long without having to worry about running out of power.

Use Cases

piPocket is perfect for a wide range of use cases, including:

Coding and development: piPocket is the perfect platform for coding and developing software. It comes pre-loaded with a variety of coding environments and development tools, and it is powerful enough to run even the most demanding applications.

Prototyping and testing: piPocket is also a great tool for prototyping and testing new ideas. It is small and portable, so you can take it with you wherever you go, and it is powerful enough to handle even the most complex prototypes.

IoT and embedded systems: piPocket is also a great platform for IoT and embedded systems development. It is small and low-power, making it ideal for battery-powered devices. It also comes with a variety of I/O ports, so you can connect piPocket to a variety of sensors and actuators.

Conclusion

piPocket is the ultimate pocket computer for innovators, coders, hackers, and anyone else who wants to create and build amazing things. It is small, powerful, and versatile, making it the perfect platform for a wide range of use cases.

Check out piPocket on Kickstarter today and learn more about this amazing new product!

[craftingtableus]

Home Automation Electronics Kit

Discover the fascinating world of smart home technology with this interactive learning kit, designed to spark curiosity in young minds. Combining the versatile ESP32 board with engaging story-based activities, this kit immerses children in the exciting world of home automation. Packed with a variety of sensor modules and programming tools, it allows young learners to build, experiment, and protect a smart home while honing essential STEM skills. Perfect for nurturing creativity and problem-solving abilities, this hands-on kit offers a fun and accessible introduction to the future of technology. Ready to dive in? Click the link to learn more and make your purchase!

[pichondria]

🚀 Just Launched: Power Your Raspberry Pi 5 with Ultimate Flexibility! 🔌

We’re thrilled to introduce our newest product: the USB PD 2.0/3.0 to 5V 5A Converter—your go-to solution for powering the Raspberry Pi 5. Designed for versatility, our converter lets you use ANY adapter or even Li-ion batteries to keep your Pi 5 running smoothly.

🌟 Why You Need This:

Use Any Adapter: No need for a new power supply—simply plug in what you have!

Battery Power: Take your projects on the go with Li-ion battery compatibility.

Effortless Setup: Get up and running in minutes with our easy-to-follow tutorial.

Reliable Performance: Delivers a stable 5V 5A output, ensuring your Pi 5 performs at its best.

Don't miss out on the chance to power your Raspberry Pi 5 with ultimate ease and flexibility. Whether you’re a maker, developer, or hobbyist, this is the power solution you’ve been waiting for!

🔗 Get Started Now: Check out our tutorial and learn more

[electricalinsightsdaily]

A4988 Pinout: A Comprehensive Guide

Discover the functionality and versatility of the Stepper Motor Driver Module A4988 Pinout, a crucial component in the world of robotics and automation. Let’s delve into the key details, with a specific focus on the A4988 pinout for a clearer understanding.

Stepper Motor Driver Module A4988

The A4988 is a stepper motor driver module that plays a pivotal role in controlling the precise movements of stepper motors. Whether you’re working on a 3D printer, CNC machine, or any other project requiring accurate motor control, the A4988 is a go-to choice.

A4988 Pinout Configuration

Understanding the A4988 pinout configuration is essential for effectively integrating the A4988 into your projects. Here’s a breakdown of the key pins:

MS1, MS2, MS3 (Microstep Resolution): These pins determine the microstep resolution, allowing you to set the stepping mode for the stepper motor. Configuring these pins enables fine-tuning of motor movement.

VMOT (Motor Power Supply Voltage): Connect this pin to the motor power supply voltage (typically 8V to 35V) to ensure the proper functioning of the stepper motor.

GND (Ground): Establish the ground connection by linking this pin to the ground of your power supply or microcontroller.

VDD (Logic Power Supply Voltage): Provide the logic power supply voltage (typically 3V to 5.5V) to this pin to power the internal logic circuitry of the A4988.

DIR (Direction Input): Control the direction of the stepper motor by connecting this pin to a digital output on your microcontroller.

STEP (Step Input): Trigger individual steps of the stepper motor by connecting this pin to another digital output on your microcontroller.

RESET (Reset Input): This pin resets the internal translator circuit, and it is optional to use.

SLEEP (Sleep Input): Putting the A4988 into sleep mode is achieved by connecting this pin to a digital high signal.

Read More: A4988 Pinout

[teardownit]

Pi Extension board "PiEBridge"

"PiEBridge" is an extension board for microcomputers similar to the Raspberry Pi (Pi), which is designed to be a helper for the DIY-maker in all his activities - Pi, together with PiEBridge, can perform a variety of functions:

universal programmer

software and hardware debugger for target systems

PCB fusion furnace controller

smart-home controller

as well as do many other useful things

You might say Pi already knows how to do these useful things, so why does it need more extension boards? Here is the answer to that question:

PiEBridge transforms the Pi's 40-pin I/O subsystem into more practical 6/10-pin lines for many applications and provides signal integrity for these lines

adds the simplest controls and indications (button, pedal, and LEDs)

has a programmable 2.5...5V power supply for external devices

"Naked" Pi is usable in two extreme configurations - either just a box controlled externally via SSH or a desktop computer with a monitor, keyboard, and often even a mouse. In addition to these typical use cases, PiEBridge allows you to use the Pi as a standalone software automaton to perform random repeating tasks with minor interactive operator participation.

PiEBridge is plugged into the Pi extension connector (compatible with family models with a 40-pin connector) and installed vertically. For this purpose, the Pi case (if available) must have a corresponding cutout on top.

When used as a programmer, PiEBridge can work with most known 6-pin and 10-pin connectors, and GND and Vcc can be randomly connected to their pins to ensure compatibility.

The programmable power supply for external devices is programmable on/off and programmable in the range of 2.5 - 5V with an accuracy of about 2%.

Deb-packages for PiEBridge have been created and compiled into a repository:

general-purpose, providing configs and libraries for working with controls and indications, as well as with the power supply

special purpose, e.g., applications for MCU and FPGA programming and debugging

auxiliary purpose, for example, for repeating operations automation (like mass-production function for firmware flashing). In this case, the user can use settings that provide autonomous launching of the necessary software when the Pi is turned on, and then (after finishing its work) its simple parking and shutdown by pressing and holding the button for a long time.

metapackages, which cause installation of necessary software and configs for the selected role and allow to simplify preparation for work

[techbyrish]

Amazing USB to LoRa Dongle for sale @SB Components. BUY NOW LINK : https://shorturl.at/ajqNY

[zeroloop]

GeeekPi Raspberry Pi Micro GPIO Terminal Block Breakout Board Module with LED

Questo e un terminale per GPIO dotato di morsetti a vite e led compatibile con la maggior parte dei Raspberry pi. Nella confezione di vendita oltre il terminale troviamo tutto il necessario per montarlo su Raspberry Pi.  Premetto che sono appassionato di elettronica  e ho in dotazione  vari Raspberry Pi (dal 2B al 4 e Zero) e utilizzo spesso il GPIO per i miei progetti. Lo utilizzato per il…

[synths-and-sensibility]

Victory!

It's a whole entire rats nest and I can't keep little hands away, but I managed to get signals routed and audio generated

Woohoo! I'm on vacation, but rainy afternoon is a perfect excuse to play with my toys. Accomplishments for the day consist of:

Teensy is receiving MIDI

PC is routing messages from the virtual keyboard to the Teensy

Next steps:

Get Raspberry Pi set up as the midi hub

Get neotrellis sending messages to the hub/Teensy

Get the Teensy responding to midi (one of my goals is a Karplus-Strong implementation)

Get the ATMega32U4 that I brought along on this trip playing too

[ayeforscotland]

Ad | Some Humble Bundle Goodies

One for the audio engineers - The Audio Arcade bundle gives you a whole bunch of royalty-free music and SFX as well as plugins to insert in all the major game engines. Ambient tracks, environmental sounds, explosions, you name it.

Money raised goes towards Children's Miracle Network Hospitals.

For those who dabble in Virtual Reality, the Upload VR Showcase with Devolver Digital has a bunch of Serious Sam VR games as well as the Talos Principle, a really solid puzzle game.

Money raised goes to Special Effect which helps people with disabilities enjoy games via accessible controllers. I've seen the stuff they do and it's honestly great.

Want to get into programming but don't know where to start? The Learn to Program bundle has a tonne of resources covering everything from HTML and CSS through to Python, C# and Ruby.

Money raised goes towards Code.org which seeks to expand participation in computing science by helping women and students of colour.

The Future Tech Innovators Toolkit is a software bundle with courses on Robotics, Electronics and programming with Raspberry Pi and Arduino.

Money raised goes towards Alzheimers Research UK.

The Home How-To Guides bundle offers a complete set of books for home improvements and projects. Want to know more about plumbing, home repair, bathrooms, wiring or carpentry? This bundle has you covered.

Money raised goes to It Gets Better, a charity that supports LGBT Youth.

Want to pick up the latest Elden Ring DLC? It's also available on the Humble Store with the key being redeemable on Steam.

[sb-components]

Buy Rock 4 Model C+ 4GB at Best Price

A dependable Rockchip RK3399T SoC, Dual Cortex® A72 CPU, and Arm MaliTM T860MP4 GPU make up the ROCK 4C+, a multipurpose, high-performing single-board computer. The board, created by OKdo Technology in partnership with Radxa, includes best-in-class functionality appropriate for a variety of multimedia and industrial applications, assuring exceptional dependability.

The single-board computer ROCK 4C+ is energy-efficient and comes with an inbuilt On/Off power switch. It also has several storage options, including an eMMC socket and 4GB of 64-bit RAM, as well as an inbuilt fan controller, an external antenna, an audio connection, support for twin displays, and two micro-HDMI ports that can handle screens with a resolution of up to 4Kp60.

ROCK 4 SE - a robust, versatile special edition single-board computer 

High-performing Hexa-core Rockchip RK3399-T processor big.LITTLE™ Arm® Dual Cortex-A72® CPU, Quad-core Cortex-A53 and Arm Mali™ - T860MP4 GPU

Available in a 4GB 64bit LPDDR4 RAM option

Expandable with eMMC module

Onboard RTC, WiFi, Bluetooth, Antenna, Audio jack (headphone and headset), 4K HDMI port
